Display
More parameters can be set in the Expert menu > see 5.2.7 chapter.
5.2.7

Expert menu (MMA)

The Expert menu has adjustable parameters stored that don't require regular setting. The number of
parameters shown may be limited, e.g. if a function is deactivated.
Display
The setting ranges for the parameter values are summarised in the Parameter overview
section > see 10.1 chapter.
5.3

TIG welding

5.3.1

Shielding gas supply (shielding gas cylinder for welding machine)

Risk of injury due to improper handling of shielding gas cylinders!
Improper handling and insufficient securing of shielding gas cylinders
can cause serious injuries!
• Place shielding gas cylinder into the designated holder and secure with
fastening elements (chain/belt)!
• Attach the fastening elements within the upper half of the shielding gas
cylinder!
• The fastening elements must tightly enclose the shielding gas cylinder!
099-002003-EW501
02.03.2017
Setting/selection
Pulse welding (average value pulses)
------- Function switched on
------- Function switched off (ex works)

Pulse frequency

ENTER
Setting/selection
Arcforce correction
• Increase value > harder arc
• Decrease value > softer arc

Pulse balance

Pulse current > see 5.2.6 chapter
Arc length restriction > see 5.4 chapter
------- Function switched on
------- Function switched off
Design and function
Figure 5-13
WARNING
TIG welding
EXIT
25
