Printronix P7000 Programmer's Reference Manual page 66

Chapter 3
P-Series EVFU
Table 19. P-Series EVFU Codes - PI Line Enabled
ASCII
Hex Dec. Code
0C 12 FF
0D 13 CR
0E 14 SO
0F 15 SI
6E 110 n
6F 111 o
Table 20. P-Series EVFU Codes - PI Line Disabled or Not Used
ASCII
Hex Dec. Code
10 16 DLE
11 17 DC1
12 18 DC2
13 19 DC3
14 20 DC4
15 21 NAK
16 22 SYN
17 23 ETB
18 24 CAN
19 25 EM
1A 26 SUB
1B 27 ESC
1C 28 FS
1D 29 GS
1E 30 RS
66
PI 8 7 6
1 X X X
1 X X X
1 X 0 0
1 X 0 0
1 X 1 1
1 X 1 1
(X = Undefined, 0, or 1) (1 = High) (0 = Low)
Data Bits
8 7 6
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
Data Bits
5 4 3 2
0 1 1 0
0 1 1 0
0 1 1 1
0 1 1 1
0 1 1 1
0 1 1 1
5 4 3 2
1 0 0 0
1 0 0 0
1 0 0 1
1 0 0 1
1 0 1 0
1 0 1 0
1 0 1 1
1 0 1 1
1 1 0 0
1 1 0 0
1 1 0 1
1 1 0 1
1 1 1 0
1 1 1 0
1 1 1 1
Channel
1
0 13
1 14
0 15
1 16
0 Start
Load
1 End
Load
Channel
1
0 1 (TOF)
1 2
0 3
1 4
0 5
1 6
0 7
1 8
0 9
1 10
0 11
1 12 (VT)
0 13
1 14
0 Start Load
