Figure 1
BPC130 charger tray and battery tray layout
CHARGER
BATTERY (2 x 6 V) *
BATTERY TRAY
(PN: BTRAY130-SER600)
BATTERY (2 x 6 V) *
BATTERY TRAY
(PN: BTRAY130-SER600)
385 mm
RACK DEPTH = 600 mm
BPC130 / BDIST / MDIST – Product Manual
CHARGER
BDIST
TRAY
(PN: BPC130)
U-0456-0145.doc – Issue: 04 complete, approved
Page 6 of 40
BDIST
CHARGER
BATTERY *
BATTERY *
(1 x 6 V)
(1 x 6 V)
BATTERY TRAY
(PN: BTRAY130-SER800)
660 mm
RACK DEPTH = 800 mm
* BATTERY PACK = 4 x 6V
(PN: BPC130-BAT)
CHARGER
TRAY
(PN: BPC130)
BATTERY *
BATTERY *
(1 x 6 V)
(1 x 6 V)
