SPX FLOW Bolting System RWP55-BS Operating Instructions Manual page 25

Parts List Continued
ITEM PART NO.
1 10020
2 33113
3 10361
4 10375
5 23547
6 23548
7 11228
8 11813
9 11814
10 23549
11 11955
12 11064
13 11261
14 23556
15 11821
16 23557
17 30533
18 10001
19 21091
20 11199
21 10266
22 40120
23 10427
24 21272
25 10303
26 10425
27 20771
28 10271
29 12389
30 20849
31 23255
32 10426
33 23256
200423
200645
© SPX FLOW, Inc.
SCREW, 1/4-20 X 1�25 (Torque to 19-20 Nm (170-180 in-lbs�))
HIGH PRESSURE PUMP
SPRING COMPRESSION
STEEL BALL
BEARING TOP PLATE
TOP PLATE
THRUST BEARING
BEARING RACE
BALL BEARING
10 DEGREE ANGLE PLATE
SPRING SLOTTED PIN
NEEDLE BEARING
EXTERNAL RETAINING RING
SHAFT
WOODRUFF KEY
DRIVE GEAR
PUMP END PLATE
SCREW, #10-32 X 1�75 (Torque to 6-7 Nm (50-60 in-lbs�))
DRIVE COUPLING
NEEDLE BEARING
O-RING
PUMP - MACHINE BODY
PIPE PLUG
DRIVE GEAR
O-RING
SPRING COMPRESSION
POPPET
O-RING
BACKUP WASHER
SPOOL
SPRING GUIDE
SPRING COMPRESSION
SPRING GUIDE
PARTS INCLUDED BUT NOT SHOWN
SHIM - 0�065/0�070 THICK
SHIM - 0�020 THICK
DESCRIPTION
24
QTY.
9
1
1
1
1
1
2
3
1
1
1
2
2
1
1
1
1
12
1
2
1
1
1
1
1
2
2
1
1
1
1
1
1
1
2
Form No. 1000680
Rev. 5 Nov. 24, 2022
