Page 1 DEEP SEA ELECTRONICS DSE8610 MKII Operator Manual Document Number: 057-254 Author: Ashley Senior 057-254 ISSUE: 10...
Page 2 Deep Sea Electronics Ltd. Any reference to trademarked product names used within this publication is owned by their respective companies. Deep Sea Electronics Ltd. reserves the right to change the contents of this document without prior notice. Amendments Since Last Publication Amd.
Page 3 DSE8610 MKII Operator Manual Amendments List Continued Amd. No. Comments Corrected imperial distances. Updated J1939-75 Specification, Applicable Standards and DSE Four Steps to Synchronising Added Additional Droop Commissioning Screen, MSC Connect DSE8610s Screen, Droop and Load Demand Scheme Operation, DSE Steps to Successful Loadsharing.
Page 4: Table Of Contents
DSE8610 MKII Operator Manual TABLE OF CONTENTS Section Page INTRODUCTION ....................10 CLARIFICATION OF NOTATION ..................11 GLOSSARY OF TERMS ......................11 BIBLIOGRAPHY ........................13 1.3.1 INSTALLATION INSTRUCTIONS ................... 13 1.3.2 MANUALS ........................14 1.3.3 TRAINING GUIDES ......................15 1.3.4 THIRD PARTY DOCUMENTS ..................
Page 5 DSE8610 MKII Operator Manual 2.11.5.5 CONNECTION TO BASIC ETHERNET ..............40 2.11.5.6 CONNECTION TO COMPANY ETHERNET INFRASTRUCTURE ......41 2.11.5.7 CONNECTION TO THE INTERNET ................ 42 2.11.5.8 FIREWALL CONFIGURATION FOR INTERNET ACCESS ........43 2.11.5.9 ETHERNET USED FOR THE DSE2610 REMOTE DISPLAY ......... 44 2.11.6...
Page 6 DSE8610 MKII Operator Manual 3.4.8 2 PHASE (L1 & L2) 3 WIRE WITHOUT EARTH FAULT ..........83 3.4.9 2 PHASE (L1 & L3) 3 WIRE WITH RESTRICTED EARTH FAULT ........ 84 3.4.10 2 PHASE (L1 & L3) 3 WIRE WITHOUT EARTH FAULT ..........85 3.4.11...
Page 7 DSE8610 MKII Operator Manual QUICKSTART GUIDE ......................140 5.1.1 STARTING THE ENGINE ..................... 140 5.1.2 STOPPING THE ENGINE ..................... 141 STOP/RESET MODE ......................142 5.2.1 ECU OVERRIDE ......................142 MANUAL MODE ........................143 5.3.1 STARTING SEQUENCE ....................143 5.3.2 ENGINE RUNNING ....................... 144 5.3.3...
Page 8 DSE8610 MKII Operator Manual MAIN CONFIGURATION EDTIOR ..................204 7.1.1 ACESSING THE MAIN CONFIGURATION EDTIOR ............ 204 7.1.2 ENTERING PIN ......................204 7.1.3 EDITING A PARAMETER ..................... 205 7.1.4 EXITING THE MAIN CONFIGURATION EDITOR ............205 7.1.5 MAIN CONFIGURATION EDITOR PARAMETERS ............206 ‘RUNNING’...
Page 9 DSE8610 MKII Operator Manual 10.1.16 GTACP - GENERATOR TOTAL AC POWER ............236 10.1.17 GTACR - GENERATOR TOTAL AC REACTIVE POWER ........236 10.2 BROADCAST MESSAGES ENGINE INSTRUMENTATION ........... 236 10.2.1 DD - DASH DISPLAY ....................236 10.2.2 EC2 - ENGINE CONFIGURATION 2 ................237 10.2.3...
Page 10: Introduction
This allows the generator OEM greater flexibility in the choice of controller to use for a specific application. The DSE8610 MKII module has been designed to allow the operator to start, stop and synchronise the generator, and if required, transfer the load to the generator either manually or automatically.
Page 11: Clarification Of Notation
DSE8600 MKII, All modules in the DSE86xx MKII range. DSE86xx MKII DSE8610 MKII DSE8610 MKII module/controller DSE8x10 DSE8610, DSE8610 MKII, DSE8710 and DSE8810 module/controller DSE8x60 DSE8660, DSE8660 MKII, DSE8760 and DSE8860 module/controller DSE8x80 DSE8680 module/controller Controller Area Network Vehicle standard to allow digital devices to communicate to one another.
Page 12 Introduction Term Description Global System for Mobile communications. Cell phone technology used in most of the World. HEST High Exhaust System Temperature Initiates when DPF filter is full in conjunction with an extra fuel injector in the exhaust system to burn off accumulated diesel particulate matter or soot. Human Machine Interface A device that provides a control and visualisation interface between a human and a process or machine.
Page 13: Bibliography
DSE2152 Ratio-metric Output Expansion Installation Instructions 053-147 DSE9460 & DSE9461 Battery Charger Installation Instructions 053-152 DSE123 Cummins PCC Variant Installation Instructions 053-182 DSE8610 MKII Installation Instructions 053-183 DSE8620 MKII Installation Instructions 053-184 DSE8660 MKII Installation Instructions 053-185 DSE9473 & DSE9483 Battery Charger Installation Instructions...
Page 14: Manuals
PLC Programming Guide For DSE Controllers 057-176 DSE9460 & DSE9461 Battery Charger Operator Manual 057-220 Options for Communications with DSE Controllers 057-238 DSE8610 MKII Configuration Suite PC Software Manual 057-257 DSE8660 MKII Configuration Suite PC Software Manual 057-259 DSE8660 MKII Operator Manual 057-239...
Page 15: Training Guides
Introduction 1.3.3 TRAINING GUIDES Training guides are provided as ‘hand-out’ sheets on specific subjects during training sessions and contain specific information regarding to that subject. DSE Part Description 056-001 Four Steps To Synchronising 056-005 Using CTs With DSE Products 056-006 Introduction to Comms 056-010 Over Current Protection...
Page 16: Third Party Documents
Introduction 1.3.4 THIRD PARTY DOCUMENTS The following third-party documents are also referred to: Reference Description IEEE Std C37.2-1996 IEEE Standard Electrical Power System Device ISBN 1-55937-879-4 Function Numbers and Contact Designations. Institute of Electrical and Electronics Engineers Inc ISBN 0-7506-1147-2 Diesel generator handbook.
Page 17: Specification
Specification 2 SPECIFICATION 2.1 PART NUMBERING 8610 Variant Product Type Standard Module. DSE8610 MKII Generator 8610 Synchronising Control Standard Module Module with Heater. Hardware Revision Conformal Coated Module. Conformal Coated Module with Heater. UL 6200:2019 Certified. 2.2 OPERATING TEMPERATURE Module...
Page 18: Requirements For Ul
Specification 2.3 REQUIREMENTS FOR UL WARNING!: More than one live circuit exists, refer to section entitled Typical Wiring Diagram elsewhere in this document. Specification Description Screw Terminal • 4.5 lb-in (0.5 Nm) Tightening Torque • Terminals suitable for connection of conductor size 13 AWG to 20 AWG (0.5 Conductors mm²...
Page 19: Terminal Specification
Specification 2.4 TERMINAL SPECIFICATION Description Specification Two-part connector. Male part fitted to module Connection Type Female part supplied in module packing case - Screw terminal, rising clamp, no internal spring. Minimum Cable Size 0.5 mm² (AWG 20) Example showing cable entry and Maximum Cable Size 2.5 mm²...
Page 20: Voltage & Frequency Sensing
Specification 2.6 VOLTAGE & FREQUENCY SENSING NOTE: When using voltage transformers (VTs) they must be fitted to both generator and bus sensing, have the same ratio from the primary to secondary windings, and a 0° phase offset between the primary and secondary windings. Description Specification Measurement Type...
Page 21: Va Rating Of The Cts
Specification 2.7.1 VA RATING OF THE CTS NOTE: Details for 4 mm² cables are shown for reference only. The connectors on the DSE modules are only suitable for cables up to 2.5 mm². The VA burden of the module on the CTs is 0.5 VA. However, depending upon the type and length of cabling between the CTs and the module, CTs with a greater VA rating than the module are required.
Page 22: Ct Polarity
Specification 2.7.2 CT POLARITY NOTE: Take care to ensure correct polarity of the CT primary as shown above. If in doubt, check with the CT supplier. Take care to ensure the correct polarity of the CTs. Incorrect CT orientation leads to negative kW readings when the set is supplying power.
Page 23: Inputs
Specification 2.8 INPUTS 2.8.1 DIGITAL INPUTS Description Specification 12 configurable digital inputs Number (16 when Analogue Inputs are configured as digital inputs) Arrangement Contact between terminal and ground Low Level Threshold 2.1 V minimum High Level Threshold 6.6 V maximum Maximum Input Voltage +50 V DC with respect to plant supply negative Minimum Input Voltage...
Page 24: Analogue Inputs
Specification 2.8.3 ANALOGUE INPUTS All of the analogue inputs are flexible within the DSE8610 MKII module 2.8.3.1 ANALOGUE INPUT A Description Specification Flexible: Configured for Oil Sensor in the DSE default configuration. Input Type Flexible Options: Not used, Digital Input, Flexible Analogue Oil...
