INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-DEEP
BI-40-DEEP
BI-50-DEEP
BI-60-DEEP
BI-72-DEEP
BI-88-DEEP
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BI-40-DEEP and is the answer not in the manual?

Questions and answers

Related Manuals for Amantii BI-40-DEEP

Summary of Contents for Amantii BI-40-DEEP

  • Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-DEEP BI-40-DEEP BI-50-DEEP BI-60-DEEP BI-72-DEEP BI-88-DEEP SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................4...

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use.

  • Page 4: Unpacking And Testing Appliance

    UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly.

  • Page 5: Bi-40-Deep

    BI-40-DEEP This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER 28.6W Canada. If you need assistance during...

  • Page 6: Bi-50-Deep

    BI-50-DEEP This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER 33.6W Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 7: Bi-60-Deep

    BI-60-DEEP This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER 36.6W Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 8: Bi-72-Deep

    BI-72-DEEP This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER 41.4W Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 9: Bi-88-Deep

    BI-88-DEEP This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER 45.2W Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 10: Safety Drill Screw Area

    SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) T h e m a n u a l c o n tro l p a d p o s itio n HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing.

  • Page 11: For Bathroom Use

    2. Attach the wiring to the junction block. Please make sure the live wire goes into the “L”, the neutral wire into “N” and the ground wire into “G”. 3. Put the plate back and screw back. FOR BATHROOM USE If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit.

  • Page 12: Outdoor Installations

    OUTDOOR INSTALLATIONS The BI-DEEP series electric fireplaces are suitable for installation in outdoor areas protected from direct water impingement. In addition to maintaining the listed mantel and combustibles clearances, a rain protection overhang factor of 1/2 shall be constructed to the front and to each side of the installed appliance.

  • Page 13: Installation

    Note: The optional trim can be pulled out directly from the unit. It will need two people to do it. The rough wall opening size of the fireplace: W(＂) D(＂) H(＂) BI-40-DEEP BI-50-DEEP BI-60-DEEP BI-72-DEEP 73 1/2 BI-88-DEEP 89 1/4 1.
  • Page 14 2. Remove the framing plates from the unit framing plate 3. Re-fix the framing plates to the unit as the picture shows framing plate...
  • Page 15 4. Bend up the framing plates. 5. Put the unit into the opening.
  • Page 16 6. Drive the mounting screws into the framing plates on the unit and the wall studs. framing plate 7. After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install plywood or drywall. NOTE: In order to use the supplied trim kit, the thickness of the desired wall finish can not exceed 1 inch.
  • Page 17 8. Decorate the plywood or drywall with glazed tile, wallpaper, etc. Fireplace 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...

  • Page 18: Panorama Cover Installation

    PANORAMA COVER INSTALLATION Make sure install the pan-cover when the fireplace used outdoors. Remove the cover from the packaging. The handles will need to be attached to the cover with the provided hardware as shown in fig. 1 Fig 1 First, place a plate washer and then a spring washer on the screw as shown in fig.

  • Page 19: Media Options

    Media Options The BI-40-DEEP, BI-50-DEEP,BI-60-DEEP 2. Installing the fire glass media. Pour the is shipped with 3 large glass nuggets, clear fire glass media into the tray as shown and blue diamond shaped media and 11 below. Feel free to use any combination piece log set.

  • Page 20: Operation

    OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2.
  • Page 21 REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will beep once.

  • Page 22: Installing Wall Thermostat

    INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. Turn off circuit breaker. 2. Remove cover plate located on the left side of appliance. Pull the wire out and cut the inside thermostat.

  • Page 23: Replacement Parts

    REPLACEMENT PARTS This list contains replacement parts DESCRIPTION QTY. NO. BI-40-DEEP BI-50-DEEP BI-60-DEEP BI-72-DEEP BI-88-DEEP 602030C 602030C 602030C 602030C 602030C BLOWER AND HEATER ASSEMBLY FIREPLACE BOX 10104010 10104010 10104010 10104010 10104010 SWITCH 601032B 601032B 601032B 601032B 601032B CONTROL PANEL 601092C...

  • Page 24: Exploded View

    EXPLODED VIEW...

  • Page 25: Trouble Shooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow...

  • Page 26: Service History

    SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
