Waters Pump Control Module II Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Waters Pump Control
Module II
Installation Guide
71500078604/Revision B
Copyright © Waters Corporation 2009
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pump Control Module II and is the answer not in the manual?

Questions and answers

Related Manuals for Waters Pump Control Module II

Summary of Contents for Waters Pump Control Module II

  • Page 1 Waters Pump Control Module II Installation Guide 71500078604/Revision B Copyright © Waters Corporation 2009 All rights reserved...

  • Page 2: Copyright Notice

    Corporation assumes no responsibility for any errors that may appear in this document. This document is believed to be complete and accurate at the time of publication. In no event shall Waters Corporation be liable for incidental or consequential damages in connection with, or arising from, its use.

  • Page 3: Customer Comments

    Customer comments Waters’ Technical Communications department invites you to tell us of any errors you encounter in this document or to suggest ideas for otherwise improving it. Please help us better understand what you expect from our documentation so that we can continuously improve its accuracy and usability.

  • Page 4: Contacting Waters

    Contacting Waters ® Contact Waters with enhancement requests or technical questions regarding the use, transportation, removal, or disposal of any Waters product. You can reach us via the Internet, telephone, or conventional mail. Waters contact information Contacting medium Information Internet The Waters Web site includes contact information for Waters locations worldwide.

  • Page 5: Safety Advisories

    Waters data control system. Intended use of the Pump Control Module II Waters designed the Pump Control Module II to provide programmable control through a Waters data system of up to three, 500-series high-pressure pumps. Calibrating To calibrate LC systems, follow acceptable calibration methods using at least five standards to generate a standard curve.

  • Page 6: Quality-Control

    To calibrate mass spectrometers, consult the calibration section for the operator’s guide of the instrument you are calibrating. Quality-control Routinely run three QC samples that represent subnormal, normal, and above-normal levels of a compound. Ensure that QC sample results fall within an acceptable range, and evaluate precision from day to day and run to run.

  • Page 7: Table Of Contents

    Customer comments .................... iii Contacting Waters ....................iv Safety considerations ..................iv Safety advisories ....................v Operating the Waters Pump Control Module II ......... i-v Applicable symbols ....................v Audience and purpose..................v Intended use of the Pump Control Module II............. v Calibrating ......................
  • Page 8 Task-specific hazard warnings................ A-2 Warnings that apply to particular instruments, instrument components, and sample types....................A-3 Caution symbol ....................A-5 Warnings that apply to all Waters instruments ......... A-5 Electrical and handling symbols ..............A-12 Electrical symbols ..................A-12 Handling symbols ..................A-13 B Specifications ..................

  • Page 9: Overview

    Overview Contents Topic Page Introduction System configurations Signal conditions...

  • Page 10: Introduction

    Pump Control Module II Depending on your pump configuration requirements, you can attach as many as three Waters 510 or 515 HPLC Pumps to the module and regulate the solvent composition and flow rates by programming instrument method settings in Empower, Millennium, or MassLynx data control software. (For the module’s firmware/software requirements, see the Waters Pump Control...

  • Page 11: System Configurations

    When the module is under data system control, it can operate in one of these configurations: • Where all system modules, including the Pump Control Module II, communicate with the data system via an IEEE-488 bus interface • Where all system modules, including the Pump Control Module II, communicate with the data system via Ethernet communications You cannot use the module’s Ethernet port at the same time you...

  • Page 12: Ieee-488 Configuration

    Pump (6 available) IEEE-488 configuration To communicate with the Waters data control system via IEEE-488, an IEEE-488 cable connects the module to an IEEE-488 controller (a busLAC/E™ card in the data control system for Millennium or Empower software or an NI IEEE-488 card for MassLynx software).

  • Page 13: Signal Conditions

    HPLC system configuration using IEEE-488 communications busLAC/E card IEEE-488 cable Data control system External event-in (Inj or Stop Flow) Pump Control Event cables Module II Module-to-pump cable External event-out Pump Pump Pump (6 available) Signal conditions Terminal strips for two event input (inject-start and stop-flow) and six event output signal connections are located on the module’s rear panel (see “Terminal strips”...
  • Page 14 Overview...
  • Page 15 Installing the Pump Control Module II Contents Topic Page Selecting the site and unpacking Rear-panel signal connections Powering-on the module 2-12 Programming the module 2-14 Maintenance and troubleshooting 2-14 To avoid damaging the module and voiding its warranty, Caution: perform all procedures in the order specified in this guide before you power-on the module (see “Powering-on the module”...

  • Page 16: Selecting The Site And Unpacking

    Unpacking and inspecting the module Unpack the shipment, comparing all items received to those specified in the packing list. Notify Waters immediately if you discover a discrepancy. In the case of damages items, immediately notify the shipping agency and Waters Technical Service.

  • Page 17: Rear-Panel Signal Connections

    Pump (A, B, and C) Up to three, Waters 510 or 515 HPLC Pumps RS-232 For firmware upgrades only The following figure shows the rear panel locations of the signal connectors used to operate the module with external devices.

