Specifications

Function Range Resolution
DC Voltage 600mV 0.1mV
6V 0.001V
60V 0.01V
600V 0.1V
1000V 1V
AC Voltage
6V 0.001V
60V 0.01V
600V 0.1V
1000V 1V
All AC voltage ranges are specified from 5% of range to 100% of range
DC Current
600μA 0.1μA
6000μA 1μA
60mA 0.01mA
600mA 0.1mA
6A 0.001A
10A 0.01A
(20A: 30 sec max with reduced accuracy)
AC Current
600μA 0.1μA
6000μA 1μA
60mA 0.01mA
600mA 0.1mA
6A 0.001A
10A 0.01A
(20A: 30 sec max with reduced accuracy)
All AC voltage ranges are specified from 5% of range to 100% of range
NOTE: Accuracy is stated at 65
±(0.09% reading + 2 digits)
50 to 60Hz
±(1.0% reading + 3 dgts) ±(2.0% reading + 3 dgts)
±(1.0% reading + 3 digits)
40Hz to 1kHz
±(1.5% reading + 3 digits)
o o o o
F to 83 F (18 C to 28 C) and less than 75% RH.
13
Accuracy
40Hz to 1KHz
EX520-EU_ENG V2.3 1/08
