In-bottom/Out-back Cooling Kit for FA09-FA10
Installation Guide
2.2 Installation Overview
APPLYING GASKETS
This kit contains self-adhesive gaskets to ensure a proper seal between metal parts.
-
Before affixing a gasket, check that the part matches the gasket and that no holes are covered.
1
2
3
4
5
6
7
Illustration 2: Overview of In-bottom/Out-back Cooling Kit
4 | Danfoss A/S © 2022.03
N O T I C E
Installation
8
9
10
11
12
AN371942757356en-000101 / 136R0252
