Rear-panel signal connections

Use the signal connectors on the module's rear panel to connect the module to
other HPLC system components. The following table summarizes these signal
connections.
Component connector types
Connector type
Ethernet
IEEE-488
Analog Event inputs/outputs
terminal strips
Pump (A, B, and C)
RS-232
The following figure shows the rear panel locations of the signal connectors
used to operate the module with external devices.
Component
Waters data control system, such as an
Empower 2 system, connected via the
Ethernet network
The Ethernet port also supports the
Tip:
Waters PC-based Autoloader utility for
installing firmware (for details, see the
Waters Pump Control Module II release
notes).
Waters data control system, such as
Empower, Millennium
system connected via the IEEE-488 bus
Peripheral devices, such as column
select valves, column-switching valves,
and manual injectors
Up to three, Waters 510 or 515 HPLC
Pumps
For firmware upgrades only
Rear-panel signal connections
32
, or MassLynx
2-3
