Danfoss iC7 Series Installation Manual page 13

In-bottom/Out-back Cooling Kit for FA09-FA10
Installation Guide
1
2
3
4
5
6
Illustration 10: Installation of the Frequency Converter in the Cabinet
1 Mounting holes
2 M10x30 screw
3 Frequency converter
4 Seal plate gasket
5 Seal plate
2.8 Installing the Duct Support Plate
The duct support plate attaches the bottom duct to the lower end of the frequency converter. To install the duct support plate, use
the following steps. Refer to
Procedure
Danfoss A/S © 2022.03
Illustration 11.
6 M10x30 screw
7 Pem nuts
8 Cutout gasket
9 Mounting plate
10 Strip gasket
AN371942757356en-000101 / 136R0252 | 13
Installation
7
8
9
10
