USER MANUAL
IPM-SHUTTER10 Shutter Assembly for IPM-10KW
For usage in a dirty industrial environment, the IPM-10KW
can be fitted with an automated dust tight shutter assembly to
protect the unit from dust and debris. The shutter unit has a
built-in scatter shield and includes a field replaceable
antireflection coated protective window.
• Built-in scatter shield
• Antireflective coated window
• Motorized dust-resistant shutter
• IP62 rated
Model
IPM-SHUTTER10
Use Provides IP62 in industrial environment
Control Via host IPM-10KW unit
Aperture mm Ø45mm
Backscattered
~1%
(b)
Power
Weight kg 2
Connection to IPM-10KW unit – D9
Connectors
Name
Part Numbers
IPM-SHUTTER10
and Optional
IPM-SHUTTER10 Window
Accessories
replacement kit
Name
IPM-10KW
Related
IPM-COM-Profinet
Products
IPM-COM-
EtherNet/IP-M
When working at 10.6µm (CO2), the window should be removed.
Notes: (a)
Using built in scatter shield, use the NIRS or CO2S setting to compensate for slightly higher reading.
Notes: (b)
IPM-SHUTTER10
8 | IPM USER MANUAL
(a)
Description
Combined protective shutter. Includes built in scatter shield
Replacement anti reflective coated window
Description
IPM industrial laser power sensor
Profinet communications adapter with AIDA connectors
EtherNet/IP communications adapter with M connectors
7Z07106 - REV 2 - 25/OCT/2022
P/N
7Z08409
7Z08411
P/N
7Z07106
7Z08404
7Z08405
