Replacing the Belts and Brush Rolls

Scan the QR code for a how-to video.
1. Unplug machine and remove 2. Remove belt cover. Use
both tanks. While reclined, lay Phillips-head screwdriver to
machine on its front. remove three screws.
5. If brush roll belts or brush
4. If flat belt is broken, place
a new belt around red pulley. roll assembly is broken, replace
Stretch belt toward back of with new brush roll assembly.
machine and around metal
shaft.

Troubleshooting

Visit support.BISSELL.ca or scan the QR code with your
smartphone camera for troubleshooting.
Note: Any other servicing should be performed by an authorized
service representative.

Warranty

Limited 5-year warranty. Visit support.BISSELL.ca or call 1-800-263-2535 for complete warranty
information.
WARNING
To reduce the risk of injury, do not touch the steam cleaning nozzle or adjacent surfaces when
steam-cleaning or when the nozzle is heated.
3. Use Phillips-head screwdriver
to remove two screws. Then
remove brush roll assembly by
unhooking belt.
6. Reinstall brush roll
assembly, making sure to loop
belt over the shaft. Reinstall
belt cover.
BISSELL.ca 11
