- Page 1 Aristo® Mig 5000i WeldCloud™ 400 V Instruction manual Valid for: serial no. 834-xxx-xxxx 0463 663 001 GB 20200326...
-
Page 3: Table Of Contents
If necessary ..................... Every year ....................TROUBLESHOOTING ................. ORDERING OF SPARE PARTS ..............DIAGRAM ......................ORDERING NUMBERS ..................24 SPARE PARTS LIST .................... 25 ACCESSORIES ....................26 Rights reserved to alter specifications without notice. 0463 663 001 © ESAB AB 2020... -
Page 4: Safety
Safety Data Sheets (SDSs). Safety precautions Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or near the equipment observes all the relevant safety precautions. Safety precautions must meet the requirements that apply to this type of equipment. The following recommendations should be observed in addition to the standard regulations that apply to the workplace. - Page 5 Protect your eyes and body. Use the correct welding screen and filter lens and wear protective clothing. • Protect bystanders with suitable screens or curtains. NOISE - Excessive noise can damage hearing Protect your ears. Use earmuffs or other hearing protection. 0463 663 001 - 5 - © ESAB AB 2020...
- Page 6 There may be potential difficulties in ensuring electromagnetic compatibility of class A equipment in those locations, due to conducted as well as radiated disturbances. 0463 663 001 - 6 - © ESAB AB 2020...
- Page 7 For further information contact the nearest ESAB dealer. ESAB has an assortment of welding accessories and personal protection equipment for purchase. For ordering information contact your local ESAB dealer or visit us on our website. 0463 663 001 - 7 - ©...
-
Page 8: Introduction
The power source Mig 5000i WeldCloud™ is combined with U8 and provides a control box which enables wireless monitoring. ESAB accessories for the product can be found in the "ACCESSORIES" chapter of this manual. For more information about feed units, refer to the Instruction manuals. -
Page 9: Technical Data
68 - 80 V MIG/MAG (GMAW), MMA (SMAW), VRD 59 V function deactivated 2) VRD function activated 2) < 35 V Operating temperature -10 to +40 °C (14 to 104 °F) 0463 663 001 - 9 - © ESAB AB 2020... - Page 10 Maximum water flow 2.0 l/min (0.53 us gal) Maximum number of water-cooled Two MIG welding torches or one TIG torch and one welding torches that may be connected MIG welding torch 0463 663 001 - 10 - © ESAB AB 2020...
-
Page 11: Installation
Lifting instructions Power source Trolley and power source Trolley 2 and power source Placing Position the welding power source such that its cooling air inlets and outlets are not obstructed. 0463 663 001 - 11 - © ESAB AB 2020... -
Page 12: Mains Power Supply
With control unit U8 and wire feed units without control panel it is possible to manage up to 4 wire feed units from one power source. It is possible to choose between the following connections: 0463 663 001 - 12 - © ESAB AB 2020... - Page 13 B. Welding current connection C. Control box connection Four wire feed units Two connection kits and an extra cooling unit are required when connecting four wire feed units, see chapter "ACCESSORIES". 0463 663 001 - 13 - © ESAB AB 2020...
- Page 14 4 INSTALLATION A. Water connection B. Welding current connection C. Control box connection 0463 663 001 - 14 - © ESAB AB 2020...
-
Page 15: Operation
10 WeldCloud™ version: Antenna 21 Connection for cooling water to the wire feed unit - BLUE 11 WeldCloud™ version: USB Connectivity 22 Connection for cooling water from the wire feed unit - RED 0463 663 001 - 15 - © ESAB AB 2020... -
Page 16: Turning On The Power Source
The program version in U8 should be 1.20 or higher. Power sources with intergral control panels should have program version 1.21 or higher, in order for the remote control to function correctly. 0463 663 001 - 16 - © ESAB AB 2020... -
Page 17: Weldcloud™ Unit
After set-up and restart, the power source will be visible in WeldCloud™. For more information about the WeldCloud™ unit and features, see the WeldCloud™ instruction manual. 0463 663 001 - 17 - © ESAB AB 2020... -
Page 18: Maintenance
• Replace the fan grille with the dust filter. • Top up with coolant ESAB's ready mixed coolant is recommended for use. See chapter "ACCESSORIES". • Top up with coolant until it covers half the inlet pipe. NOTE! Coolant must be topped up if connecting a welding torch or connection cables that are 5 m in length or longer. -
Page 19: Every Year
(reduced pressure). • Change the coolant and clean the hoses and water reservoir with clean water. • Check seals, cables and connections. Tighten if necessary and replace any defective parts. 0463 663 001 - 19 - © ESAB AB 2020... -
Page 20: Troubleshooting
• Check that the correct current value is set. • Check that the correct wire is being used. • Check the main power supply fuses. 0463 663 001 - 20 - © ESAB AB 2020... -
Page 21: Ordering Of Spare Parts
It is the obligation of the service unit which has carried out the service or repair work to make sure that the product still conforms to the mentioned standards. Spare parts and wear parts can be ordered through your nearest ESAB dealer, see esab.com. When ordering, please state product type, serial number, designation and spare part number in accordance with the spare parts list. -
Page 22: Diagram
DIAGRAM DIAGRAM 0463 663 001 - 22 - © ESAB AB 2020... - Page 23 DIAGRAM Cooling unit 0463 663 001 - 23 - © ESAB AB 2020...
-
Page 24: Ordering Numbers
0445 400 881 Welding power source Mig 5000iw WeldCloud™, 400 V With cooling unit 0459 839 018 Spare parts list Mig 5000i, Mig U5000i, Mig 5000i WeldCloud™, Mig U5000i WeldCloud™ Technical documentation is available on the Internet at: www.esab.com 0463 663 001 - 24 - © ESAB AB 2020... -
Page 25: Spare Parts List
SPARE PARTS LIST SPARE PARTS LIST Item Ordering no. Denomination 0458 398 001 Filter 0458 383 991 Front grill 0463 663 001 - 25 - © ESAB AB 2020... -
Page 26: Accessories
Trolley 0558 102 311 Kit adapter for 4004HD feeder 0458 731 880 Guide pin 0278 300 401 Insulating bushing for guide pin, included in trolley 0459 145 880 Autotransformer TUA2 0463 663 001 - 26 - © ESAB AB 2020... - Page 27 0459 491 883 Remote control unit AT1 CAN MMA and TIG: current 0459 491 884 Remote control unit AT1 CF CAN MMA and TIG: rough and fine setting of current. 0463 663 001 - 27 - © ESAB AB 2020...
- Page 28 15 m 0459 528 974 25 m 0459 528 975 35 m Connection set air-cooled CAN 12-10 pole 0459 528 960 1.7 m 0459 528 961 0459 528 962 10 m 0463 663 001 - 28 - © ESAB AB 2020...
- Page 29 0461 203 880 Water return flow guard Mech 7 m 0459 579 880 MMC kit for power source Mig 0459 546 880 Connection set for connection of two wire feed units 0463 663 001 - 29 - © ESAB AB 2020...
- Page 30 ACCESSORIES 0414 191 881 Cooling unit OCE2H 0465 720 002 ESAB ready mixed coolant (10 l / 2.64 gal) Use of any other cooling liquid than the prescribed one might damage the equipment. In case of such damage, all warranty undertakings from ESAB cease to apply.
- Page 31 ACCESSORIES 0463 663 001 - 31 - © ESAB AB 2020...
- Page 32 For contact information visit esab.com ESAB AB, Lindholmsallén 9, Box 8004, 402 77 Gothenburg, Sweden, Phone +46 (0) 31 50 90 00 http://manuals.esab.com...