Page 25: Analogue Input B, C & D
Specification 2.8.3.2 ANALOGUE INPUT B, C & D Description Specification Flexible: Configured for Temperature Sensor in the DSE default Analogue Input B Type configuration. Flexible Options: Not used, Digital Input and Flexible Analogue Flexible: Configured for Fuel Sensor in the DSE default Analogue Input C Type configuration.
Page 26: Charge Fail Input
Specification 2.8.4 CHARGE FAIL INPUT The charge fail input is actually a combined input and output. Whenever the generator is required to run, the terminal provides excitation current to the charge alternator field winding. When the charge alternator is correctly charging the battery, the voltage of the terminal is close to the plant battery supply voltage.
Page 27: Outputs
Specification 2.9 OUTPUTS 2.9.1 DC OUTPUTS A & B (FUEL & START) Description Specification Normally used as Fuel & Start outputs. Type Fully configurable for other purposes if the module is configured to control an electronic engine. Rating 15 A resistive at Emergency Stop supply. 2.9.2 CONFIGURABLE VOLT-FREE RELAY OUTPUTS C &...
Page 28: Communication Ports
Specification 2.10 COMMUNICATION PORTS NOTE: All communication ports can be used at the same time. Description Specification Type B USB 2.0 USB Slave Port For connection to PC running DSE Configuration Suite Max distance 5 m (16 feet) Type A USB 2.0 USB Host Port Capability to add a maximum of 16 GB USB storage device for data recording only...
Page 29: Communication Port Usage
NOTE: The DC supply must be connected to the module for configuration by PC. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The USB port is provided to give a simple means of connection between a PC and the controller.
Page 30: Rs232 Port
Specification 2.11.3 RS232 PORT NOTE: For direct connection an RS232 null modem (crossover) cable is required. This is rated to a maximum cable length of 15 m. NOTE: For a single module to PC connection and distances up to 5 m (16 feet) the USB connection method is more suitable and provides for a lower cost alternative to RS485 (which is more suited to longer distance connections).
Page 31: Recommended Pc Rs232 Serial Port Add-Ons
Specification 2.11.3.2 RECOMMENDED PC RS232 SERIAL PORT ADD-ONS NOTE: DSE have no business tie to Brainboxes. Over many years, our own engineers have used these products and are happy to recommend them. NOTE: For further details of setting up the devices below, refer to the manufacture whose details are below.
Page 32: Rs232 Used For Plc Communication
Specification 2.11.3.3 RS232 USED FOR PLC COMMUNICATION NOTE: When the RS232 Port Usage is selected to “PLC Comms” it becomes the Master RS232 module, the other module’s Port Usage must be configured to “Gencomm”. This allows the “PLC Comms” configured module to read from the “Gencomm” configured module. For details on how to configure the PLC Editor to read through its RS232, refer to DSE Publication: 057-314 Advanced PLC Software Manual which is found on our website: www.deepseaelectronics.com...
Page 33: Rs232 Used For The Dse2610 Remote Display
The DSE2610 remote display utilises the RS232 or Ethernet hardware interface to allow connection to the DSE8610 MKII genset controller. The R232 port can be configured for connection to a modem or remote monitoring equipment (i.e. Building Management System, PLC or PC RS232 port).
Page 34: Rs485 Port
Specification 2.11.4 RS485 PORT NOTE: For a single module to PC connection and distances up to 5 m (16 feet) the USB connection method is more suitable and provides for a lower cost alternative to RS485 (which is more suited to longer distance connections). The RS485 port on the controller supports the MODBUS RTU protocol and is for connection to a single MODBUS master device only.
Page 35: Recommended Pc Rs485 Serial Port Add-Ons
Specification 2.11.4.2 RECOMMENDED PC RS485 SERIAL PORT ADD-ONS NOTE: DSE have no business tie to Brainboxes. Over many years, our own engineers have used these products and are happy to recommend them. NOTE: For further details of setting up the devices below, refer to the manufacture whose details are below.
Page 36: Rs485 Used For Modbus Engine Connection
2.11.4.3 RS485 USED FOR MODBUS ENGINE CONNECTION NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The RS485 port can be configured for connection to Cummins MODBUS engines (Engines fitted with Cummins GCS (G-Drive Control System)).
Page 37: Ethernet Port
2.11.5 ETHERNET PORT NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: For a single module to PC connection and distances up to 5 m (16 feet) the USB connection method is more suitable and provides for a lower cost alternative to Ethernet (which is more suited to longer distance connections).
Page 38: Snmp
2.11.5.3 SNMP NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The Ethernet port on the controller supports V2c of the Simple Network Management Protocol (SNMP) and is able to connect to two SNMP managers. SNMP is an international standard protocol for managing devices on IP networks.
Page 39: Direct Pc Connection
Specification 2.11.5.4 DIRECT PC CONNECTION Requirements • Ethernet cable (see below) • PC with Ethernet port Network Cable Ethernet Cable Wiring Detail NOTE: DSE stock 2 m (6.5 feet) Ethernet Cable, DSE Part Number: 016-137. Alternatively, they can be purchased from any PC or IT store. Connection 1 (T568A) Connection 2 (T568A) white/green stripe...
Page 40: Connection To Basic Ethernet
Specification 2.11.5.5 CONNECTION TO BASIC ETHERNET Requirements • Ethernet cable (see below) • Working Ethernet (company or home network) • PC with Ethernet port Ethernet Cable Ethernet Router or ADSL Router Ethernet Cable Wiring Detail NOTE: DSE stock 2 m (6.5 feet) Ethernet Cable, DSE Part Number: 016-137. Alternatively, they can be purchased from any PC or IT store.
Page 41: Connection To Company Ethernet Infrastructure
Specification 2.11.5.6 CONNECTION TO COMPANY ETHERNET INFRASTRUCTURE Requirements • DSE module with the ability to connect to Ethernet • Ethernet cable (see below) • Working Ethernet (company or home network) • PC with Ethernet port PC Network Wall Ethernet Router Connection or ADSL Router Sockets...
Page 42: Connection To The Internet
Specification 2.11.5.7 CONNECTION TO THE INTERNET Requirements • Ethernet cable (see below) • Working Ethernet (company or home network) • Working Internet connection (ADSL or DSL recommended) DSL or ADSL Router Ethernet INTERNET Cable The DSL/ADSL router routes external network traffic DSL or ADSL Router...
Page 43: Firewall Configuration For Internet Access
2.11.5.8 FIREWALL CONFIGURATION FOR INTERNET ACCESS NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. As modem/routers differ enormously in their configuration, it is not possible for DSE to give a complete guide to their use with the module.
Page 44: Ethernet Used For The Dse2610 Remote Display
The DSE2610 remote display utilises the RS232 or Ethernet hardware interface to allow connection to the DSE8610 MKII genset controller. The Ethernet port can be configured for connection to remote monitoring equipment (i.e. Building Management System, PLC or PC Ethernet port).
Page 45: Msc (Multi-Set Communications) Link
2.11.6 MSC (MULTI-SET COMMUNICATIONS) LINK NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: A termination resistor MUST be fitted to the first and last unit on the MSC link. For connection details, refer to section entitled Typical Arrangement of MSC Link elsewhere in this document.
Page 46: Can Port (Redundant Msc)
Specification 2.11.7 CAN PORT (REDUNDANT MSC) NOTE: The redundant MSC link connectivity is only available in DSE8xxx MKII modules V4.1 or later. Contact DSE technical support: support@deepseaelectronics.com for more information. NOTE: A termination resistor MUST be fitted to the first and last unit on the MSC link. For connection details, refer to section entitled Typical Arrangement of MSC Link elsewhere in this document.
Page 47 Specification Description Specification “Daisy Chain” Bus with no stubs (spurs) Redundant MSC Topology 120 . Redundant MSC Termination Must be fitted externally to the first and last module. Total 40 devices made up of DSE8x10 MKII (up to 32) and DSE8x60 MKII (up to 16) This gives the possibility of : Maximum DSE8xxx MKII...
Page 48: Ecu Port (J1939)
2.11.8 ECU PORT (J1939) NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: Screened 120  impedance cable specified for use with CAN must be used for the CAN link.
Page 49: Can Supported Avrs
Specification 2.11.8.2 CAN SUPPORTED AVRS NOTE: At the time of writing this manual, only the DSEA108 & DSEA109 CAN AVRs are supported for voltage control via the CAN. For further details on connection to supported CANbus AVRs, contact DSE technical support: support@deepseaelectronics.com. The modules are fitted with a CAN interface as standard and are capable of receiving alternator data from certain AVRs compliant with the CAN J1939 standard, as well as controlling the AVR.
Page 50: J1939-75
Specification 2.11.8.3 J1939-75 NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Software Manual NOTE: For further details of CAN communication, see the section entitled CAN Interface Specification (J1939-75) elsewhere in this document. When the J1939-75 is enabled in the module’s configuration, the module’s AC measurements and alarms are sent onto the CANbus using the ECU Port, received typically by an external monitoring device.
Page 51: Configurable Can
2.11.8.4 CONFIGURABLE CAN NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Software Manual. The module’s CAN port is used to connect third-party CAN devices (controllers, battery chargers…) and allows the module to read and transmit configurable CAN instruments.
