User Guide | Intelligent Purging System (IPS 8) Ammonia
9 | BC437120335698en-000101
* For easy access to the main switch
* For easy access to the main switch
and servicing, the Purger unit shall be
and servicing, the Purger unit shall be
installed between 0,05 to 1,1 m (2 to 43 in)
installed between 0,05 to 1,1 m (2 to 43 in)
above service platform level.
above service platform level.
Fig. 3 Installation dimensions
Min. 900 mm 1051 mm
Support for 100 kg/ 220 lbs
Service platform
446 mm
Min. 300 mm
Min. 500 mm
32 mm
Flange for R717 access
Min. 900 mm
