Checking the oil level
Regularly check the oil level. To do so:
1. Press stop button (11).
2. A few minutes after stopping, the oil level should be between the oil filler neck (FC) and the top of
the sight glass (Gl).
3. If the oil level is too low, push the emergency stop button to avoid the compressor to start
unexpectedly.
4. Next, close the air outlet valve and open the manual drain valve (Dm) until the air system between oil
separator/air receiver vessel and outlet valve is fully depressurized.
5. Unscrew oil filler plug (FC) one turn to permit any pressure left in the system to escape. Wait a few
minutes.
6. Remove the plug and add oil until the level reaches the filler opening.
7. Fit and tighten the plug (FC).
8. Unlock the emergency stop button and press the "Reset key" on the controller before restarting
5.5

Automatic restarting

Description
The electronic controller has a built-in function to automatically restart the compressor when the voltage is
restored after voltage failure.
68
Position of oil level sight-glass
Whenever the compressor is shut down, the emergency push-button must be pressed or
the electricity isolating switch opened.
