INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-SLIM
BI-40-SLIM
BI-50-SLIM
BI-60-SLIM
BI-72-SLIM
BI-88-SLIM
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
UNITS
SAFETY INFORMATION
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BI-40-SLIM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amantii BI-40-SLIM

Summary of Contents for Amantii BI-40-SLIM

  • Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-SLIM UNITS BI-40-SLIM BI-50-SLIM BI-60-SLIM BI-72-SLIM BI-88-SLIM SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Table Of Contents

    Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................4...

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. 3.

  • Page 4: Unpacking And Testing Appliance

    UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. GROUNDING APPLIANCE This appliance is for use on 120 Volts.

  • Page 5: Bi-40-Slim

    BI-40-SLIM This appliance has been tested in accordance with the UL Standard 2021 Description Built-in Appliance for fixed and location dedicated Voltage 120V AC 60Hz electric room appliances in the United Watts 1500W Max States and Canada. If you need...

  • Page 6: Bi-50-Slim

    BI-50-SLIM This appliance has been tested in Model Number BI-50-SLIM accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 7: Bi-60-Slim

    BI-60-SLIM Description Built-in Appliance Voltage 120V AC 60Hz This appliance has been tested in accordance Watts 1500W Max with the UL Standard 2021 for fixed and NO HEATER location dedicated electric room appliances MOTOR HEATER in the United States and Canada. If you need Appliance Width 58 5/8”...

  • Page 8: Bi-72-Slim

    BI-72-SLIM Description Built-in Appliance This appliance has been tested in Voltage 120V AC 60Hz accordance with the UL Standard 2021 for Watts 1500W Max fixed and location dedicated electric room NO HEATER appliances in the United States and MOTOR HEATER Canada.

  • Page 9: Bi-88-Slim

    BI-88-SLIM Description Built-in Appliance Voltage 120V AC 60Hz This appliance has been tested in accordance Watts 1500W Max with the UL Standard 2021 for fixed and NO HEATER location dedicated electric room appliances MOTOR HEATER in the United States and Canada. If you need Appliance Width 88 5/8”...

  • Page 10: Installation

    Note: The optional trim can be pulled out directly from the unit. It will need two people to do it. The rough wall opening size of the fireplace: W(＂) D(＂) H(＂) BI-40-SLIM BI-50-SLIM BI-60-SLIM BI-72-SLIM 73 1/2 BI-88-SLIM 89 1/4 1.
  • Page 11 2. Remove the framing plates from the unit framing plate 3. Re-fix the framing plates to the unit as the picture shows framing plate...
  • Page 12 4. Bend up the framing plates. 5. Put the unit into the opening.
  • Page 13 6. Drive the mounting screws into the framing plates on the unit and the wall studs. framing plate 7. After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install polywood. NOTE: IF YOU WANT TO USE THE TRIM KIT SUPPLIED that the thickness of the wall finish can only be 1 inch.
  • Page 14 8. Decorate the polywood with glazed tile, wallpaper, etc. Fireplace 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...

  • Page 15: Safety Drill Screw Area

    SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) T h e m a n u a l c o n tro l p a d p o s itio n For Bathroom Use If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit.

  • Page 16: Hard-Wire Installation

    HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the household wiring.

  • Page 17: Panorama Cover Installation

    PANORAMA COVER INSTALLATION Make sure install the pan-cover when the fireplace used in outdoors. Remove the cover from the packaging. The handles will need to be attached to the cover with the provided hardware as shown in fig. 1 Fig 1 First, place a plate washer and then a spring washer on the screw as shown in fig.

  • Page 18: Outdoor Installations

    For example: if the roof-line (B) is 8’ above the base of the fireplace, the overhang (A) must be at least 4’. *Amantii recommends that the Panorama Series BI-DEEP and BI-SLIM model installations also adhere to these instructions in addition to using the protective PAN-COVER.

  • Page 19: Media Options

    Media Options The BI-40-SLIM, BI-50-SLIM, BI-60-SLIM is shipped with 3 large glass nuggets, clear and blue diamond shaped media and 6 piece log set. The BI-72-SLIM, BI-88-SLIM is shipped with 6 large glass nuggets, clear and blue diamond shaped media and 6 piece log set.

  • Page 20: Operation

    OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2.
  • Page 21 REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will beep once.

  • Page 22: Installing Wall Thermostat

    INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. Turn off circuit breaker. 2. Remove cover plate located on the left side of appliance. Pull the wire out and cut the inside thermostat.

  • Page 23: Replacement Parts

    REPLACEMENT PARTS This list contains replacement parts DESCRIPTION QTY. NO. BI-40-SLIM BI-50-SLIM BI-60-SLIM BI-72-SLIM BI-88-SLIM 602120B 602120B 602120B 602120B 602120B BLOWER AND HEATER ASSEMBLY FIREPLACE BOX 10104010 10104010 10104010 10104010 10104010 SWITCH 601032B 601032B 601032B 601032B 601032B CONTROL PANEL 601097...

  • Page 24: Exploded View

    EXPLODED VIEW...

  • Page 25: Trouble Shooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow...

  • Page 26: Service History

    SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
