Commissioning

The following details are correct for the VAR4/12/20 Router, VAR8, and VAR8-ACU software
versions at the time of publication:
•
VAR4/12/20 Router:
Master board (Board 0): CP
Slave board (Board 1 and 2): CP V6.1.0002 or later DSP V3.2.0213 or later
•
VAR8: CP V3.1.0010 or later / DSP V3.0.0415 or later
•
VAR8-ACU: CP V3.1.0006 or later / DSP V3.0.0415 or later
If any difficulties are encountered, then refer to ASL for advice, quoting the software versions
of your system.
The software versions are displayed via the following menu option:
•
VAR4/12/20: Configuration System Misc Software
•
VAR8/VAR8-ACU: Config System Misc Software
For details refer to your system specific documentation available from ASL's website:
www.asl-control.co.uk
Configure the fault reporting of the battery backup system from the Router Configuration Tool, or from the
system front panel as described in the following sections. Note that Access Level 3 is required for
configuration tasks.
5.1

Obtaining the Router's Contact

Check the system design documentation to find the Router contact being used to report the battery
backup system fault.
5.2

Configuring the Router Contact for Fault Reporting

VAR4/12/20 Menu: Configuration System Router Control Contacts <Contact #
VAR8/VAR8-ACU Menu: Configuration System Router Ctrl Contacts <Digital #
Possible values:
System default configuration: 'Not Conf'
1 This is referred as the VAR Router SW version unless other code is specified, e.g., DSP SW.
BPC130 / BDIST / MDIST – Product Manual
1
V6.1.0010 or later / DSP V4.1.0688 or later
'Not Conf'
'Routing'
'Fault Accept'
'Fault Clear'
'{Route Reset}'
'{Music Select}' (VAR4/12/20 only)
'Global Silence' (VAR8-ACU only)
U-0456-0145.doc – Issue: 04 complete, approved
Page 22 of 40
nn
> External Fault
nn
>
External Fault