  • Page 18: Ethernet Signal Cable Connections

    The module is equipped with a RJ-45 connector for Ethernet port communications (see the figure, above). The Ethernet port—a 10/100 Base-T networking interface—is used only for remote control, the case when Empower 2 controls its operation, and for firmware upgrades via the Waters Autoloader utility. Appendix C lists the supplied Ethernet cable.

  • Page 19: Ieee-488 Signal Cable Connections

    Appendix C lists the IEEE-488 cables. Requirements: • In an IEEE-488 configuration, all of the Waters HPLC system components, including the module, must communicate with the data system via IEEE-488 communications. • When using an autoinjector, triggering of the inject-start signal occurs over the IEEE-488 cable, so no external I/O cable is needed.
  • Page 20 These settings have a value of 0 IEEE address Add 1 + 2 + 4 = 7 The following table shows the switch positions for addresses 2 to 29. IEEE-488 switch settings IEEE-488 Switch settings address Installing the Pump Control Module II...

  • Page 21: Connecting The Pumps

    IEEE-488 switch settings (Continued) IEEE-488 Switch settings address Connecting the pumps Caution: To avoid damaging the module’s electronic components, power-off the pumps before connecting cables to—or disconnecting them from—the module. To connect the pumps Connect one end of the module-to-pump cable to one of the three pump connectors on the rear of the module (see the figure on page 2-4).

  • Page 22: Connecting The Event Cables

    Requirement: ensure that the pump is in remote mode, and then press Run/Stop on the pump display to activate Run-Rem mode (see the Waters 515 HPLC Pump Operator’s Guide for additional information). Repeat steps 1 and 2 for each pump.
  • Page 23 Left terminal strip positions (Continued) Left connector Description I/O type SW 3 (two) Relay 3 Ground INJECT START Active Low Input Ground Right terminal strip positions Right connector Description I/O type SW 4 (two) Relay 4 SW 5 (two) Relay 5 SW 6 (two) Relay 6 Ground...
  • Page 24 STOP FLOW and GND connections on the right-hand terminal strip. Connect the red and black cables to carry positive and negative signals, respectively. A contact closure signals the module to stop the flow. 2-10 Installing the Pump Control Module II...
  • Page 25 Removable event-terminal strips Event-out connections You can trigger as many as six external devices. For each device, connect a shielded event cable to the SW 1 through SW 6 event-out connections on the terminal strips. Program the event-out signals using the instrument method editor for the module in your MassLynx, Empower, or Millennium software (see “Programming the module”...

  • Page 26: Powering-On The Module

    Power-on the pumps and any devices connected to the external event terminals. Tip: Refer to each device’s installation guide for powering-on procedures. Power-on the module by pressing 1 on the power switch located on the front panel. Power-on the data control system. 2-12 Installing the Pump Control Module II...
  • Page 27 3 4 5 OK LED RUN LED Waters Pump Control Module II Power switch Two LED (light-emitting diode) indicators on the front panel flash as the module performs a series of diagnostic self-tests. When the OK LED remains lit, the initialization sequence is successful.

  • Page 28: Programming The Module

    Use a small screwdriver to remove the fuse holder from its socket in the rear panel. Remove the faulty fuse from the fuse holder. Install a new, F 3.15-A fuse in the fuse holder (see Appendix Refit the fuse holder into its socket. 2-14 Installing the Pump Control Module II...

  • Page 29: Troubleshooting

    LED inspect all cable and is faulty. power connections, and then restart the module. If the previous behavior persists, contact Waters Service. The RUN LED does not The LED is faulty. Power-off the module, light during an injection...
  • Page 30 2-16 Installing the Pump Control Module II...
  • Page 31 Safety Advisories Waters instruments display hazard symbols designed to alert you to the hidden dangers of operating and maintaining the instruments. Their corresponding user guides also include the hazard symbols, with accompanying text statements describing the hazards and telling you how to avoid them.

  • Page 32: A Safety Advisories

    Heed all warnings when you install, repair, and operate Waters instruments. Waters assumes no liability for the failure of those who install, repair, or operate its instruments to comply with any safety precaution.

  • Page 33: Warnings That Apply To Particular Instruments, Instrument Components, And Sample Types

    The following warnings can appear in the user manuals of particular instruments and on labels affixed to them or their component parts. Burst warning This warning applies to Waters instruments fitted with nonmetallic tubing. Warning: Pressurized nonmetallic, or polymer, tubing can burst.
  • Page 34 Standby mode before touching areas marked with this high voltage warning symbol. Biohazard warning This warning applies to Waters instruments that can be used to process material that might contain biohazards: substances that contain biological agents capable of producing harmful effects in humans.

