3-2. SYSTEM CONTROLLER SYSTEM ADJUSTMENTS

1. Initializing the Page D Data

Note: If the page D data is initialized, the following adjustments
must be performed again.
"LCD System Adjustments", "Color Electronic View finder
System Adjustments", "Battery Down Adjustment", and
"Base Band Block Adjustment" and "Clock Adjustment" of
the "Video System Adjustment".
Adjustment Page D
Adjustment Address 10 to DB
Initializing Method:
1) Set data: 01 to page: 0, address: 01.
2) Set data: 2D to page: 2, address: 00, and press the PAUSE button
of the adjusting remote commander.
3) Set data: 2D to page: 2, address: 01, and press the PAUSE button
of the adjusting remote commander.
4) Check that the data of page: 2, address: 02 is "01".
5) Perform "Changing the Page D Data".

2. Changing the Page D Data

If the page D data has been initialized, change the data as shown in
the following table by manual input.
Note 1: Before changing the data, set data: 01 to page: 0, address:
01.
Note 2: When changing the data, press the PAUSE button of the
adjusting remote commander each time when setting new
data, since the data is written in the non-volatile memory.
Note 3: After changing the data, set data: 00 to page: 0, address:
01.
Note 4: No mark : Common
( ): AEP/UK model
[ ]: E/Tourist model
Address
13
14
15
1A
1E
20
21
23
24
26
27
2F
30
38
3E
49
4A
4B
5B
60
61
62
63
64
65
66
67
68
6A
6B
6C
6D
6E
6F
70
71
72
5–42
Data
NTSC PAL
02 04
(56)[57]
(01)[03]
73 73
39 39
39 39
C0 (20)[CO]
7E
0B
0D
5A
00 00
04 04
C9
C9
06 06
2A 2A
83 83
D6 D6
79 79
00
72 72
70 70
9D 9D
CB B5
97 97
82 82
80 80
8D
A3
78 78
BF BF
7C 7C
61
61
33 33
65 65
70 70
60 60
A1 A1
