3.4.1.6
Powering the System Up
23.
Connect the AC mains supply to the charger.
24.
Wait for the batteries to fully charge (24 hours) and then switch the Mini Circuit Breakers on as
required.
3.4.1.7
Commissioning the Battery Backup System at the Router
25.
Commission the BPC65 as described in Section "5 Commissioning" (page 16).
3.4.2
MDIST Installation
MDIST comprises a distribution block and a number of IEC320-IEC320 leads with lengths to
suit ASL rack layout specification; please refer to ASL for details.
1.
Ensure that the AC mains supply to the MDIST is isolated.
2.
Fit the incoming mains cable through the gland and connect it into the terminal block inside the end
of the distribution block.
1) Ensure that the incoming mains cable is suitably rated for the load.
!
!
2) Ensure that the gland and terminals are tightly fitted.
3.
The MDIST distribution block should be mounted behind the charger tray using the fixings provided.
4.
Ensure that the earth strap provided on the distribution block is connected to the rack.
5.
Connect all required IEC320-IEC320 leads between the distribution block and equipment.
6.
Ensure that all cables are tied back neatly and clear from any sharp edges or other risk of chafing.
7.
Connect the AC mains supply to the MDIST.
BPC65 / BDIST / MDIST – Product Manual
U-0456-0143.doc – Issue: 03 complete, approved
Page 14 of 32
