Function Range
Resistance
600Ω
6kΩ
60kΩ
600kΩ
6MΩ
40MΩ
Capacitance 60nF
600nF
6μF
60μF
600μF
1000μF
Frequency 9.999Hz
(electronic)
99.99Hz
999.9Hz
9.999kHz
99.99kHz
999.9kHz
9.999MHz
40MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @
20% to 80% duty cycle and > 100kHz
Frequency 10.00-400Hz
(electrical)
Sensitivity: 15Vrms
Duty Cycle 0.1 to 99.9%
Pulse width: 100µs - 100ms, Frequency: 5Hz to 150kHz
Temp
-50 to 1382°F 1°F
(type-K)
-45 to 750°C
Note: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
Resolution
0.1Ω
0.001kΩ
±(0.3% reading + 4 digits)
0.01kΩ
0.1kΩ
0.001MΩ
±(0.3% reading + 20 digits)
0.01MΩ
0.01nF
0.1nF
±(3.5% reading + 4 digits)
0.001μF
0.01μF
0.1μF
±(5% reading + 5 digits)
1μF
0.001Hz
0.01Hz
0.1Hz
0.001kHz
±(0.1% reading + 1 digits)
0.01kHz
0.1kHz
0.001MHz
0.01MHz
.
0.01Hz ±(0.5% reading)
±(1.2% reading + 2 digits)
0.1%
±(3.0% reading + 5°C/9°F)
(probe accuracy not included)
1°C
