Installation

3.1

Equipment and Tool Requirements

•
BPC130 charger tray, battery tray(s), battery pack and front panels
•
BDIST cable assembly of suitable size for all rack battery power feeds
•
MDIST of suitable size for all rack mains feeds
•
Flat-bladed screwdriver (small and medium)
•
Pozidriv screwdrivers (1, 2 and 3)
•
Wire cutters and strippers
•
Ferrules and crimping tool
•
AF spanner with insulated handle for 6 mm nuts
•
AF spanner for 4 mm nuts
•
A 19-inch standard rack fitted with supporting rails and wired with power supply, signal, and control
wiring, as required by your specific system design
3.2

Cabling Requirements

Signals
Mains supply
Mains distribution
Battery distribution
(for high current
equipment, e.g.
Amplifier Mainframes)
Battery distribution (for
low current equipment,
e.g. Routers)
Fault relay
Refer to BS7671:2008 (Requirements for Electrical Installations) or other appropriate local standards
for guidelines on maximum potential cable lengths given the actual installation parameters.
BPC130 / BDIST / MDIST – Product Manual
Cable Description Termination
1 x 3-core mains
Suitable ferrules
cable
•
IEC-IEC 10 A
mains lead
•
•
1 x 1-core red
1 x 1-core black
•
•
1 x 2-core cable
•
•
•
•
1 x 2-core cable
•
U-0456-0145.doc – Issue: 04 complete, approved
Amplifier Mainframe end:
IEC320-C13 (female)
MDIST end: IEC320-C14 (male)
Amplifier Mainframe end: 7W2
mixed signal D connector
(female)
BPC130 end: suitable ferrules
VAR4/12/20 end: 2-way
pluggable Wago cage clamp
terminal (male)
VAR8/VAR8-ACU end: suitable
ferrules
BPC130 end: suitable ferrules
VAR4/12/20 end: standard
25-way D connector (male)
VAR8/VAR8-ACU end: suitable
ferrules
BPC130 end: suitable ferrules
Page 8 of 40
Suggested Type
Suitably rated standard
mains cable
ASL MDIST4, MDIST6 or
MDIST8 cable assembly
ASL BDIST4-CA,
BDIST6-CA or
BDIST8-CA cable
assembly
Suitably rated 2-core
cable
Suitably rated 2-core
cable
