System configurations

When the module is under data system control, it can operate in one of these
configurations:
• Where all system modules, including the Pump Control Module II,
communicate with the data system via an IEEE-488 bus interface
• Where all system modules, including the Pump Control Module II,
communicate with the data system via Ethernet communications
Restriction:
are using its IEEE-488 bus interface for communications.
For details on the module's software and firmware requirements, see
Note:
the Waters Pump Control Module II release notes.

Ethernet configuration

To communicate with the Waters data control system via Ethernet, an
Ethernet cable connects the module with the system's Ethernet network in
one of two ways:
• Directly, through the Ethernet LAN card in the data control system
• Through a network switch
For more information, see
You cannot use the module's Ethernet port at the same time you
"Ethernet signal cable connections" on page
System configurations
2-4.
