Introducing the Parallel PCI 1P
The Parallel PCI 1P high-speed parallel card provides one
additional parallel port to your system. Depending on
the model purchased, this board will fit into either Full or
Low Profile chassis.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Supports 32-/64-bit, 3.3V/5V PCI and PCI-X slots
•
Full support for Windows-based software
•
Reduces CPU load and improves system
performance dramatically
•
Supports EPP/ECP, BPP (bi-directional), SPP
(standard) parallel port modes
System Requirements
•
Pentium or equivalent computer with an available
32-/64-bit PCI or PCI-X slot
•
Windows
/64-bit)/Server 2003 (32-/64-bit)/Vista (32-/64-bit)
Package Contents
•
Parallel PCI 1P board
•
Low profile bracket (for Dual Profile PCI-1P only)
•
Driver CD
•
This quick installation guide
04-0358C
Parallel PCI 1P
Quick Installation Guide
95/98/98SE/ME/NT 4.0/2000/XP (32-
®
1
Advertisement
Related Manuals for SIIG JJ-P00112-S6
Summary of Contents for SIIG JJ-P00112-S6
- Page 1 Parallel PCI 1P Quick Installation Guide Introducing the Parallel PCI 1P The Parallel PCI 1P high-speed parallel card provides one additional parallel port to your system. Depending on the model purchased, this board will fit into either Full or Low Profile chassis. Features and Benefits •...
-
Page 2: Hardware Installation
Layout Depending on the model purchased, the bracket mounted on your board may vary from the image displayed. Full profile bracket Parallel Port Figure 1. Layout Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. -
Page 3: Driver Installation
Remove your computer’s cover. Remove the slot bracket from an available PCI slot. To install the card, carefully align the card's bus connector with the selected PCI slot on the motherboard. Push the board down firmly, but gently, until it is well seated. Replace the slot bracket holding screw to secure the card. - Page 4 From the main desktop, double click My Computer, Control Panel, System, then click Device Manager. Double click Ports (COM & LPT), ECP Printer Port... and SIIG CyberPro Parallel port should be displayed. Windows NT 4.0 From the desktop click Start, then Run.
- Page 5 Restart Windows to complete the installation. To Verify Windows 2000 Installation Right click My Computer, click Manage, then click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), SIIG CyberPro Parallel port... should be displayed.
- Page 6 Restart Windows to complete the installation. To Verify Windows XP/Server 2003 Installation Right click My Computer, click Manage, then click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), SIIG CyberPro Parallel port... should be displayed.
- Page 7 Click Next, then click Close to complete the installation. To Verify Windows Vista Installation Right click Computer, click Manage, click Continue, then click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), SIIG CyberPro Parallel port... should be displayed.
- Page 8 Blank Page...
- Page 9 Blank Page...
- Page 10 Blank Page...
-
Page 11: Technical Support And Warranty
Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. SIIG RMA department can also be reached at (510) 413-5333. - Page 12 6078 Stewart Avenue Fremont, CA 94538-3152, USA Parallel PCI 1P is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
