REVOLUTION® HYDROSTEAM™
UPRIGHT CARPET CLEANER WITH STEAM
3423 SERIES
What's in the Box? ............................................ 3
Assembly .............................................................. 3
Controls and Cleaning Modes ...................... 3
Filling the Clean Water Tank......................... 4
Three Modes of Cleaning ............................... 5
Cleaning with the Hose and Tool ................ 7
After-Cleaning Care ......................................... 8
Replacing the Belts and Brush Rolls .........11
Troubleshooting .................................................11
Warranty ...............................................................11
Product Overview
1. Handle with Fingertip
Controls
2. Clean Water Tank
Carry Handle
3. Clean Water Tank
4. Dirty Water Tank
Carry Handle
5. Machine Carry Handle
6. Dirty Water Tank
7. Mode Indicator Lights
8. Accessory Hose Door
9. HydroSteam Bar
10. EdgeSweep® Brushes
11. Formula & Steam
Spray Trigger
12. Quick Release™
Cord Wrap
13. Recline Pedal
Meet your new BISSELL product!
Go to support.BISSELL.com for a comprehensive walkthrough
of your new purchase, including videos, tips, support, and more.
Want to get started right away? This guide has all the information
you need to set up your new product. Let's take a look...
1
2
3
4
5
6
7
8
9
10
11
12
13
Advertisement
Table of Contents
Related Manuals for Bissell REVOLUTION HYDROSTEAM 3423 Series
Summary of Contents for Bissell REVOLUTION HYDROSTEAM 3423 Series
- Page 1 6. Dirty Water Tank 7. Mode Indicator Lights Meet your new BISSELL product! Go to support.BISSELL.com for a comprehensive walkthrough of your new purchase, including videos, tips, support, and more. Want to get started right away? This guide has all the information...
-
Page 2: Important Safety Instructions
• With brush roll on, do not allow cleaner to sit in one location for an extended period of time, as damage to floor can result. 2 BISSELL.com... -
Page 3: What's In The Box
Trial Formula Clean Water Tank Dirty Water Tank (vary by model) Assembly Go to support.BISSELL.com for assembly videos. 1. Remove clean tank from 2. Insert handle into machine 3. Insert clean tank into upper body. Ensure upper until it clicks into place. -
Page 4: Filling The Clean Water Tank
PRO OXY Urine Eliminator, Oxy Boost, Pet Oxy Boost, Simply Carpet Deep Clean, Clean + Allergen, Pro Oxy Deep Clean WARNING To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL cleaning formula intended for use with this machine. 4 BISSELL.com... - Page 5 Three Modes of Cleaning Visit support.BISSELL.com for how-to videos. Startup • This appliance is primarily a carpet cleaner with a steam-cleaning feature. • Remove any solids and use a dry vacuum cleaner over area before using your deep cleaner. • To prevent damage to Berber carpets, avoid repeated strokes in the same area. Before cleaning area rugs, check the manufacturer’s tag and test an inconspicuous spot on the rug for...
- Page 6 “dry passes” by pushing foot. to dispense water and formula. machine forward and back While holding trigger, make across carpet until water can two “wet passes,” moving the no longer be seen in nozzle. machine forward and back across carpet. 6 BISSELL.com...
-
Page 7: Attaching The Hose
ON. Cleaning the 2-in-1 Upholstery Tool 1. Twist dirt cup to open. 2. Rinse dirt bin. Let dry Empty into a garbage bin. completely before reinstalling. CONTINUED ON NEXT PAGE BISSELL.com 7... -
Page 8: Emptying The Dirty Water Tank
After-Cleaning Care For more helpful maintenance tips, check out support.BISSELL.com. Emptying the Dirty Water Tank Note: When the tank is full, the float will shut off suction and emit a high-pitched sound indicating it is time to empty your tank. -
Page 9: Cleaning The Machine
CONTINUED ON NEXT PAGE two clicks. WARNING To reduce the risk of injury, do not touch the steam cleaning nozzle or adjacent surfaces when steam-cleaning or when the nozzle is heated. BISSELL.com 9... - Page 10 Once your cleaning is complete, make sure both the dirty and clean water tanks are emptied, rinsed out, and dried before the next use. Wrap cord around cord wrap for storage. Store machine in a protected, dry area. 10 BISSELL.com...
-
Page 11: Troubleshooting
Note: Any other servicing should be performed by an authorized service representative. Warranty Limited 5-year warranty, may vary by state. Visit support.BISSELL.com or call 1-800-237-7691 for complete warranty information. WARNING To reduce the risk of injury, do not touch the steam cleaning nozzle or adjacent surfaces when steam-cleaning or when the nozzle is heated. - Page 12 We’re Waggin’ Our Tails! BISSELL proudly supports BISSELL Pet Foundation® and its mission to help save homeless pets. When you buy a BISSELL® product, you help save pets, too. We’re proud to design products that help make pet messes, odors, and pet homelessness disappear.
Need help?
Do you have a question about the REVOLUTION HYDROSTEAM 3423 Series and is the answer not in the manual?
Questions and answers
Spray hose not spraying solution
The spray hose on the Bissell REVOLUTION HYDROSTEAM 3423 Series may not be spraying solution due to several possible reasons:
1. Empty Clean Water Tank – Ensure the clean water tank has enough solution.
2. Clogged Hose or Nozzle – Check for blockages and rinse with warm water.
3. Unseated Tank – Make sure the clean water tank is properly installed.
4. Trigger Not Engaged – Ensure the spray trigger is being pressed correctly.
5. Air in the Hose – Prime the hose by holding the trigger until the solution flows.
If the issue persists, further troubleshooting may be needed.
This answer is automatically generated
Using Attachment with Trigger To Clean Steps
To clean steps with the attachment using the Bissell Revolution Hydrosteam 3423 Series:
1. Attach the Hose:
- Lift the accessory hose door on the front of the machine.
- Insert the hose until it clicks into place, ensuring the colored hose release clip faces outward.
2. Attach the Tool:
- Connect the desired cleaning tool (e.g., 2-in-1 Upholstery Tool or 3”/6” Tool) to the end of the hose.
3. Select Cleaning Mode:
- If using the 2-in-1 Upholstery Tool, switch between Wet and Dry Cleaning modes as needed.
4. Apply Cleaning Solution:
- Point the tool above the stain and press the spray trigger to dispense water and formula.
5. Scrub and Extract:
- Gently scrub the stain with the tool.
- Release the trigger and suction up the stain by moving the tool over the cleaned area.
6. After Cleaning Care:
- Empty and rinse the tool’s dirt bin if applicable.
- Allow it to dry completely before reinstalling.
Note: The hose and tool use only water and formula, not steam.
This answer is automatically generated