Page 52: Dsenet (Expansion Modules)
(EXPANSION MODULES) NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: As a termination resistor is internally fitted to the controller, the controller must be the ‘first’ unit on the DSENet link.
Page 53: Dsenet Used For Modbus Engine Connection
2.11.9.1 DSENET USED FOR MODBUS ENGINE CONNECTION NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. As DSENet ® utilises an RS485 hardware interface, this port can be configured for connection to Cummins MODBUS engines (Engines fitted with Cummins GCS (G-Drive Control System)).
Page 54: Sounder
Specification 2.12 SOUNDER The module features an internal sounder to draw attention to warning, electrical trip and shutdown alarms. Description Specification Sounder Level 64 dB at 1 m 2.12.1 ADDING AN EXTERNAL SOUNDER Should an external alarm or indicator be required, this can be achieved by using the DSE Configuration Suite PC software to configure an auxiliary output for Audible Alarm, and by configuring an auxiliary input for Alarm Mute (if required).
Page 55: Dimensions And Mounting
Specification 2.14 DIMENSIONS AND MOUNTING 2.14.1 DIMENSIONS 245 mm x 184 mm x 51 mm (9.6 ” x 7.2 ” x 2.0 ”) 2.14.2 PANEL CUTOUT 220 mm x 159 mm (8.7” x 6.3”) 2.14.3 WEIGHT 0.98 kg (2.16 lb) Page 55 of 246 057-254 ISSUE: 10...
Page 56: Fixing Clips
Specification 2.14.4 FIXING CLIPS NOTE: In conditions of excessive vibration, mount the module on suitable anti-vibration mountings. The module is held into the panel fascia using the supplied fixing clips: • Withdraw the fixing clip screw (turn anticlockwise) until only the pointed end is protruding from the clip.
Page 57: Cable Tie Fixing Points
Specification 2.14.5 CABLE TIE FIXING POINTS Cable tie fixing points are included on the rear of the module’s case to aid wiring. This additionally provides strain relief to the cable loom by removing the weight of the loom from the screw connectors, reducing the chance of future connection failures.
Page 58: Applicable Standards
Specification 2.15 APPLICABLE STANDARDS Standard Description BS 4884-1 This document conforms to BS4884-1 1992 Specification for presentation of essential information. BS 4884-2 This document conforms to BS4884-2 1993 Guide to content BS 4884-3 This document conforms to BS4884-3 1993 Guide to presentation BS EN 60068-2-1 -30 C (-22 F) (Minimum...
Page 59 81 – Frequency relay 83 – Automatic selective control or transfer relay 86 – Lockout relay In line with our policy of continual development, Deep Sea Electronics, reserve the right to change specification without notice. Page 59 of 246 057-254 ISSUE: 10...
Page 60: Enclosure Classifications
Specification 2.15.1 ENCLOSURE CLASSIFICATIONS 2.15.1.1 IP CLASSIFICATIONS The modules specification under BS EN 60529 Degrees of protection provided by enclosures IP65 (Front of module when module is installed into the control panel with the optional sealing gasket). IP42 (front of module when module is installed into the control panel WITHOUT being sealed to the panel) First Digit Second Digit Protection against contact and ingress of solid objects...
Page 61: Installation
Installation 3 INSTALLATION The module is designed to be mounted on the panel fascia. For dimension and mounting details, see the section entitled Dimension and Mounting elsewhere in this document. 3.1 USER CONNECTIONS NOTE: Availability of some terminals depends upon module version. Full details are given in the section entitled Terminal Description elsewhere in this manual.
Page 62: Connection Descriptions
Start output requirements may be different. For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Cable Description...
Page 63: Analogue Sensor Inputs & Can
3.2.2 ANALOGUE SENSOR INPUTS & CAN NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: It is VERY important that terminal 15 (sensor common) is connected to an earth point on the ENGINE BLOCK, not within the control panel, and must be a sound electrical connection to the sensor bodies.
Page 64: Mpu, Ecu, Msc & Dsenet
3.2.3 MPU, ECU, MSC & DSENET NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring NOTE: Screened 120 ...
Page 65: Output C & D, & V1 (Generator) Voltage & Frequency Sensing
Installation 3.2.4 OUTPUT C & D, & V1 (GENERATOR) VOLTAGE & FREQUENCY SENSING NOTE: The below table describes connections to a three phase, four wire alternators. For alternative wiring topologies, see the section entitled Alternate Topology Wiring Diagrams elsewhere in this document. Cable Description Notes...
Page 66: Current Transformers
Installation 3.2.6 CURRENT TRANSFORMERS WARNING!: Do not disconnect this plug when the CTs are carrying current. Disconnection open circuits the secondary of the C.T.’s and dangerous voltages may then develop. Always ensure the CTs are not carrying current and the CTs are short circuit connected before making or breaking connections to the module.
Page 67: Ct Connections
K To Generator To Load Polarity of CT Primary 3.2.7 DIGITAL INPUTS NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Cable Description Notes Size 0.5 mm² Configurable Digital Input A...
Page 68: Rs485
3.2.8 RS485 NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: A 120 Ω termination resistor must be fitted across terminals A and B if the DSE module is the first or last device on the R485 link.
Page 69: Rs232
3.2.9 RS232 NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: Connecting a modem directly to the module’s RS232 is for legacy support only. When a new installation requires remote communication using the cellular network, refer to DSE products DSE890, DSE891 and DSEWebNet on the DSE website: www.deepseaelectronics.com.
Page 70: Usb Slave (Pc Configuration) Connector
CAUTION!: Care must be taken not to overload the PCs USB system by connecting more than the recommended number of USB devices to the PC. For further information, consult your PC supplier. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Cable Description Notes...
Page 71: Typical Wiring Diagram
Installation 3.3 TYPICAL WIRING DIAGRAM As every system has different requirements, these diagrams show only a typical system and do not intend to show a complete system. Genset manufacturers and panel builders may use these diagrams as a starting point; however always refer to the completed system diagram provided by the system manufacturer for complete wiring detail.
Page 72: Phase 4 Wire With Restricted Earth Fault
Star, 3 Phase 4 Wire Delta L1-N-L2, 3 Phase 4 Wire Delta L1-N-L3 and 3 Phase 4 Wire Delta L2-N-L3. For further details of module configuration to suit these different topologies, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’...
Page 73: Earth Systems
Installation 3.3.2 EARTH SYSTEMS 3.3.2.1 NEGATIVE EARTH The typical wiring diagrams located within this document show connections for a negative earth system (the battery negative connects to Earth). 3.3.2.2 POSITIVE EARTH When using a DSE module with a Positive Earth System (the battery positive connects to Earth), the following points must be followed: Follow the typical wiring diagram as normal for all sections except the earth points.
Page 74: Typical Arrangement Of Dsenet
3.3.3 TYPICAL ARRANGEMENT OF DSENET NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: This feature is not available if the DSE86xx MKII module has been configured to ®...
Page 75: Typical Arrangement Of Msc Link
Communications) Link and CAN Port (Redundant MSC) elsewhere in this document. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: Screened 120  impedance cable specified for use with CAN must be used for the MSC link connection.
Page 76: Alternate Topology Wiring Diagrams
Installation 3.4 ALTERNATE TOPOLOGY WIRING DIAGRAMS 3.4.1 SINGLE PHASE (L1 & N) 2 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’...
Page 77: Single Phase (L1 & N) 2 Wire Without Earth Fault
Installation 3.4.2 SINGLE PHASE (L1 & N) 2 WIRE WITHOUT EARTH FAULT Page 77 of 246 057-254 ISSUE: 10...
Page 78: Single Phase (L1 & L2) 3 Wire With Restricted Earth Fault
Installation 3.4.3 SINGLE PHASE (L1 & L2) 3 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’...
Page 79: Single Phase (L1 & L2) 3 Wire Without Earth Fault
Installation 3.4.4 SINGLE PHASE (L1 & L2) 3 WIRE WITHOUT EARTH FAULT Page 79 of 246 057-254 ISSUE: 10...
Page 80: Single Phase (L1 & L3) 3 Wire With Restricted Earth Fault
Installation 3.4.5 SINGLE PHASE (L1 & L3) 3 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’...
Page 81: Single Phase (L1 & L3) 3 Wire Without Earth Fault
Installation 3.4.6 SINGLE PHASE (L1 & L3) 3 WIRE WITHOUT EARTH FAULT Page 81 of 246 057-254 ISSUE: 10...
Page 82: Phase (L1 & L2) 3 Wire With Restricted Earth Fault
Installation 3.4.7 2 PHASE (L1 & L2) 3 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’...
Page 83: Phase (L1 & L2) 3 Wire Without Earth Fault
Installation 3.4.8 2 PHASE (L1 & L2) 3 WIRE WITHOUT EARTH FAULT Page 83 of 246 057-254 ISSUE: 10...
Page 84: Phase (L1 & L3) 3 Wire With Restricted Earth Fault
Installation 3.4.9 2 PHASE (L1 & L3) 3 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’...
