1. Bleeding Air from the System
A� Cycle the hydraulic system until operation is smooth and consistent�
B. Check the pump reservoir level. Add Power Team hydraulic fluid as needed.
2. Air Motor Operation
A� Connect the air supply line�
B� The remote hand control has two momentary push buttons,
advance and retract, with spring offset to hold�
Press push buttons accordingly�
3. Adjusting the Pressure Regulating Valve (if equipped). All others are factory
preset
NOTE: For easy adjustment of the pressure regulating valve, always adjust the pressure by increasing to the
desired pressure setting.
A� Loosen the locknut on the pressure regulating valve�
NOTE: The pressure range is from 69-690 bar (1,000-10,000 psi), depending on the pump model.
B� Use a screwdriver to back out the adjusting screw a few turns in a counterclockwise direction� This
decreases the setting to a lower-than-desired pressure�
C� Air - The pump must be completely connected� Connect the pump to the appropriate air source and start the
pump�
D� With the screwdriver, slowly turn the adjusting screw in a clockwise direction� This gradually increases the
pressure setting� When the desired pressure is reached, lock the adjusting screw in position by tightening
the locknut�
© SPX FLOW, Inc.

OPERATING INSTRUCTIONS

9
Figure 2. Air Pendant Control
