Main Logic Board Connectors

Figure Legend
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
Connector
EISA expansion slots (1 through 4); slot one is a shared EISA/PCI slot
Primary PCI expansion slots (1 through 4); slot four is a shared PCI/EISA
slot
Memory module 2
Serial ports
Parallel port and video port
Mouse and keyboard ports
Secondary PCI expansion slots (5 through 8)
Diskette drive
3.3 V dc power supply
5 V dc power supply
Power control signal
Top cover interlock connector
Operator Control Panel (OCP)
Processor module 1
Memory module 1
Processor module 2 or terminator card
Fan connector (fans 1 through 4)
Speaker
Remote Server Management (RSM)
FRU Replacement
5-19
