INSTALLATION /OWNER'S MANUAL

PANORAMA BUILT IN DEEP SERIES

BI-40-DEEP

(DE-190040-1)

BI-50-DEEP

(DE-190050-1)

BI-60-DEEP

(DE-190060-1)

BI-72-DEEP

(DE-190072-1)

BI-88-DEEP

(DE-190088-1)

SAFETY INFORMATION

For your safety, always comply with all

warnings and safety instructions

contained in this manual to prevent

personal injury or property damage.

Do not store or use gasoline or other flammable vapors

and liquids in the vicinity of this appliance.

INSTALLER: LEAVE OWNER'S MANUAL WITH THE APPLIANCE.

CONSUMER: RETAIN OWNER'S MANUAL FOR FUTURE REFERENCE.

DEEP

WARNING

Version:202210

Table of Contents

Need help?

Do you have a question about the DE-190040-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amantii DE-190040-1

Page 1 INSTALLATION /OWNER’S MANUAL PANORAMA BUILT IN DEEP SERIES BI-40-DEEP DEEP (DE-190040-1) BI-50-DEEP DEEP (DE-190050-1) BI-60-DEEP DEEP (DE-190060-1) BI-72-DEEP DEEP (DE-190072-1) BI-88-DEEP DEEP (DE-190088-1) SAFETY INFORMATION WARNING For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage.
Page 2: Table Of Contents
TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ............................FCC CAUTIONS ..................................
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use.
Page 4: Fcc Cautions
FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 5: Unpacking And Testing The Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly.
Page 6: Bi-40-Deep (De-190040-1)
BI-40-DEEP (DE-190040-1) Description Built-in Appliance This appliance been tested Voltage 120V AC 60Hz accordance with the UL Standard 2021 for fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 28.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 7: Bi-50-Deep (De-190050-1)
BI-50-DEEP (DE-190050-1) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 33.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 8: Bi-60-Deep (De-190060-1)
BI-60-DEEP (DE-190060-1) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 36.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 9: Bi-72-Deep (De-190072-1)
BI-72-DEEP (DE-190072-1) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 41.4W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 10: Bi-88-Deep (De-190088-1)
BI-88-DEEP (DE-190088-1) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 45.2W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 11: Mantel Clearance
MANTEL CLEARANCE The clearance to the mantel should be 4” minimum when a mantel is applied (Measurement is taken from the trim). Wall (Combustible facing allowed) Mantel Fireplace Fireplace Floor FOR BATHROOM USE If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit. If If this unit is installed in a bathroom it must be receptacle is used it must be readily accessible.
Page 12: Safety Drill Screw Area
SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) OUTDOOR INSTALLATION This electric fireplace is suitable for installation in outdoor areas protected from direct water impingement.
Page 13: Installation
120 Volt grounded outlet. The rough wall opening size of the fireplace: The rough wall opening size of the fireplace: W(“) D(“) H(“) BI-40-DEEP (DE-190040-1) BI-50-DEEP (DE-190050-1) BI-60-DEEP (DE-190060-1) BI-72-DEEP 73 1/2 (DE-190072-1)
Page 14 1. Take out the unit from the box. Please do the pre Take out the unit from the box. Please do the pre-test before you install the fireplace test before you install the fireplace. Pull out the optional trim from the unit as shows below. ull out the optional trim from the unit as shows below.
Page 15 3. Re-attach the framing plates as shown in the picture. framing plate 4. Bend up the framing plates. Bend up the framing plates.
Page 16 5. Put the unit into the opening. Put the unit into the opening. 6. Drive the mounting screws into the f Drive the mounting screws into the framing plates on the unit and the wall studs. raming plates on the unit and the wall studs. framing plate...
Page 17 7. After checking that the fireplace operates properly, cover the glass panel with protective After checking that the fireplace operates properly, cover the glass panel with protective After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install plywood or drywall.
Page 18 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...
Page 19: Hardwire Installation
HARDWIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance.
Page 20: Panorama Cover Installation
PANORAMA COVER INSTALLATION Make sure install the pan-cover when the fireplace used outdoors. Remove the cover from the packaging. The handles will need to be attached to the cover with the provided hardware as shown in fig. 1 Fig 1 First, place a plate washer and then a spring washer on the screw as shown in fig.
Page 21: Media Options
Media Options The media that come with BI-DEEP are 2. Installing the fire glass media. Pour the large glass nuggets, clear glass, clear, blue fire glass media into the tray as shown below. Feel free to use any combination & white diamond shaped media and of fire glass media that you find most DESIGN-MEDIA-OAK-10PCE.
Page 22: Operation
OPERATION The Fireplace operates by using either the touch panel located on the upper left hand corner or by remote control. Plug the fireplace into a 15 Amp wall socket. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION Press to turn on and off the fireplace.
Page 23: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the fireplace is plugged in and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes some time for the receiver to respond to the transmitter.
Page 24 AUTO means fireplace can automatically adjust to the temperature you set. When in AUTO, you can set the desired temperature with keys. You can switch temperature between Celsius and Fahrenheit with keys.When it is on Auto mode,fireplace operate at 1500W. Press this button to adjust the speed of the flame.
Page 25 When the 7 day timer’s set, the icon will be displayed on the LCD screen of the remote control. Press again to cancel the 7 da y timer and the icon will disappears. NOTE: If the 7 day timing and the general timing are set at the same time, the system will respond to an earlier shutdown time.
Page 26: Wifi Operation
WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart; 1. Search for “TuyaSmart life” in the APP store on your phone, download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION 1.
Page 27 FIG.4 3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds when the fireplace in standby mode. There will be 2 beeps come out from the fireplace and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then please confirm to go next.
Page 28 6. Now you are in the interface like FIG.7. You can operate the fireplace via Wi-fi. FIG.7 NOTE: Turn off the flashing blue Wifi indicator light Touch the (power button) once, the blue light will stop flashing.
Page 31: Exploded View
EXPLODED VIEW...
Page 32: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow...
Page 33: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
Page 34: Warranty
Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Amantii warrants such products to be free from defects in material and workmanship for a period of five (5) years from the date of the ﬁrst purchase of such products.
Page 35 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, speciﬁ cations, prices and the right to discontinue styles and products. GLASS...
