Figure 21
Overall dimensions – Battery tray for rack with 800 mm depth
BATTERY TRAY (TOP VIEW)
BATTERY TRAY (FRONT VIEW)
BPC130 / BDIST / MDIST – Product Manual
TOP OF BATTERY
TOP OF BATTERY
TOP OF BATTERY
TOP OF BATTERY
FRONT OF BATTERY
344 mm
476 mm
U-0456-0145.doc – Issue: 04 complete, approved
Page 33 of 40
