REVO C 3PH from 60A to 800A - 690V

8.3 Cable dimensions (suggested) of Earth and of the Command Terminals

Current
60A (S11)
90A (S11)
120A (S13)
150A (S13)
180A (S13)
210A (S13)
300A (S14)
400A (S14)
450A (S14)
500A (S14)
600A (S17)
700A (S17)
800A (S17)
Bus bar
3PH 300A
30
15 15
Earth
Cable
mm² AWG
16 6
16 6
16 6
25 4
25 4
25 4
50 1
50 1
70 1/0
70 1/0
70 1/0
70 1/0
70 1/0
3PH 400A
66
33
Screw
M
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
33
15
25
User's manual
Command Terminals
Cable
mm² AWG
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
0,50 18
3PH 450-800A
66
15
36