Page 85: Phase (L1 & L3) 3 Wire Without Earth Fault
Installation 3.4.10 2 PHASE (L1 & L3) 3 WIRE WITHOUT EARTH FAULT Page 85 of 246 057-254 ISSUE: 10...
Page 86: Phase 3 Wire Detla Without Earth Fault
Installation 3.4.11 3 PHASE 3 WIRE DETLA WITHOUT EARTH FAULT 057-254 ISSUE: 10 Page 86 of 246...
Page 87: Phase 4 Wire Without Earth Fault
Star, 3 Phase 4 Wire Delta L1-N-L2, 3 Phase 4 Wire Delta L1-N-L3 and 3 Phase 4 Wire Delta L2-N-L3. For further details of module configuration to suit these different topologies, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Page 87 of 246...
Page 88: Phase 4 Wire With Restricted Earth Fault
Star, 3 Phase 4 Wire Delta L1-N-L2, 3 Phase 4 Wire Delta L1-N-L3 and 3 Phase 4 Wire Delta L2-N-L3. For further details of module configuration to suit these different topologies, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. 057-254 ISSUE: 10...
Page 89: Phase 4 Wire With Unrestricted Earth Fault
L2-N-L3. For further details of module configuration to suit these different topologies, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. This example shows the CTs in the neutral to earth link for a three phase four wire system to provide unrestricted earth fault protection, but the same philosophy is applicable to the other topologies.
Page 90: Typical Single Line Application Drawings
Installation 3.5 TYPICAL SINGLE LINE APPLICATION DRAWINGS 3.5.1 MULTI GENERATORS FOR PRIME POWER NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com. 057-254 ISSUE: 10 Page 90 of 246...
Page 91: Multi Generators For Prime Power Using Load-Share Lines
Installation 3.5.2 MULTI GENERATORS FOR PRIME POWER USING LOAD-SHARE LINES NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com. NOTE: To use analogue loadshare lines from external Load Share Units, each DSE8x10 MKII must be fitted with a DSE123 to convert its MSC link.
Page 92: Multi Generators For Prime Power With Bus Couplers
Installation 3.5.3 MULTI GENERATORS FOR PRIME POWER WITH BUS COUPLERS NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com. 057-254 ISSUE: 10 Page 92 of 246...
Page 93: Multi Generators With Single Synchronising Mains Switch
NOTE: To use the DSE8x60 MKII without a bus breaker, the No Bus Breaker option in the DSE8x10 MKII and DSE8x60 MKII modules must be enabled. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual and DSE Publication: 057-257 DSE8660 MKII Configuration Suite PC Software Manual, or contact DSE technical support for further information, support@deepseaelectronics.com.
Page 94: Multi Generators With Single Synchronising Transfer Switch
Installation 3.5.5 MULTI GENERATORS WITH SINGLE SYNCHRONISING TRANSFER SWITCH NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com . 057-254 ISSUE: 10 Page 94 of 246...
Page 95: Multi Generators With Two Synchronising Transfer Switches
Installation 3.5.6 MULTI GENERATORS WITH TWO SYNCHRONISING TRANSFER SWITCHES NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com . Page 95 of 246 057-254 ISSUE: 10...
Page 96: Multi Generators & Synchronising Transfer Switches
Installation 3.5.7 MULTI GENERATORS & SYNCHRONISING TRANSFER SWITCHES NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com . 057-254 ISSUE: 10 Page 96 of 246...
Page 97: Multi Generators & Transfer Switches With Bus Coupler
Installation 3.5.8 MULTI GENERATORS & TRANSFER SWITCHES WITH BUS COUPLER NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com . Page 97 of 246 057-254 ISSUE: 10...
Page 98: Single Generator Exporting (Base Loading) Power
Installation 3.5.9 SINGLE GENERATOR EXPORTING (BASE LOADING) POWER NOTE: When the DSE8x10 MKII unit is used for exporting (base loading) power it cannot be used for synchronising back to the mains upon its return without a DSE8x60 unit. For further details of export (base loading) power and its operation, refer to DSE Publication: 056-054 DSExx10 in Fixed Export.
Page 99: Multi Generators Exporting (Base Loading) Power
Installation 3.5.10 MULTI GENERATORS EXPORTING (BASE LOADING) POWER NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaelectronics.com . NOTE: When the DSE8x10 MKII unit is used for exporting (base loading) power it cannot be used for synchronising back to the mains upon its return without a DSE8x60 unit.
Page 100: Description Of Controls
Description of Controls 4 DESCRIPTION OF CONTROLS CAUTION: The module may instruct an engine start event due to external influences. Therefore, it is possible for the engine to start at any time without warning. Prior to performing any maintenance on the system, it is recommended that steps are taken to remove the battery and isolate supplies.
Page 101 Description of Controls Menu Module Navigation Display Four configurable status LEDs Open Close Generator Generator (Manual Mode (Manual Mode Only) Only) Start Stop / Reset Manual Auto Alarm Mute & Mode Mode Mode Lamp Test Generator Available LED Selected Mode Generator Indication LED Breaker LED...
Page 102: Control Push Buttons
Description of Controls 4.1 CONTROL PUSH BUTTONS NOTE: For further details, see section entitled Operation elsewhere in this manual. Icon Description Stop / Reset Mode This button places the module into its Stop/Reset Mode . This clears any alarm conditions for which the triggering criteria has been removed. If the engine is running and the module is put into Stop/Reset Mode , the module automatically instructs the generator off load (‘Close Generator Output’...
Page 103 Description of Controls NOTE: For further details, see section entitled Operation elsewhere in this manual. Icon Description Alarm Mute / Lamp Test This button silences the audible alarm in the controller, de-activates the Audible Alarm output (if configured) and illuminates all of the LEDs on the module’s facia as a lamp test function.
Page 104: Viewing The Instrument
NOTE: Depending upon the module’s configuration, some display screens may be disabled. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. It is possible to scroll to display the different pages of information by repeatedly operating the Next &...
Page 105: Status
Configurable Status Screens if configured. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. This is the ‘home’ page, the page that is displayed when no other page has been selected, and the page that is automatically displayed after a period of inactivity (LCD Page Timer) of the module control buttons.
Page 106: Configurable Status Screens
Description of Controls 4.2.1.3 CONFIGURABLE STATUS SCREENS The contents of the Home Page may vary depending upon configuration by the generator manufacturer or supplier. Below is an example of the Home Page being changed to show engine CAN related information. The configured status pages are displayed as the Home Page Example of EPA icons...
Page 107: Engine
Description of Controls 4.2.2 ENGINE NOTE*: For further details of support engine, refer to DSE Publication: 057-004 Electronic Engines and DSE Wiring Guide. These pages contain instrumentation gathered about the engine measured or derived from the module’s inputs, some of which may be obtained from the engine ECU. Engine 1500 RPM Engine Speed...
Page 108: Manual Fuel Pump Control
4.2.2.1 MANUAL FUEL PUMP CONTROL NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Depending upon module configuration, the Fuel Level page may include a Tick icon. This denotes that Manual Fuel Pump Control is available by pressing and holding the Tick button.
Page 109: Dpf Regeneration Lamps
DPF REGENERATION LAMPS NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Depending upon the Engine Type selected in the module’s configuration, the Engine section may include the DPF Regeneration Lamps page. This page contains icons to show the status of various ECU functions, some of which are applicable to Tier 4 engine requirements.
Page 110: Generator
Description of Controls 4.2.3 GENERATOR Contains electrical values of the Generator, measured or derived from the module’s voltage and current inputs. Press the Instrumentation Scroll buttons scroll through the Generator parameters. Generator 50.00 Hz Generator Voltage (Line to Neutral) Generator Voltage (Line to Line) Generator Frequency Generator Current (A) Generator Load Line to Neutral (kW)
Page 111: Commisioning Screens
Description of Controls 4.2.3.1 COMMISIONING SCREENS NOTE: Some of the items may be removed from the commissioning screens if they are not applicable to the module configuration. NOTE: The Commissioning Screens are used to gauge how well the module is controlling the generator for Loadsharing.
Page 112: Synchroscope
Description of Controls 4.2.3.2 SYNCHROSCOPE Note: If the module display is showing the status page when the synchronising process begins, the module automatically switches to the Synchroscope page. The ramp progress is also be displayed on the screen once paralleling has taken place. Initially the synchroscope display shows the difference between the bus and generator supplies.
Page 113: Dse8X10 Msc Connection Status
DSE8X10 MSC CONNECTION STATUS NOTE: The MSC ID is configured only using the DSE Configuration Suite Software. For further details, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. NOTE: Depending on the module’s configuration, the MSC ID is set automatically or manually.
Page 114: Power De-Rate
DSE Configuration Suite PC Software. For further details, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The Power De-Rate feature serves to reduce the amount of power produced by the generator when in parallel, upon certain conditions that could be related to engine temperature levels, digital inputs, or other conditions.
Page 115: Bus
NOTE: Depending upon the module’s configuration, some display screens may be disabled. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Contains measured values from various input expansion modules that are connected to the DSE module.
Page 116: Charger Id
NOTE: Depending upon the module’s configuration, some display screens may be disabled. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Contains the information and instrumentation of the DSE Intelligent Battery Chargers that are connected to the DSE controller.
