Connection Diagram - ASL INTERCOM BPC130 Series Product Manual

4

Connection Diagram

Figure 17 Connection diagram
Batteries
Charger
Mains Input
to rack
Fault Relay: connect to any available Router contact. For further details, refer to the Router user documentation.
BPC130 / BDIST / MDIST – Product Manual
Battery Output
25A Breaker
Battery Output
25A Breaker
Batteries
3A Breaker
(-BT &+BT)
Charger Output
(0V &+V)
3A Breaker
Fault relay FLTNO
Fault relay FLTCOM
BPC130 components
U-0456-0145.doc – Issue: 04 complete, approved
Page 21 of 40
Amplifier
Mainframe
Amplifier
Mainframe
Aux. I/O
Router
+V
Contact +
Contact -
0V
External components
Rack components
ASL EMS
series
microphone
