SIIG CyberPro PCI 1S Quick Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Introducing the CyberPro PCI 1S I/O
The CyberPro PCI 1S high-speed serial I/O card provides
one additional 9-pin serial port. Depending on the
model purchased, this board will fit into either a Full or
Low Profile chassis.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Full support for Windows-based software
•
Reduces CPU load and improves system
performance dramatically
•
IRQ sharing feature reduces IRQ conflicts
•
High-speed serial port (9-pin) works with 56K V.90
external modems, ISDN terminal adapters, PDAs,
digital cameras, label printers and other serial port
devices
•
Built-in FIFO buffers dramatically increase data
transmit/receive speed, especially under Windows'
multitasking environment
•
Each serial port can be configured for either 5V or
12V output, for serial devices that require power
System Requirements
•
Pentium or equivalent computer with an available
PCI slot
•
Windows 95/98/98SE/ME/NT 4.0/2000/XP/
Server 2003
04-0340B
CyberPro PCI 1S
Quick Installation Guide
1

Advertisement

loading

Related Manuals for SIIG CyberPro PCI 1S

Summary of Contents for SIIG CyberPro PCI 1S

  • Page 1 CyberPro PCI 1S Quick Installation Guide Introducing the CyberPro PCI 1S I/O The CyberPro PCI 1S high-speed serial I/O card provides one additional 9-pin serial port. Depending on the model purchased, this board will fit into either a Full or Low Profile chassis.

  • Page 2: Package Contents

    Package Contents • CyberPro PCI 1S board • Driver CD • Low profile bracket (Dual Profile board only) • Quick installation guide Layout Full profile bracket Serial Port (9-pin) Figure 1. Layout Note: Depending on the model purchased, the bracket size will be either Full or Low-profile.

  • Page 3: Hardware Installation

    Hardware Installation General instructions for installing the card are provided below, since the design of computer cases and motherboards vary. Refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer’s case for a few seconds.

  • Page 4: Driver Installation

    Driver Installation This section provides information on how to install the CyberPro PCI 1S drivers. Windows 95 At the Update Device Driver Wizard, click Next. Insert the driver CD, and click Other Locations. Type in D:\9x, click OK, then Finish. (Change D: to match your CD-ROM drive letter) From the Insert Disk window, click OK.
  • Page 5 From the main desktop, double click My Computer, Control Panel, System, then click Device Manager. Double click Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed. Double click Multi-function adapters, SIIG CyberPro 1S PCI board and PCI Function should be displayed. Windows NT 4.0 From the desktop click Start, then Run.
  • Page 6 To Verify Windows NT 4.0 Installation Go to Start / Setting / Control Panel, double click Ports device icon. A new COM port will be assigned when successfully installed. Windows 2000 At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (recommended) and click Next.
  • Page 7 Right click My Computer, click Manage, then select Device Manager. Click on the + (plus sign) in front of Ports (Com & LPT), CyberSerial PCI 16Cxxx... should be displayed. Double click Multifunction adapters, SIIG CyberPro 1S PCI board should be displayed.
  • Page 8 Changing COM Port Address Some serial devices need a specific COM port in order to work. If your serial device works properly, do not change this setting. Windows 95/98/98SE/ME From the Device Manager window double click Ports(COM & LPT), then double click the CyberSerial PCI serial port you want to change.

  • Page 9: Technical Support And Warranty

    SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton. You are responsible for the cost of shipping the product to SIIG • at the following address: SIIG, Inc.
  • Page 10 Fremont, CA 94538-3152 CyberPro PCI 1S is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
