Single WDP-1 Pro
HTP (Highest Takes Precedence)
If the DMX input value is higher than the fader (03/10) value, then the DMX input will take precedence
over the fader input. Similarly, if the fader (03/10) value is higher than the DMX input value, then the fader
input will take precedence over the DMX input.
Installation
Remove all packing materials from the Single WDP-1 Pro. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Connection Example
Fig. 02
Ordercode: 50758
6
