Arm/Disarm it or receive system status information (see Chapter 7).
• Numerical keys serve as function keys: When the system is disarmed, the numerical keys are used also to
control various system functions. A simple icon on each key identifies the task of that key.
• Data retrieval: You can obtain status information, trouble information and review memorized alarm events
visually (see Chapter 5).
• Event log: System events are memorized in an event log that stores the most recent events, each tagged
with the time and date of the event. You can access this log and review the past events in case of need such
as after a burglary (see Chapter 10. Maintenance).
• Looking after elderly, physically handicapped and infirm individuals: The system can be programmed to
monitor people activity within the protected area and send out an alert message if no movement is detected in
the area for a predefined period of time (See Chapter 6. Menus and Functions).
• Distress calls: Keyfobs may be used to activate this function by the simultaneous pressing of two buttons.
• Disarming under duress: If a user is forcibly compelled to disarm the system, he can do so using a special
code ("Duress Code") that disarms the system as usual, but also sends a silent alarm to the monitoring station
(see Chapter 2. Operating the PowerMaster System).
• System supervision: All wireless peripherals within the protected site send periodic keep alive supervision
messages. If such a message is overdue, the PowerMaster displays a 'missing' trouble message. Your
installer can disable this feature if so desired.
• Battery supervision: The PowerMaster continuously monitors the battery condition of the sensors and
devices in the system and displays a 'Low Battery' message whenever a battery needs to be replaced within a
maximum of 30 days. Wireless sirens can still provide 2 siren alarms before the siren becomes totally inactive.
Note: When the 'Low Battery' message is received, the battery should be replaced within 7 days.
PowerMaster-10 G2 Panel Indicator and Controls
2 0
LED Indicators
No.
Indication
2
3
4
5
D-307502 PowerMaster-10/30 G2 User's Guide
Figure 1a. PowerMaster-10 G2 Controls and Indicators
Function
Power (Green): Indicates that your system is properly connected to the power outlet.
Arm (Red): Lights when the system is in the armed state.
Chime (Green): Chime zones will chime when disturbed (see Chapter 2).
Trouble (Orange): Lights when the system is in a state of trouble (see Chapter 5).
1
2
3
4
6
7
8
1 1
1 3
1 5
1 7
1 9
INTRODUCTION
5
9
1 0
1 2
1 4
1 6
1 8
5