Page 117: Alarms
Description of Controls 4.2.7 ALARMS When an alarm is active, the Internal Audible Alarm sounds and the Common Alarm LED, if configured, illuminates. The audible alarm is silenced by pressing the Alarm Mute / Lamp Test button. The LCD display jumps from the ‘Information page’ to display the Alarm Page Number of active alarms.
Page 118: Ecu Alarms (Can Fault Codes / Dtc)
Description of Controls 4.2.7.1 ECU ALARMS (CAN FAULT CODES / DTC) NOTE: For details on these code/graphic meanings, refer to the ECU instructions provided by the engine manufacturer, or contact the engine manufacturer for further assistance. NOTE: For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring When connected to a suitable CAN engine, the controller displays alarm status messages from the ECU in the Alarms section of the display.
Page 119: Event Log
4.2.8 EVENT LOG NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The module maintains a log of past alarms and/or selected status changes. The log size has been increased in the module over past module updates and is always subject to change.
Page 120: Protections Disabled
Description of Controls 4.2.8.1 PROTECTIONS DISABLED NOTE: For further details on Protections Disabled, see section entitled Protections elsewhere in this manual. Configuration is possible to prevent Shutdown and Electrical Trip alarms from stopping the generator. Under such conditions the operator is informed the events were blocked. Example: Event Log Oil Pressure Low...
Page 121: Communications
Description of Controls 4.2.9 COMMUNICATIONS 4.2.9.1 RS232 SERIAL PORT NOTE: Factory default settings are for the RS232 port to be enabled for Gencomm connection, operating at 115200 baud, MODBUS slave address 10. NOTE: Connecting a modem directly to the module’s RS232 is for legacy support only. When a new installation requires remote communication using the cellular network, refer to DSE products DSE890, DSE891 and DSEWebNet on the DSE website: www.deepseaelectronics.com.
Page 122 Description of Controls Connected to an RS232 GSM Modem NOTE: Not all alarms generate a dial out command; this is dependent upon module configuration of the event log. Any event configured to be recorded in the event log causes the modem to dial out to a PC.
Page 123 Description of Controls Modem Initialisation Sequence The modem attempts to communicate to the module If the Modem and module communicate successfully: In case of communication failure between the modem and module, the modem is automatically reset, and initialisation is attempted once more: In the case of a module that is unable to communicate with the modem, the display continuously cycles between ‘Modem Reset’...
Page 124 Description of Controls Connected to An RS232 MODBUS Master NOTE: The MODBUS Master can be another DSE module communicating through its PLC. For further details see section entitled RS232 Used For PLC Communication elsewhere in this document. The modules operate as a MODBUS RTU slave device. In a MODBUS system, there is only one Master, typically a PLC, HMI system, PC SCADA system, or another DSE module using its PLC Comms.
Page 125 Description of Controls Connected to An RS232 Slave DSE Module NOTE: For details on how to use the PLC to read from another DSE module’s GenComm registers, refer to DSE Publication: 057-314 Advanced PLC Software Manual which is found on our website: www.deepseaelectronics.com The module operates as a master controller to read from another DSE module’s GenComm registers.
Page 126: Rs485 Serial Port
Description of Controls 4.2.9.2 RS485 SERIAL PORT NOTE: Factory default settings are for the RS485 port to be enabled for Gencomm connection, operating at 115200 baud, MODBUS slave address 10. This section is included to give information about the currently selected serial port. The items displayed on this page change depending upon configuration of the module.
Page 127 Description of Controls RS485 MODBUS RTU Diagnostics RS485 MODBUS RTU diagnostic screens are included; press the Scroll Down button when viewing the RS485 Serial Port instruments to cycle to the available screens. If experiencing RS485 MODBUS RTU communication problems, this information aids troubleshooting. RS485 Port 1 Shows the state of the RS485 communication lines.
Page 128: Usb Connection
Description of Controls Connected to RS485 Slave DSE Modules NOTE: For details on how to use the PLC to read from another DSE module’s GenComm registers, refer to DSE Publication: 057-314 Advanced PLC Software Manual which is found on our website: www.deepseaelectronics.com The module operates as a master controller to read from other DSE module(s) GenComm registers.
Page 129: Ethernet
Description of Controls 4.2.9.4 ETHERNET Whilst in the Communication section, press the Scroll Down button to access more information about the network settings. Network settings are configured using DSE Configuration Suite PC Software. The module must be rebooted for the changes to take effect. Network IP Address: The configured network IP address of the module IP Address...
Page 130: Dsenet Connection
Description of Controls 4.2.9.5 DSENET CONNECTION DSENet diagnostic screens are included; press the Scroll Down button when viewing the Communication instrument section to cycle to the available screen. If experiencing DSENet communication problems, this information aids troubleshooting. DSENet Connection Shows the state of the DSENet communication lines. These can help diagnose connection problems.
Page 131: Avr Can
4.2.10 AVR CAN NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Software Manual. NOTE: The Feedback Voltages might not indicate the true Generator Voltage values. The Feedback Voltage instruments’ reading(s) depend on the CAN AVR device used, the way it is connected to the AC alternator’s windings and configuration.
Page 132: Avr Current Dtcs
Description of Controls Stability Selection Shows the selected Stability configuration in the CAN AVR. Software Version Information screen indicating the software version of V2.0.2 the CAN AVR connected to the DSE module. 4.2.10.1 AVR CURRENT DTCS NOTE: For details on these code/graphic meanings, refer to the AVR instructions provided by the manufacturer, or contact the manufacturer for further assistance.
Page 133: Schedule
Scheduler in the Operation section of this document. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The controller contains an inbuilt exercise run scheduler, capable of automatically starting and stopping the set or inhibiting the set from starting.
Page 134: Plc Instruments
NOTE: Depending upon the module’s configuration, some display screens may be disabled. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual and 057-314 Advanced PLC Programming Guide for DSE Controllers. Contains values from various elements from the module’s internal PLC editor to enable the user to view them from the module’s facia.
Page 135 Description of Controls String Example: PLC Instruments String: The name of the string as configured in the PLC. New String Var 1 Value: The initial value text as configured in the PLC. Test Timer Example: PLC Instruments Timer 1: The name of the timer as configured in the PLC. New Timer 1 Value: The time configured in the PLC.
Page 136: Configurable Can
NOTE: Depending upon the module’s configuration, some display screens may be disabled. For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The configurable CAN instruments are intended to display CAN information from external third-party CAN devices such as fuel flow meters.
Page 137: Miscellaneous
Description of Controls 4.2.15 MISCELLANEOUS 4.2.15.1 DATA LOGGING Whilst in the ‘ABOUT’ section, press Scroll Down button to access more information about the data logging settings. Location of logged data. Displays either internal module memory or external USB memory. Data Logging Log to internal memory If data logging is active or inactive Logging active...
Page 138: About
Description of Controls 4.2.16 ABOUT Contains important information about the module and the firmware versions. This information may be asked for when contacting DSE Technical Support Department for advice. About Variant: DSE86xx MKII Application Version: The version of the module’s main Variant 8610 MKII firmware file (Updatable using the Firmware Update...
Page 139: User Configurable Indicators
Description of Controls 4.3 USER CONFIGURABLE INDICATORS These LEDs are configured by the user to indicate any one of 100+ different functions based around the following: Indications - Monitoring of a digital input and indicating associated functioning user’s equipment - Such as Battery Charger On or Louvres Open, etc.
Page 140: Operation
Operation 5 OPERATION NOTE: The following descriptions detail the sequences followed by a module containing the standard ‘factory configuration’. Always refer to your configuration source for the exact sequences and timers observed by any particular module in the field. 5.1 QUICKSTART GUIDE This section provides a quick start guide to the module’s operation.
Page 141: Stopping The Engine
Operation 5.1.2 STOPPING THE ENGINE NOTE: For further details, see the section entitled Operation elsewhere in this document. Select Stop/Reset mode. The generator is stopped Page 141 of 246 057-254 ISSUE: 10...
Page 142: Stop/Reset Mode
Viewing the instruments and event logs is NOT affected by Panel Lock. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Stop/Reset Mode is activated by pressing the Stop/Reset Mode button.
Page 143: Manual Mode
CAN. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The fuel relay is energised and the engine is cranked. If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the Crank Rest Timer duration after which the next start attempt is made.
Page 144: Engine Running
Operation 5.3.2 ENGINE RUNNING NOTE: The load transfer signal remains inactive until the generator is available. This prevents excessive wear on the engine and alternator. , the generator does not synchronise and close its load switch unless a ‘loading In Manual Mode request’...
Page 145: Automatic Mode
CAN and transmit the engine speed to the DSE controller. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. To allow for ‘false’ start requests, the Start Delay timer begins.
Page 146: Engine Running
Operation 5.4.3 ENGINE RUNNING NOTE: The load transfer signal remains inactive until the generator is available. This prevents excessive wear on the engine and alternator. The generator synchronises to the bus and is placed on load if configured to do so. If all start requests are removed, the Stopping Sequence begins.
Page 147: Prime Power (Load Share)
Operation 5.5 PRIME POWER (LOAD SHARE) 5.5.1 ISOCHRONOUS NOTE: For further details on the Load Demand Scheme (automatic starting/stopping of generators based on load), refer to section entitled Load Demand Scheme elsewhere in this document. When generators are running in parallel isochronously (zero droop), the amount of power they produce to the load has to be controlled to ensure it is shared amongst them whilst still running at nominal frequency and voltage.
