Better Solutions Are Within Reach
Programming
A programming remote control (PD108-420) is used to perform all setup operations for the TV.
NOTE: The following instructions assume you have correctly mounted the TV, wired an external pillow
speaker, and connected an RF coax cable signal, and AC power cord to the TV.
Service Levels Setup
The CV2200, CV3200 TV contains four separate service levels, allowing the hospital to offer basic and enhanced
viewing. The current service level can be quickly determined by accessing the SETUP menu using the remote
control. Service Level can be changed to any of the 4 levels at any time by entering the SETUP menu and changing
the Service Level setting.
Signal
Four different tuning types are available depending upon the healthcare facility's signal style. Selection of the correct
signal type is required for the TV to recognize all possible channels and before any channel programming can begin.
1.
Press SETUP on the remote control.
Press CH▲ or CH▼ to highlight Channels.
2.
Press VOL► to enter the Channels menu.
3.
Press CH▲ or CH▼ to highlight Signal.
4.
Press VOL◄ or VOL► to select Air, Cable STD, Cable IRC, or Cable HRC.
5.
NOTE: Most hospitals use the Cable STD signal style.
6.
Now perform Auto Program or Add/Delete Channels to adjust the channels.
PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 800-628-9870 FX 937-743-5664
MODEL NUMBER:
CV2600, CV3200
Healthcare LCD TV
TM
DISABLED – This is like a mechanical key lock. The TV can be
turned OFF and ON, but cannot be used for viewing programs. A
standard message appears on a black screen.
FREE – This lets patients watch hospital education and information
channels without renting the TV. The channels containing
programming for no charge are typically programmed into this level of
service. This is the factory default setting for Service Level.
BASIC – This service typically allows additional channels beyond
those offered in the FREE level.
PREMIUM – This is the highest service level with typically the most
channels available for viewing.
Document Number:
PD196-241R2
Page 6 of 9