  • Page 35: Caution Symbol

    Chemical hazard warning This warning applies to Waters instruments that can process corrosive, toxic, flammable, or other types of hazardous material. Warning: Waters instruments can be used to analyze or process potentially hazardous substances. To avoid injury with any of these materials, familiarize yourself with the materials and their hazards, observe Good Laboratory Practices (GLP), and consult your organization’s safety...
  • Page 36 Attention: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Important: Toute modification sur cette unité n’ayant pas été expressément approuvée par l’autorité responsable de la conformité à la réglementation peut annuler le droit de l’utilisateur à...
  • Page 37 • Keine Schläuche verwenden, die stark geknickt oder überbeansprucht sind. • Nichtmetallische Schläuche nicht für Tetrahydrofuran (THF) oder konzentrierte Salpeter- oder Schwefelsäure verwenden. • Durch Methylenchlorid und Dimethylsulfoxid können nichtmetallische Schläuche quellen; dadurch wird der Berstdruck des Schlauches erheblich reduziert. Warnings that apply to all Waters instruments...
  • Page 38 Attenzione: fare attenzione quando si utilizzano tubi in materiale polimerico sotto pressione: • Indossare sempre occhiali da lavoro protettivi nei pressi di tubi di polimero pressurizzati. • Spegnere tutte le fiamme vive nell'ambiente circostante. • Non utilizzare tubi eccessivamente logorati o piegati. •...
  • Page 39 농축 질산 또는 황산과 함께 사용하지 마십시오. 염화 메틸렌(Methylene chloride) 및 디메틸술폭시드(Dimethyl sulfoxide)는 비금속 튜브를 부풀려 튜브의 파열 압력을 크게 감소시킬 수 있으므로 유의하십시오. 警告：圧力のかかったポリマーチューブを扱うときは、注意してください。 • 加圧されたポリマーチューブの付近では、必ず保護メガネを着用してください。 • 近くにある火を消してください。 • 著しく変形した、または折れ曲がったチューブは使用しないでください。 • 非金属チューブには、テトラヒドロフラン(THF)や高濃度の硝酸または硫酸などを 流さないでください。 塩化メチレンやジメチルスルホキシドは、非金属チューブの膨張を引き起こす場合が あり、その場合、チューブは極めて低い圧力で破裂します。 Warnings that apply to all Waters instruments...
  • Page 40 Warning: The user shall be made aware that if the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. Attention: L’utilisateur doit être informé que si le matériel est utilisé d’une façon non spécifiée par le fabricant, la protection assurée par le matériel risque d’être défectueuses.
  • Page 41 警告 ： 為了避免火災， 更換保險絲時， 請使用與儀器保險絲蓋旁面板上所印刷 之相同類型與規格的保險絲。 警告 ：为了避免火灾，应更换与仪器保险丝盖旁边面板上印刷的类型和规 格相同的保险丝。 경고: 화재의 위험을 막으려면 기기 퓨즈 커버에 가까운 패널에 인쇄된 것과 동일한 타입 및 정격의 제품으로 퓨즈를 교체하십시오. 警告： 火災予防のために、ヒューズ交換では機器ヒューズカバー脇のパ ネルに記載されているタイプおよび定格のヒューズをご使用ください。 Warnings that apply to all Waters instruments A-11...

  • Page 42: Electrical And Handling Symbols

    Electrical and handling symbols Electrical symbols These can appear in instrument user manuals and on the instrument’s front or rear panels. Electrical power on Electrical power off Standby Direct current Alternating current Protective conductor terminal Frame, or chassis, terminal Fuse Recycle symbol: Do not dispose in municipal waste.

  • Page 43: Handling Symbols

    Handling symbols These handling symbols and their associated text can appear on labels affixed to the outer packaging of Waters instrument and component shipments. Keep upright! Keep dry! Fragile! Use no hooks! Electrical and handling symbols A-13...
  • Page 44 A-14 Safety Advisories...
  • Page 45 Specifications Contents Topic Page Physical and environmental specifications Accuracy and precision Electrical specifications AC-to-DC power specifications...

  • Page 46: Physical And Environmental Specifications

    −10 to 0 VDC, representing a pressure range from 0 to Input range 41365 kPa (413.7 bar, 6000 psi) Pressure update 10 kHz rate Note: Flow precision and accuracy is determined by the type of pumps that the module controls (Waters 510 or 515 HPLC pumps). Specifications...

  • Page 47: Electrical Specifications

    Electrical specifications Protection Class 1 Protection Class 1 is the insulating scheme used in the module to protect from electrical shock. Class I identifies a single level of insulation between live parts (wires) and exposed conductive parts (metal panels) in which the exposed conductive parts are connected to a grounding system.

  • Page 48: Ac-To-Dc Power Specifications

    Electrical specifications (Continued) Item Specification Line voltage 85 to 264 VAC Frequency 47 to 63 Hz Analog-to-Digital converter Parameter Allowed values Input VA rating 60 VA Fuse rating F 3.15 A / 250 V ADC input range 0 to 4.95 V, 0 to 45505 kPa (455 bar, 6600 psi) ADC transfer 10 kHz function...

  • Page 49: C Spare Parts

    Spare Parts Spare parts in the following table constitute only those parts replaceable by the user. Parts not listed require replacement by a Waters field service representative. Pump Control Module II spare parts Item Part number Pump Control Module II with Startup kit...