Page 148: Droop
Operation 5.5.2 DROOP NOTE: The Frequency Droop and Voltage Droop function within the module is not supported when using a DSExx60 module. NOTE: The Load Demand Scheme is not available whilst operating in Droop. When generators are running in parallel in Droop only, the amount of power they produce to the load has to be controlled to ensure it is shared between the generators, by varying the frequency and voltage the system is running at.
Page 149 Operation Whilst the generators are in parallel, the DSE8x10 controllers instruct the generators to run at a certain frequency/voltage dependant on the active power (kW)/reactive power (kvar) the generator is producing. In the example below, both generators have the same Droop Curve configured for the Frequency Droop and Voltage Droop.
Page 150: Load Demand Scheme
“86xx up to v5.1” for module versions up to v5.1. For more details refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The module is included in the Load Demand Scheme by activating a digital input configured as Remote Start on Load Demand.
Page 151 Operation Remote Start on Remote Start Load Demand on Load Page 151 of 246 057-254 ISSUE: 10...
Page 152: Fixed Export (Base Load)
Operation 5.6 FIXED EXPORT (BASE LOAD) NOTE: For further details on the fixed export (base load), refer to DSE Publication: 056- 054 DSExx10 in Fixed Export and see section entitled Single Generator Exporting (Base Loading) Power elsewhere in this document. When a generator is running in parallel with the mains isochronously (zero droop), the amount of power it produces has to be controlled.
Page 153: Power Modes
NOTE: For further details of the configuration for the different power modes, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. It is sometimes required that when a generator is placed in parallel with the mains, that it does not simply produced a fixed amount of Active Power (kW) or Reactive Power (kvar).
Page 154: Voltage And Reactive (Kvar) Power Control
Operation 5.6.1.2 VOLTAGE AND REACTIVE (KVAR) POWER CONTROL Constant Reactive Power Mode (Default) This is the default mode of exporting power to the mains (utility); where the DSE load share controller holds the amount of reactive power produced at a constant level. The amount of reactive power produced by the generator is irrespective of the load level or any other parameter.
Page 155: Simulation Injection Testing
Operation 5.6.1.3 SIMULATION INJECTION TESTING NOTE: For further details about the Simulation Injection Testing, refer to DSE Publication: 056-123 Simulation Injection Testing. The Simulation Injection Testing enables the user to override the DSE module’s measurements of the generator’s voltage and frequency. This is provided so the various Power Modes for mains parallel can be tested without having to alter the main’s actual voltage and frequency.
Page 156: Scheduler
Operation 5.7 SCHEDULER The controller contains an inbuilt exercise run scheduler, capable of automatically starting and stopping the set or inhibiting the set from starting. Up to 16 scheduled (in two banks of 8) start/stop/inhibiting start sequences can be configured to repeat on a 7-day or 28-day cycle. Scheduled runs may be on load or off load depending upon module configuration.
Page 157: Msc Compatibility Mode
 = The DSE8610 MKII uses MSC link for connection to other DSE modules for ramping and load sharing.  = The DSE8610 MKII is connected to a DSE123 to convert the MSC link into Analogue Load Share lines interface.
Page 158: Alternative Configurations
Operation 5.9 ALTERNATIVE CONFIGURATIONS Depending upon the configuration of the system by the generator supplier, the system may have selectable configurations (for example to select between 50 Hz and 60 Hz). If this has been enabled the generator supplier will advise how this selection can be made (usually by operating an external selector switch or by selecting the required configuration file in the module’s front panel configuration editor).
Page 159: Load Shedding Control
Operation 5.10.2 LOAD SHEDDING CONTROL The Load Shedding Control feature (if enabled) allows for a maximum of five load shedding steps. When the generator is about to take load, the configured number of Load Shedding Control Outputs at Start will energise. This allows certain none-essential loads to be removed prior to the generator’s load switch being closed.
Page 160: Sms Control
Operation 5.11 SMS CONTROL The SMS Control feature (if enabled) allows the user to send control commands to the module via SMS message. There are five control commands that the user is able to send to the module shown in the table below.
Page 161: Dead Bus Synchronising (Auto Mode)
Synchronising, any number of generators are able to be online and in parallel potentially within 15 seconds, depending upon applications and hardware used. 5.12.2 HARDWARE REQUIREMENTS • DSE8610 MKII controller. • DC controlled generator load switch. • Auxiliary contact to feedback generator breaker status to the DSE controller.
Page 162: Operation
Operation 5.12.3 OPERATION Before the generator sets are started, their load switches are closed. As there is no AC supply the load switches must be DC controlled. Next, the alternator excitation field is disabled by isolating the supply to the AVRs. The engines are all started at the same time and allowed for the Excitation Delay timer to reach the desired operating speed.
Page 163: Protections
Protections 6 PROTECTIONS 6.1 ALARMS When an alarm is active, the Internal Audible Alarm sounds and the Common Alarm output if configured, activates. The audible alarm is silenced by pressing the Alarm Mute / Lamp Test button. The LCD display jumps from the ‘Information page’ to display the Alarm Page Number of active alarms.
Page 164: Protections Disabled
Protections 6.1.1 PROTECTIONS DISABLED Configuration is possible to prevent Shutdown and Electrical Trip alarms from stopping the generator. Under such conditions, Protections Disabled appears on the module display to inform the operator. Shutdown and Electrical Trip alarms still appear however, the operator is informed the alarms are blocked.
Page 165: Reset Electrical Trip
Protections 6.1.2 RESET ELECTRICAL TRIP Configuration is possible to enable the operator to reset Electrical Trip alarm a configurable number of times before the generator has stopped. This is to allow the generator to go back on load without having to perform a cooling run first. It is also possible to prevent an Electrical Trip alarm from stopping the generator.
Page 166: Ecu Alarms (Can Fault Codes / Dtc)
Protections 6.1.3 ECU ALARMS (CAN FAULT CODES / DTC) NOTE: For details on these code meanings, refer to the ECU instructions provided by the engine manufacturer, or contact the engine manufacturer for further assistance. NOTE: For further details on connection to electronic engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring When connected to a suitable CAN engine, the controller displays alarm status messages from the ECU in the Alarms section of the display.
Page 167: Indications
Protections 6.2 INDICATIONS Indications are non-critical and often status conditions. They do not appear on the LCD display of the module as a text message in the Status, Event Log or Alarms pages. However, an output or LED indicator is configured to draw the operator’s attention to the event. Example: •...
Page 168: Warning Alarms
For further details of module configuration, refer to DSE Publication: 057- 2130 ID 1 to 4 Analogue 238 DSE8610 MKII Configuration Suite PC Software Manual. Input E to H High The module detected that an analogue input value of a DSE2130 had risen above the Flexible Sensor High Pre-Alarm Trip level.
Page 169 For further details of module configuration, refer to DSE Publication: 057-238 2131 ID 1 to 4 Analogue DSE8610 MKII Configuration Suite PC Software Manual. Input A to J Low The module detected that an analogue input value of a DSE2131 had fallen below the Flexible Sensor Low Pre-Alarm Trip level.
Page 170 For further details of module configuration, refer to DSE Publication: 057-238 Charger ID 0 to 3 DSE8610 MKII Configuration Suite PC Software Manual. Common Warning The module detected that a battery charger connected by DSENet ®...
Page 171 For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Digital Input A to L The module detected that a digital input configured to create a fault condition became active and the appropriate LCD message is displayed.
Page 172 DSE Publication: 057- Flexible Sensor A to D High 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that an analogue input value had risen above the Flexible Sensor High Pre-Alarm Trip level.
Page 173 For further details of module configuration, refer to DSE Publication: 057- Maintenance Due 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that one of the configured maintenance alarms is due as its configured maintenance interval has expired.
Page 174 Protections Fault Description The module detected that an input configured for MSC Alarms MSC Alarms Inhibited Inhibit had become active disabling all the MSC alarms. That module detected that the MSC and Redundant MSC MSC 1 and 2 Failure communication failed, most likely caused by it being disconnected. The module detected that data on the MSC link had become MSC 1 Data Error corrupt, possibly caused by incorrect wiring or faulty cabling.
Page 175: Electrical Trip Alarms
For further details of module configuration, refer to DSE Publication: 057- 2130 ID 1 to 4 Analogue 238 DSE8610 MKII Configuration Suite PC Software Manual. Input E to H High The module detected that an analogue input value of a DSE2130 had risen above the Flexible Sensor High Alarm Trip level.
Page 176 For further details of module configuration, refer to DSE Publication: 057- 2131 ID 1 to 4 Analogue 238 DSE8610 MKII Configuration Suite PC Software Manual. Input A to J High The module detected that an analogue input value of a DSE2131 had risen above the Flexible Sensor High Alarm Trip level.
Page 177 For further details of module configuration, refer to DSE Publication: 057-238 Charger ID 0 to 3 Common DSE8610 MKII Configuration Suite PC Software Manual. Electrical Trip ® The module detected that a battery charger connected by DSENet had issued a Common Electrical Trip Alarm.
