3.4.2.5

Fitting the Front Panel

10. After batteries have been installed and commissioned, fit all front panels using M6 cage nuts, screws
and nylon washers.
11. Fit the supplied caution label to the appropriate front panel.
3.4.2.6

Powering the system up

12. Connect the AC mains supply to the charger.
13. Wait for the batteries to fully charge (24 hours) and then switch the Mini Circuit Breakers on as
required.
3.4.2.7

Commissioning the Battery Backup System at the Router

14. Commission the BPC130 as described in Section "5 Commissioning" (page 22).
3.4.3

MDIST Installation

MDIST comprises a distribution block and a number of IEC320-IEC320 leads with lengths to
suit ASL rack layout specification; please refer to ASL for details.
1. Ensure that the AC mains supply to the MDIST is isolated.
2. Fit the incoming mains cable through the gland and connect it into the terminal block inside the end
of the distribution block.
1) Ensure that the incoming mains cable is suitably rated for the load.
!
!
2) Ensure that the gland and terminals are tightly fitted.
3. The MDIST distribution block should be mounted behind the charger tray using the fixings provided.
4. Ensure that the earth strap provided on the distribution block is connected to the rack.
5. Connect all required IEC320-IEC320 leads between the distribution block and equipment.
6. Ensure that all cables are tied back neatly and clear from any sharp edges or other risk of chafing.
7. Connect the AC mains supply to the MDIST.
