INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-DEEP
UNITS
BI-40-DEEP
BI-50-DEEP
BI-60-DEEP
BI-72-DEEP
BI-88-DEEP
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Related Manuals for Amantii BI-40-DEEP
Summary of Contents for Amantii BI-40-DEEP
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-DEEP UNITS BI-40-DEEP BI-50-DEEP BI-60-DEEP BI-72-DEEP BI-88-DEEP SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS............................3 PLUG INSTALLATION INSTRUCTIONS......................... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Please read the following instructions carefully before using the appliance. Caution - Fire, electric shock, physical injury and material damage hazards: To use the appliance, always follow the instructions for assembly, use and maintenance as well as usage cautions: 1. - Page 4 the room on their own, unless constant supervision is provided. 22. If the glass is damaged, do not use the heater in order to avoid a hazard. 23. Children of less than 3 years should be kept away from unless continuously supervised. 24.
- Page 5 Cautions ·Always install the heater in accordance with this guide. If in doubt obtain expert advice. ·Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. ·Always disconnect the heater from the electrical supply before Do’s moving it, or carrying out cleaning, maintenance.
-
Page 6: Plug Installation Instructions
PLUG INSTALLATION Your power cord will come separate from the unit, please locate it when unpacking your fireplace. The plug contained inside the box is predetermined at the factory and according to orders placed by authorized dealers. Available are UK, European & Swiss plugs. Should you require any of these options please contact your dealer for purchase. -
Page 7: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 240 Volt grounded outlet. LOCATING THE FIREPLACE Plan where to locate and frame the fireplace. -
Page 8: Bi-40-Deep
BI-40-DEEP Description Built-in Appliance Voltage 240V AC 50-60Hz Watts 1900W Max NO HEATER MOTOR HEATER Appliance Width 38 5/8” or 98.1 cm Appliance Height 23 5/8” or 60 cm Appliance Depth 12 1/4” or 31.2 cm Gross Weight 94.6lbs or 43kg... -
Page 9: Bi-50-Deep
BI-50-DEEP Model Number BI-50-DEEP Voltage 240V AC 50-60Hz Watts 1900W Max NO HEATER MOTOR HEATER Appliance Width 48 5/8” or 123.5 cm Appliance Height 23 5/8” or 60 cm Appliance Depth 12 1/4” or 31.2 cm Gross Weight 110lbs or 50kg Plug Location Left side Cord Length... -
Page 10: Bi-60-Deep
BI-60-DEEP Description Built-in Appliance Voltage 240V AC 50-60Hz Watts 1900W Max NO HEATER MOTOR HEATER Appliance Width 58 5/8” or 148.5 cm Appliance Height 23 5/8” or 60 cm Appliance Depth 12 1/4” or 31.2 cm Gross Weight 127.6lbs or 58kg Plug Location Left side Cord Length... -
Page 11: Bi-72-Deep
BI-72-DEEP Description Built-in Appliance Voltage 240V AC 50-60Hz Watts 1900W Max NO HEATER MOTOR HEATER Appliance Width 72 1/8” or 183.2 cm Appliance Height 23 5/8” or 60 cm Appliance Depth 12 1/4” or 31.2 cm Gross Weight 156.2lbs or 71kg Plug Location Left side Cord Length... -
Page 12: Bi-88-Deep
BI-88-DEEP Description Built-in Appliance Voltage 240V AC 50-60Hz Watts 1900W Max NO HEATER MOTOR HEATER Appliance Width 88 5/8” or 225.2 cm Appliance Height 23 5/8” or 60 cm Appliance Depth 12 1/4” or 31.2 cm Gross Weight 195.8lbs or 89kg Plug Location Left side Cord Length... -
Page 13: Safety Drill Screw Area
SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) T h e m a n u a l c o n tro l p a d p o s itio n... -
Page 14: Installation
Note: The optional trim can be pulled out directly from the unit. It will need two people to do it. The rough wall opening size of the fireplace: W(＂) D(＂) H(＂) BI-40-DEEP BI-50-DEEP BI-60-DEEP BI-72-DEEP 73 1/2 BI-88-DEEP 89 1/4 1. - Page 15 2. Remove the framing plates from the unit framing plate 3. Re-fix the framing plates to the unit as the picture shows framing plate...
- Page 16 4. Bend up the framing plates. 5. Put the unit into the opening.
- Page 17 6. Drive the mounting screws into the framing plates on the unit and the wall studs. framing plate 7. After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install plywood or drywall. NOTE: In order to use the supplied trim kit, the thickness of the desired wall finish can not exceed 1 inch.
- Page 18 8. Decorate the plywood or drywall with glazed tile, wallpaper, etc. Fireplace 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...
-
Page 19: Media Options
Media Options The BI-40-DEEP, BI-50-DEEP,BI-60-DEEP 2. Installing the fire glass media. Pour the is shipped with 3 large glass nuggets, clear fire glass media into the tray as shown and blue diamond shaped media and 11 below. Feel free to use any combination piece log set. -
Page 20: Operation
OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1、 Press key . Press for the first time，heater work at 1900W, indicator lights red. -
Page 21: Remote Control Operation
REMOTE CONTROL OPERATION Press the remote control’s key“ ”, its screen turns on, the flame ignites and the flame icon appears on 、 the LCD screen of the remote control. Week, time (24h system), and temperature setting are displayed normally. Press it again, the screen of the remote control will turn off; Key“... - Page 22 7、 Press the heating key“ .” Press for the first time ,the heating elements work at 1900W, the LCD screen displays , the indicator on the machine lights red. Press a second time , the heating elements work at 950W, the LCD screen displays , the indicator on the machine lights blue.
- Page 23 for Tuesday. Press for the 7th time and it displays . Press for the 8th time and it exits and recovers to the current week day; 11、Press“ .” Press for the first time and the timing function turns on, the LCD screen displays the machine’s indicator lights green.
-
Page 24: Care And Maintenance
CARE AND MAINTENANCE 1. Switch off and unplug from the power supply before cleaning. 2. Using a soft, moist cloth, with or without a mild soap solution, carefully clean the exterior surface of the products. CAUTION: Allow the product to completely cool before handling or cleaning it. 3. -
Page 25: Replacement Parts
REPLACEMENT PARTS This list contains replacement parts DESCRIPTION QTY. NO. BI-40-DEEP BI-50-DEEP BI-60-DEEP BI-72-DEEP BI-88-DEEP 602032B 602032B 602032B 602032B 602032B BLOWER AND HEATER ASSEMBLY FIREPLACE BOX 10104010 10104010 10104010 10104010 10104010 SWITCH 601035 CONTROL PANEL 601095F CIRCUIT BOARD 10101221C 10101221C... -
Page 26: Exploded View
EXPLODED VIEW... -
Page 27: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow... -
Page 28: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