Page 178 DSE Publication: 057- Flexible Sensor A to D High 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that an analogue input value had risen above the Flexible Sensor High Alarm Trip level.
Page 179 For further details of module configuration, refer to DSE Publication: 057- Maintenance Due 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that one of the configured maintenance alarms is due as its configured maintenance interval has expired.
Page 180 Protections Fault Description The module detected that another module on the MSC link was incompatible. Check all the module firmware version numbers (under About | Application Number on the modules’ displays) and MSC Old Version Unit ensure all are the latest version firmware. Use the DSE Configuration Suite Software to upgrade the firmware (Tools | Update Firmware) of the older modules.
Page 181: Shutdown Alarms
For further details of module configuration, refer to DSE Publication: 057- 2130 ID 1 to 4 Analogue 238 DSE8610 MKII Configuration Suite PC Software Manual. Input E to H High The module detected that an analogue input value of a DSE2130 had risen above the Flexible Sensor High Alarm Trip level.
Page 182 For further details of module configuration, refer to DSE Publication: 057- 2131 ID 1 to 4 Analogue 238 DSE8610 MKII Configuration Suite PC Software Manual. Input A to J High The module detected that an analogue input value of a DSE2131 had risen above the Flexible Sensor High Alarm Trip level.
Page 183 For further Charger ID 0 to 3 Common details of module configuration, refer to DSE Publication: 057- Shutdown 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that a battery charger connected by ® DSENet had issued a Common Shutdown Alarm.
Page 184 For further details of module configuration, refer to DSE Publication: 057- 238 DSE8610 MKII Configuration Suite PC Software Manual. Digital Input A to L The module detected that a digital input configured to create a fault condition became active and the appropriate LCD message is displayed.
Page 185 DSE Publication: 057- Flexible Sensor A to D Low 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that an analogue input value had fallen below the Flexible Sensor Low Alarm Trip level.
Page 186 For further details of module configuration, refer to DSE Publication: 057- Maintenance Due 238 DSE8610 MKII Configuration Suite PC Software Manual. The module detected that one of the configured maintenance alarms is due as its configured maintenance interval has expired.
Page 187: Maintenance Alarms
Protections 6.6 MAINTENANCE ALARMS Depending upon module configuration one or more levels of engine maintenance alarm may occur based upon a configurable schedule. Example 1: Screen capture from DSE Configuration Suite Software showing the configuration of the Maintenance Alarm for 1, 2 and 3. When activated, the maintenance alarm can be either a warning (set continues to run) or shutdown...
Page 188: Mains Decoupling Alarms
Protections Example 3: Screen capture from DSE Configuration Suite Software showing the Maintenance Alarm Reset ‘button’ in the DSE Configuration Suite SCADA | MAINTENANCE section. Example 4: Screen capture from DSE Configuration Suite Software showing the configuration holding stop button to reset the maintenance alarm. 6.7 MAINS DECOUPLING ALARMS NOTE: These protections only operate only when the mains and generator bus are in parallel, it is disabled at all other times.
Page 189: Over Current Alarm
Protections 6.8 OVER CURRENT ALARM The Over Current Alarm combines a simple warning trip level with a fully functioning IDMT curve for thermal protection. 6.8.1 IMMEDIATE WARNING If the Immediate Warning is enabled, the controller generates a warning alarm as soon as the Trip level is reached.
Page 190: Inverse Definite Minimum Time (Idmt) Alarm
Protections 6.8.2 INVERSE DEFINITE MINIMUM TIME (IDMT) ALARM If the Over Current IDMT Alarm is enabled, the controller begins following the IDMT ‘curve’ when the current on any phase passes the Trip setting. If the Trip is surpassed for an excess amount of time, the IDMT Alarm triggers (Shutdown or Electrical Trip as selected in Action).
Page 191: Creating A Spreadsheet For The Over Current Idmt Curve
Protections 6.8.2.1 CREATING A SPREADSHEET FOR THE OVER CURRENT IDMT CURVE The formula used: �� = �� − 1) �� Where: �� is the tripping time in seconds �� is the actual measured current of the most highly loaded line (L1, L2 or L3) ��...
Page 192 Protections Over Current IDMT Alarm Curves 100000000 10000000 1000000 100000 10000 1000 Current as a Multiple of I Time Multiplier = 1 Time Multiplier = 18 Time Multiplier = 36 (Default Setting) Time Multiplier = 72 057-254 ISSUE: 10 Page 192 of 246...
Page 193: Short Circuit Idmt Alarm
Protections 6.9 SHORT CIRCUIT IDMT ALARM If the Short Circuit Alarm is enabled, the controller begins following the IDMT ‘curve’ when the current on any phase passes the Trip setting. If the Trip is surpassed for an excess amount of time, the IDMT Alarm triggers (Shutdown or Electrical trip as selected in Action).
Page 194: Creating A Spreadsheet For The Short Circuit Idmt Curve
Protections 6.9.1 CREATING A SPREADSHEET FOR THE SHORT CIRCUIT IDMT CURVE The formula used: �� × 0.14 �� = 0.02 �� − 1) �� Where: �� is the tripping time in seconds (accurate to +/- 5% or +/- 50 ms (whichever is greater)) ��...
Page 195 Protections Short Circuit IDMT Alarm Curves 10000 1000 0.01 Current as a Multiple of I Time Multiplier = 0.01 (Default Setting) Time Multiplier = 0.02 Time Multiplier = 0.04 Time Multiplier = 0.08 Time Multiplier = 0.16 Page 195 of 246 057-254 ISSUE: 10...
Page 196: Earth Fault Idmt Alarm
Protections 6.10 EARTH FAULT IDMT ALARM When the module is suitably connected using the ‘Earth Fault CT’. The module measures Earth Fault and can optionally be configured to generate an alarm condition (shutdown or electrical trip) when a specified level is surpassed. If the Earth Fault Alarm is enabled, the controller begins following the IDMT ‘curve’...
Page 197: Creating A Spreadsheet For The Earth Fault Idmt Curve
Protections 6.10.1 CREATING A SPREADSHEET FOR THE EARTH FAULT IDMT CURVE The formula used: �� × 0.14 �� = 0.02 �� − 1) �� Where: �� is the tripping time in seconds (accurate to +/- 5% or +/- 50 ms (whichever is greater)) ��...
Page 198 Protections Earth Fault IDMT Alarm Curves 100000 10000 1000 Current as a Multiple of I Time Multiplier = 0.1 (Default Setting) Time Multiplier = 0.2 Time Multiplier = 0.4 Time Multiplier = 0.8 Time Multiplier = 1.6 057-254 ISSUE: 10 Page 198 of 246...
Page 199: Default Current Protection Tripping Characteristics
Protections 6.11 DEFAULT CURRENT PROTECTION TRIPPING CHARACTERISTICS The graph on the following page shows the default settings for the IDMT tripping curves for the Over Current, Short Circuit and Earth Fault protections. The default setting for the Over Current alarm allows for an overload of an alternator to the limits of the Typical Brushless Alternator whereby 110% overload is permitted for 1 hour or 200% overload is permitted for 36 seconds.
Page 200 Protections DSE Default Configratuion of Over Current, Short Circuit & Earth Fault IDMT Alarm Curves 100000000 10000000 1000000 100000 10000 1000 0.01 Current as a Multiplier of The Full Load Current Rating Over Circuit IDMT Trip Curve with Time Multiplier = 36, Trip Point = 100% (Default Settings) Short Circuit IDMT Trip Curve with Time Multiplier = 0.01, Trip Point = 200% (Default Settings) Earth Fault IDMT Trip Curve with Time Multiplier = 0.1, Trip Point = 10% (Default Settings) 057-254 ISSUE: 10...
Page 201: Fault Ride Through
For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. The Fault Ride Through function is applicable for generators in parallel with the mains (whilst in Mains Parallel Mode) and generators that are paralleling with each other to supply critical power distribution networks.
Page 202 Protections The Connection Point Voltages (Uret, Uclear, Urec1, Urec2, Urec3) and time intervals (Tclear, Trec1, Trec2, Trec3, Trec4) are configured in the Fault Ride Through section of the module’s configuration. For guidance on how to configure these settings, refer to the relevant standards for Fault Ride Through protection which are normally governed by mains parallel standards.
Page 203: Front Panel Configuration
Front Panel Configuration 7 FRONT PANEL CONFIGURATION This configuration mode allows the operator to fully configure the module through its display without the use of the DSE Configuration Suite PC Software. Use the module’s facia buttons to traverse the menu and make value changes to the parameters: Next Parameter / Increase Valvue Next...
Page 204: Main Configuration Edtior
DSE8610 MKII Configuration Suite PC Software Manual. NOTE: Depending upon module configuration, some parameters in the Main Editor may not be available. For more information refer to DSE publication 057-238 DSE8610 MKII Configuration Suite PC Software Manual available from www.deepseaelectronics.com •...
Page 205: Editing A Parameter
Front Panel Configuration 7.1.3 EDITING A PARAMETER NOTE: Pressing and holding the Menu Navigation buttons provides the auto-repeat functionality. Values can be changed quickly by holding the navigation buttons for a prolonged period of time. • Press the Right or Left buttons to cycle to the section to view/change.
