Distech Controls ECB-VAV UUKL Installation Manual page 18

Device too far from the Wireless Receiver
Configuration problem
Flow sensor is not giving proper readings
Tubing connection problem
Controller is not calibrated properly
Damper is not opening or closing properly
Mechanical stops not in proper position
Controller in Override
Rx/Tx LEDs
RX LED not blinking
TX LED not blinking
Status LED– Normal Operation
One fast blink
Fast blink continuous:
(150ms On, 150ms Off, continuous)
The Status LED is always OFF
Status LED blink patterns – Repeats every 2 seconds (highest priority shown first)
Long Long Long blink
(800ms On, 300ms Off, 800ms On, 300ms Off,
800ms On)
Short Short Long blink
(150ms On, 300ms Off, 150ms On, 300ms Off,
800 ms On)
Short Long blink
(150ms On, 300ms Off)
For issues with the Allure EC-Smart-Vue Series Communicating Sensor, refer to the Allure EC-Smart-Vue Series Communicating Sensor Hardware In-
stallation Guide.
Images are simulated. While all efforts have been made to verify the accuracy of information in this manual, Distech Controls is not responsible for damages or claims arising from the use of this manual.
Persons using this manual are assumed to be trained HVAC specialist / installers and are responsible for using the correct wiring procedures and maintaining safe working conditions with fail-safe environ-
ments. Distech Controls reserves the right to change, delete or add to the information in this manual at any time without notice.
Distech Controls, the Distech Controls logo, Open-to-Wireless, Innovative Solutions for Greener Buildings, and Allure are trademarks of Distech Controls Inc. BACnet is a registered trademark of ASHRAE.
Global Head Office - 4205 place de Java, Brossard, QC, Canada, J4Y 0C4 - EU Head Office - ZAC de Sacuny, 558 avenue Marcel Mérieux, 69530 Brignais, France
18 / 18
Reposition the device to be within the range of the Wireless Receiver. For information on typical transmission ranges, refer
to the Open-to-Wireless Application Guide.
Using the device configuration plug-in or wizard, check the configuration of the input. Refer to the Wireless Battery-less
Sensors and Switches Solutions Guide for more information.
1. Ensure the tubing is installed properly and that the tubing is not bent.
2. Verify that the high and low pressure sensors are not inversed.
Recalibrate the controller. Refer to the controller's user guide for more information.
The two mechanical stops must be positioned to stop the damper motion when it is completely closed and completely
opened. The mechanical stops can be moved by increments of 5°.
Set the Override to OFF in the wizard.
Data is not being received from the BACnet MS/TP data bus.
Data is not being transmitted onto the BACnet MS/TP data bus.
Initialization: The device is starting up.
Firmware upgrade in progress. Controller operation is temporarily unavailable. The new firmware is being loaded into
memory. This takes a few seconds. Do not interrupt power to the device during this time.
The controller is operating normally.
The device has not received a BACnet token, and therefore cannot communicate on the network: Verify that the controller's
MAC Address is unique on the BACnet MS/TP Data Bus – see Device Addressing. Make sure the controller's BAUD rate is
the same as the BACnet MS/TP Data Bus' BAUD rate (see Setting the BAUD Rate (optional)). Verify that the Max Master is
set high enough to include this controller's MAC Address (See the Network Guide).
Poor-quality power; The device has browned-out: The voltage at the 24VAC and 24VCOM terminals has gone below the
device's acceptable limit during power up.
Invalid MAC address: The device's MAC address is set to zero (0) or is set to an address higher than the Max Master. See
the Network Guide, or for the ECB-VAV UUKL controller, refer to the Distech Controls UUKL Smoke Control System Design
Guide.
