Chicago Pneumatic CPVS 20 Product Description

CPVS 20 – 30 PRODUCT DESCRIPTION
The CHICAGO PNEUMATIC CPVS 20-30 compressor is a quiet, complete and
ready-for-use unit for the production of compressed air for light and medium
industrial applications.
OVERVIEW
The CHICAGO PNEUMATIC CPVS 20-30 consists of a single-stage screw rotary
compressor with oil injection technology, standard low-sound enclosure, ES3000
microprocessor with VSD operation, totally-enclosed fan-cooled (TEFC) motor with
soft start and reliable belt-drive transmission. Maximum operating pressure is 190
psig. The CHICAGO PNEUMATIC CPVS 20-30 is designed for indoor installation
and carries a standard 1 year warranty.
warranty shall be extended to a CP SECURE 5 Year Warranty (see warranty policy
for details).
MAJOR COMPONENTS
1. Dry air suction filter. Before being ingested, the atmospheric air is filtered by a
panel pre-filter placed on the cabinet of the machine. The air is then filtered
again by the 2 micron air filter element at the inlet of the compressor
2. Inlet assembly equipped with intake regulator and solenoid valve for idle or
discharge operation, able to avoid oil backups due to eventual and sudden stops
under load
3. 5 on 6 lobe rotary screw compressor airend that assures:
- Maximum yield and maximum efficiency in any condition of operation
- Low noise level
- Low air losses and/or blow-by
4. Asynchronous, 460V, three-phase electric motor, 2 pole, class F insulation, top-
mounted junction box and TEFC protection which provides resistance to dust,
debris and liquids, increasing motor and compressor life
5. Efficient cooling system with forced ventilation and air flows via dedicated turbine
or axial fan for optimum heat transference to package ambient
6. The drive transmission from the electric motor to the compression unit is
performed by means of V-belts. Multiple belts permit the dissipation of heat,
increasing their longevity and decreasing downtime.
7. Oil filter to hold eventual solid particles in suspension in the oil helping to prevent
contamination into the airend and compressed air.
8. High efficiency air/oil separator element to ensure the best separation of oil from
the compressed air. Separation shall take place through at least three methods,
CPVS 20-30 Product Description
Upon satisfactory commissioning, the
