Introducing the Parallel PCI 1P
The Parallel PCI 1P high-speed parallel card provides one
additional parallel port to your system. Depending on
the model purchased, this board will fit into either Full or
Low Profile chassis.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Supports 32-/64-bit, 3.3V/5V PCI and PCI-X slots
•
Full support for Windows-based software
•
Reduces CPU load and improves system
performance dramatically
•
Supports EPP/ECP, BPP (bi-directional), SPP
(standard) parallel port modes
System Requirements
•
Pentium or equivalent computer with an available
32-/64-bit PCI or PCI-X slot
•
Windows
/64-bit)/Server 2003 (32-/64-bit)/Vista (32-/64-bit)
Package Contents
•
Parallel PCI 1P board
•
Low profile bracket (for Dual Profile PCI-1P only)
•
Driver CD
•
This quick installation guide
04-0358C
Parallel PCI 1P

Quick Installation Guide

95/98/98SE/ME/NT 4.0/2000/XP (32-
®
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 04-0358C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG 04-0358C

Summary of Contents for SIIG 04-0358C

  • Page 1: Quick Installation Guide

    32-/64-bit PCI or PCI-X slot • Windows 95/98/98SE/ME/NT 4.0/2000/XP (32- ® /64-bit)/Server 2003 (32-/64-bit)/Vista (32-/64-bit) Package Contents • Parallel PCI 1P board • Low profile bracket (for Dual Profile PCI-1P only) • Driver CD • This quick installation guide 04-0358C...

  • Page 2: Hardware Installation

    Layout Depending on the model purchased, the bracket mounted on your board may vary from the image displayed. Parallel Port Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed.

  • Page 3: Driver Installation

    Remove your computer’s cover. Remove the slot bracket from an available PCI slot. To install the card, carefully align the card's bus connector with the selected PCI slot on the motherboard. Push the board down firmly, but gently, until it is well seated. Replace the slot bracket holding screw to secure the card.
  • Page 4 Select Specify a location, uncheck the other boxes, insert the driver CD, type in D:\9x, then click Next. (Change D: to match your CD-ROM drive letter) Click Next, then Finish. If prompted, at the Insert Disk box click OK. Insert your Windows 98 Installation CD-ROM then click OK.
  • Page 5 At the Welcome window, click Next. Choose Install, then click Next. Click Yes, then click Exit. Click Yes to restart to complete the installation. To Verify Windows NT 4.0 Installation Click Start, Programs, Administrative Tools, then Windows NT Diagnostics. Click Resources tab, SIIGpar should be displayed. Windows 2000 At the Found New Hardware Wizard, click Next.
  • Page 6 32-bit Windows XP/Server 2003 At the Found New Hardware Wizard, insert the driver CD. For XP w/SP1 or earlier/ Server 2003: go to step #2. For XP w/SP2 or later/Server 2003 wSP1 or later: select No, not this time, click Next. Select Install the software automatically (Recommended, then click Next.
  • Page 7 Windows Vista ™ At the Found New Hardware window, insert the driver CD, click Locate and install driver software (recommended), then click Continue. Note: Windows Vista driver installation process may take several minutes to complete. Click Next, then click Close to complete the installation.
  • Page 8 Blank Page...
  • Page 9 Blank Page...
  • Page 10 Blank Page...

  • Page 11: Technical Support And Warranty

    Technical Support and Warranty QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at www.siig.com and click Support. Our online support database is updated daily with new drivers and solutions. Answers to your questions could be just a few clicks away. You can also submit questions online and a technical support analysts will promptly respond.
  • Page 12 About SIIG, Inc. Founded in 1985, SIIG, Inc. is a leading computer upgrade manufacturer of I/O connectivity products, including PCI & ISA serial and parallel ports, USB, Serial ATA & UltraATA controllers, FireWire (1394a/b), networking, sound cards, and other accessories. SIIG is the premier one-stop source of upgrades.
