INSTALLATION /OWNER'S MANUAL

PANORAMA BUILT IN DEEP XT SERIES

BI-40-DEEP

DEEP-XT

(DE-T190040-01)

BI-50-DEEP

DEEP-XT

(DE-T190050-01)

BI-60-DEEP

DEEP-XT

(DE-T190060-01)

BI-72-DEEP

DEEP-XT

(DE-T190072-01)

BI-88-DEEP

DEEP-XT

(DE-T190088-01)

INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.

CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.

Version:202106

Table of Contents

Need help?

Do you have a question about the PANORAMA BUILT IN DEEP XT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Amantii PANORAMA BUILT IN DEEP XT Series

Page 1 INSTALLATION /OWNER’S MANUAL PANORAMA BUILT IN DEEP XT SERIES BI-40-DEEP DEEP-XT (DE-T190040-01) BI-50-DEEP DEEP-XT (DE-T190050-01) BI-60-DEEP DEEP-XT (DE-T190060-01) BI-72-DEEP DEEP-XT (DE-T190072-01) BI-88-DEEP DEEP-XT (DE-T190088-01) INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
Page 2: Table Of Contents
TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ............................FCC CAUTIONS ..................................
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use.
Page 4: Fcc Cautions
FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 5: Unpacking And Testing The Appliance
UNPACKING AND TESTING APPLIANCE UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a 120 Volt grounded outlet.
Page 6: Bi-40-Deep-Xt (De-T190040-01)
BI-40-DEEP-XT (DE-T190040-01) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 28.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 7: Bi-50-Deep-Xt (De-T190050-01)
BI-50-DEEP-XT (DE-T190050-01) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 33.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 8: Bi-60-Deep-Xt (De-T190060-01)
BI-60-DEEP-XT (DE-T190060-01) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 36.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 9: Bi-72-Deep-Xt (De-T190072-01)
BI-72-DEEP-XT (DE-T190072-01) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 41.4W If you need assistance during installation, MOTOR HEATER please contact your local dealer.
Page 10: Bi-88-Deep-Xt(De-T190088-01)
BI-88-DEEP-XT(DE-T190088-01) Description Built-in Appliance This appliance been tested Voltage 120V AC 60Hz accordance with the UL Standard 2021 for Watts 1500W Max fixed and location dedicated electric room NO HEATER 45.2W appliances in the United States and Canada. MOTOR HEATER If you need assistance during installation, Appliance Width 88 5/8”...
Page 11: For Bathroom Use
FOR BATHROOM USE If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit. If receptacle is used it must be readily accessible. To prevent electric shock, please be aware that this unit is an electrical appliance that is NOT watertight and must be installed as to prevent water from entering unit.
Page 12: Safety Drill Screw Area
SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) OUTDOOR INSTALLATION This electric fireplace is suitable for installation in outdoor areas protected from direct water impingement.
Page 13: Installation
INSTALLATION NOTE: Due to the many different materials used to build walls, it is highly recommended NOTE: Due to the many different materials used to build walls, it is highly recommended NOTE: Due to the many different materials used to build walls, it is highly recommended that you consult your local builder before you install this appliance on a wall.
Page 14 1. Take out the unit from the box. Please do the pre Take out the unit from the box. Please do the pre-test before you install the fireplace test before you install the fireplace. Pull out the optional trim from the unit as shows below. ull out the optional trim from the unit as shows below.
Page 15 3. Re-attach the framing plates as shown in the picture. framing plate 4. Bend up the framing plates. Bend up the framing plates.
Page 16 5. Put the unit into the opening. Put the unit into the opening. 6. Drive the mounting screws into the f Drive the mounting screws into the framing plates on the unit and the wall studs. raming plates on the unit and the wall studs. framing plate...
Page 17 7. After checking that the fireplace operates properly, cover the glass panel with protective After checking that the fireplace operates properly, cover the glass panel with protective After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install plywood or drywall.
Page 18 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...
Page 19: Hardwire Installation
HARDWIRE INSTALLATION 1. 120V, BI-40-DEEP-XT (DE-T190040-01) only Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance.
Page 20 2. 120V, BI-50/60/72/88-DEEP-XT (DE-T190050/60/72/88-01) only 2.1 WIRING DIAGRAM Wiring diagrams are provided here for reference purposes only. This information is also provided on schematics attached directly to the appliance on the top left corner. CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS APPLIANCE OPERATION.
Page 21 3. 240V, BI-50/60/72/88-DEEP-XT (DE-T190050/60/72/88-01) only 3.1 WIRING DIAGRAM Wiring diagrams are provided here for reference purposes only. This information is also provided on schematics attached directly to the appliance on the top left corner. CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS APPLIANCE OPERATION.
Page 22: Media Options
MEDIA OPTIONS This unit does not come with media. Optional media is available for purchase. See Dealer for additional details. DECORATIVE MEDIA INSTALLATION Take off the front clear glass. There is a bracket that holds the front glass as shows below. Unscrew the screw to take off the bracket.
Page 23: Operation
OPERATION The Fireplace operates by using either the touch panel located on the upper left hand corner or by remote control. Plug the fireplace into a 15 Amp wall socket. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1.
Page 24: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the fireplace is plugged in and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes some time for the receiver to respond to the transmitter.
Page 25 third time to turn on the AUTO mode, press to set the temperature to switch temperature unit between Celsius and Fahrenheit. Press this button to adjust the speed of the flame. There are 3 options: High- Medium- Low. Press this button to turn on and off the ember bed light. When in ON position, the display screen of the remote control shows AD 1, when the number “1”...
Page 26 When the 7 day timer’s set, the icon will be displayed on the LCD screen of the remote control. Press again to cancel the 7 da y timer and the icon will disappears. NOTE: If the 7 day timing and the general timing are set at the same time, the system will respond to an earlier shutdown time.
Page 27: Wifi Operation
WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart; 1. Search for “TuyaSmart life” in the APP store on your phone, download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION 1.
Page 28 FIG.4 3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds when the fireplace in standby mode. There will be 2 beeps come out from the fireplace and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then please confirm to go next.
Page 29 6. Now you are in the interface like FIG.7. You can operate the fireplace via Wi-fi. FIG.7...
Page 31: Exploded View
EXPLODED VIEW...
Page 32: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary Back black cloth is falling off Change a new flicker and back and roll the flicker black cloth Ember bed is not Ember LED’s are burnt out Inspect the ember bed LED’s and...
Page 33: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service Technician Service Performed Special Concerns Name Name NOTES:...
