Rear rail in rack
Outer cover of rack
10
Rackmount the
autoloader,
continued
c
Attach one support bracket to each rear
rail, loosely installing the screws through
the clip nuts. Make sure that you attach
the side of the support bracket that has
only two holes, and do not tighten the
screws yet. You will tighten the screws in
Step h.
Support bracket
d
Put the autoloader into the rack and do
the following:
1. Position the autoloader in the rack so
that each autoloader bracket rests on a
support bracket. Each autoloader
bracket should slide along the lip of the
support bracket. (Procedure continues.)
Autoloader bracket
Support bracket
11
