Commissioning ECB-Series Controllers
When using an Allure EC-Smart-Vue Series Communicating Sensor for commissioning ECB Series controllers (the DIP switch located on the faceplate is
set to 0 (all off) and before code is downloaded to the controller EC-gfxProgram), connect the Allure EC-Smart-Vue Series Communicating Sensor to the
controller with its Subnet ID set to 1.
During commissioning, the sensor is used to set the controller's BACnet
pre-loaded programs that enable the ECB-VAV to control a typical VAV box.
Set the connected controller's MAC Address as follows:
Connect an Allure EC-Smart-Vue Series Communicating Sensor to the controller with a Cat 5e patch cable. Wait for the display to show the room tem-
perature.
1. Press and hold the Menu button
2. Use the down button to set the number to 9995 (this is the default password).
3. Press the Menu button
4. Press the down button
dress.
5. Use the up and down buttons
6. Press the Menu button
7. Press and hold the Menu button
Once the controller's network is operational, the controller can be programmed EC-gfxProgram. For each Allure EC-Smart-Vue Series Communicating
Sensor, set its Subnet ID number to the block number of its associated ComSensor block EC-gfxProgram. This is done in the sensor's GEN CFG menu
under SUBNET ID.
for 5 seconds to enter the password menu. 10000 is shown on the display.
to submit the password. Upon submitting the password, the GEN CFG menu appears on the display.
once to enter the GEN CFG submenu. The MAC ADDRESS menu is shown with the current controller's BACnet MAC Ad-
to set the controller's MAC Address. Only addresses from 1 to 127 are recommended to be used.
once to apply the value.
for 5 seconds to exit the configuration menu.
®
MAC Address and to perform application selection if needed. Applications are
Screen Timeout: 15 seconds
OR
Screen Timeout: 15 seconds
OR
Screen Timeout: 30 seconds
OR
Screen Timeout: 30 seconds
OR
