Vertical Tab Set - Printronix P7000 Programmer's Reference Manual

Chapter 2
Configuring The ANSI Emulation
Purpose

Vertical Tab Set

ASCII Code ESC [ p1 ; p.... ; v
Hex Code
Dec Code
Purpose
44
Line terminator. Moves the current vertical position by the
specified p1 number of decipoints as shown in Table 9.
Table 9. Vertical Position
Decipoint Value
missing or 0-4
5-9
10-14
15-19
...
15, 840 or greater
1B 5B p1 3B p... 3B 76
27 91 p1 59 p... 59118
Set up to 12 vertical tabs. The tabs values are in decipoints. If
more than 12 tabs are set, the 12 tabs nearest to the top of form
will be retained. If a tab is set in the top margin, it will be stored,
but not active until the margin is moved. If a tab is set beyond
the bottom margin, an attempt to move to that tab will move the
paper to the next top of form.
Movement in Inches
no movement
1/144 inch
2/144 inch
3/144 inch
...
22 inches
