UM1724
Connect
Pin No.
or No.
CN9
digital
1. Please refer to
Warning:
CN No.
Pin No.
Left connectors
CN6
power
CN8
analog
All manuals and user guides at all-guides.com
Table 15. Arduino connectors on NUCLEO-L053R8 (continued)
Pin name
8
D7
7
D6
6
D5
5
D4
4
D3
3
D2
2
D1
1
D0
Table 9: Solder bridges
PWM is not supported by D10 on STM32L053 since the timer
is not available on PB6.
Table 16. Arduino connectors on NUCLEO-L152RE
Pin name
1
NC
2
IOREF
3
RESET
4
+3V3
5
+5V
6
GND
7
GND
8
VIN
1
A0
2
A1
3
A2
4
A3
5
A4
6
A5
DocID025833 Rev 4
Hardware layout and configuration
MCU pin
PA8
PB10
PB4
PB5
PB3
PA10
PA2
PA3
for details.
MCU pin
-
-
NRST
-
-
-
-
-
PA0
PA1
PA4
PB0
(1)
PC1 or PB9
ADC_IN11 (PC1) or I2C1_SDA (PB9)
(1)
PC0 or PB8
ADC_IN10 (PC0) or I2C1_SCL (PB8)
Function
-
TIM2_CH3
TIM12_CH1
-
TIM2_CH2
-
USART2_TX
USART2_RX
Function
-
3.3V Ref
RESET
3.3V input/output
5V output
Ground
Ground
Power input
ADC_IN0
ADC_IN1
ADC_IN4
ADC_IN8
41/55
54