Page 206: Main Configuration Editor Parameters
Front Panel Configuration 7.1.5 MAIN CONFIGURATION EDITOR PARAMETERS Section Parameter As Shown On Display Values Display Contrast Language English, Other. Current Date and Time DD:MM:YY, hh:mm:ss Alt Config Default Config Default Config / Alternative Config Engine Oil Pressure Low Shutdown 0.00 bar Oil Pressure Low Pre Alarm 0.00 bar...
Page 207 Front Panel Configuration Section Parameter As Shown On Display Values Generator Under Voltage Shutdown Under Voltage Pre-Alarm Loading Voltage Nominal Voltage Over Voltage Pre-Alarm Over Voltage Shutdown Under Frequency Shutdown 0.0 Hz Under Frequency Pre-Alarm 0.0 Hz Loading Frequency 0.0 Hz Nominal frequency 0.0 Hz Over Frequency Pre-Alarm...
Page 208 Front Panel Configuration Section Parameter As Shown On Display Values Timers LCD Page Timer 0 h 0 m 0 s Scroll Delay 0 h 0 m 0 s Engine Pre Heat Timer 0 h 0 m 0 s Engine Post Heat Timer 0 h 0 m 0 s Engine Cranking 0 m 0 s...
Page 209: Running' Configuration Editor
7.2.1 ACCESSING THE ‘RUNNING’ CONFIGURATION EDITOR NOTE: Depending upon module configuration, some parameters in the ‘Running’ Editor may not be available. For more information refer to DSE publication 057-238 DSE8610 MKII Configuration Suite PC Software Manual available from www.deepseaelectronics.com •...
Page 210: Exiting The 'Running' Configuration Editor
Front Panel Configuration 7.2.4 EXITING THE ‘RUNNING’ CONFIGURATION EDITOR NOTE: The editor automatically exits after 5 minutes of inactivity to ensure security. • Press and hold the Tick button to exit the editor and save the changes. ‘RUNNING’ CONFIGURATION EDITOR PARAMETERS 7.2.5 Section Parameter As Shown On Display...
Page 211: Commisioning
Commissioning 8 COMMISIONING NOTE: If satisfactory operation cannot be achieved, despite repeated checking of the connections between the module and the system, then contact DSE Technical Support Department: support@deepseaelectronics.com 8.1 BASIC CHECKS NOTE: If Emergency Stop feature is not required, link the input to the DC Positive. Before the system is started, it is recommended that the following checks are made: The unit is adequately cooled and all the wiring to the module is of a standard and rating compatible with the system.
Page 212: Dse 4 Steps To Successful Synchronising
This causes long and unstable synchronising as well as unstable kW and kvar load sharing. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Continued overleaf… 057-254 ISSUE: 10...
Page 213: Determining Connections And Settings For Governors
Commissioning 8.2.1.1 DETERMINING CONNECTIONS AND SETTINGS FOR GOVERNORS Setting up the Governor (Adjustment of SW1 and SW2) Before You Start Ensure that generator bus is not live, has no load connected, the other generator’s breakers are open, and the Frequency Droop function and Mains Parallel Mode digital input within the module are disabled.
Page 214 Commissioning Adjustment of Governor SW2 NOTE: If it is not possible to achieve ±2.5 Hz adjustment with the governor, contact DSE Technical Support for further advice: support@deepseaelectronics.com 10. Increase the setting of the Nominal Frequency by 2.5 Hz (52.5 Hz or 62.5 Hz). If Frequency Droop is enabled, increase the Nominal Frequency by the Maximum Frequency Difference From Nominal (Max Hz Up) within the Droop Curve.
Page 215: Determining Connections And Settings For Avrs
Commissioning 8.2.1.2 DETERMINING CONNECTIONS AND SETTINGS FOR AVRS NOTE: Determining the settings of SW1 and SW2 for the AVR MUST only be done once the setup for SW1 and SW2 for the governor has been complete. Changing engine speed affects the level of voltage produced.
Page 216 Commissioning Adjustment of AVR SW2 NOTE: If it is not possible to achieve ±10 % voltage adjustment with the AVR, contact DSE Technical Support for further advice: support@deepseaelectronics.com 10. Increase the setting of the Nominal Voltage by 10% (230 V to 253 V for example). If Voltage Droop is enabled, increase the Nominal Voltage by the Maximum Voltage Difference From Nominal (Max Volt Up) within the Droop Curve.
Page 217: Metering
Commissioning 8.2.2 METERING WARNING!: Do not disconnect the CT wires from the DSE module when the CTs are carrying current. Disconnection open circuits the secondary of the CT’s and dangerous voltages may then develop. Always ensure the CTs are not carrying current and the CTs are short circuit connected before making or breaking connections to the module.
Page 218: Cts In The Right Direction
Commissioning 8.2.2.2 CTS IN THE RIGHT DIRECTION NOTE: Checking that the CTs are on the right phase MUST be completed prior to checking if the CTs are in the correct direction. CTs on the wrong phase also cause negative kWs. Check to ensure that the CTs on L1, L2 &...
Page 219: Communications
DSE controllers leading to problems during load sharing. NOTE: For further details of module configuration, refer to DSE Publication: 057-238 DSE8610 MKII Configuration Suite PC Software Manual. Check to ensure that all the modules are connected are communicating correctly on the MSC link and Redundant MSC (if used).
Page 220: Sync Checks
Commissioning 8.2.4 SYNC CHECKS CAUTION!: Failure to perform the Sync Check steps results in in serious damage to the system (breakers, bus bars, alternators, engines etc) caused by out of sync closures. Check to ensure that all the module’s sensing cables have been connected to the correct phases and that the generator’s load switch has been correctly connected.
Page 221: Incorrectly Wired Breaker
Commissioning 8.2.4.1 INCORRECTLY WIRED BREAKER When the DSE module’s synchroscope shows the two supplies in sync, if the voltage meter shows a voltage difference the breaker is wired incorrectly. This is shown in the example below. Page 221 of 246 057-254 ISSUE: 10...
Page 222: Correctly Wired Breaker
Commissioning 8.2.4.2 CORRECTLY WIRED BREAKER When the DSE module’s synchroscope shows the two supplies in sync, if the voltage meter shows no voltage difference the breaker is wired correctly. This is shown in the example below. 057-254 ISSUE: 10 Page 222 of 246...
Page 223: Dse Steps To Successful Loadsharing
Commissioning 8.3 DSE STEPS TO SUCCESSFUL LOADSHARING Synchronising and load sharing is often considered to be a complex subject. In fact, it is very simple when broken down into smaller steps. Before parallel operation between generators or another electrical supply is attempted, the DSE Four Steps to Successful Synchronising must be followed and completed on each of the generators.
Page 224: Droop Loadsharing
Commissioning 8.3.1.2 DROOP LOADSHARING NOTE: For further details about Isochronous Loadsharing operation, refer to section entitled Prime Power (Load Share) elsewhere within this document. When generators are running in parallel in Droop only, the amount of power they produce to the load has to be controlled to ensure it is shared between the generators, by varying the frequency and voltage the system is running at.
Page 225: Adjusting Gain (P), Stability (I) And Derivative (D)
Commissioning 8.3.2 ADJUSTING GAIN (P), STABILITY (I) AND DERIVATIVE (D) 8.3.2.1 INITIAL SETUP In most cases the DSE factory settings of 20% for Gain (P), Stability (I) and 0 % for Derivative (D) are suitable for most systems. This is because the DSE module’s control is limited by the Gain (P), Stability (I) and Derivative (D) settings of the engine’s governor / alternator’s AVR.
Page 226: Troubleshooting
Commissioning 8.3.2.3 TROUBLESHOOTING NOTE: An over damped response results in a slower control process. An under damped response (overshooting the target) leads to an unstable control process. Either case leads to undesirable consequences such as overcurrent or reverse power, resulting in generator shutdown, and loss of supply to the load. If the load is oscillating quickly between the generators it suggests that the setting for the Gain (P) on the generator(s) is too high or too low.
Page 227: Fault Finding
Fault Finding 9 FAULT FINDING NOTE: The below fault finding is provided as a guide checklist only. As the module can be configured to provide a wide range of different features, always refer to the source of the module configuration if in doubt. 9.1 STARTING Symptom Possible Remedy...
Page 228: Alarms
Fault Finding 9.3 ALARMS Symptom Possible Remedy Oil pressure low fault Check engine oil pressure. Check oil pressure switch/sensor and operates after engine has wiring. Check configured polarity (if applicable) is correct (i.e. fired Normally Open or Normally Closed) or that sensor is compatible with the module and is correctly configured.
Page 229: Synchronising & Load Sharing
Fault Finding 9.6 SYNCHRONISING & LOAD SHARING Symptom Possible Remedy Synchronising not available Check Synchronising is enabled in the configuration suite software Generator, Synchronising section Generator does not Ensure that all the DSE Four Steps to Synchronising have been loadshare correctly completed.
Page 230: Can Interface Specification (J1939-75)
NOTE: All broadcast CAN messages are priority 3 by default, it is not possible to change the priority of the configurable CAN messages. For further details of module configuration, refer to DSE Publication: 057- 238 DSE8610 MKII Configuration Software Manual. NOTE: SPNs that are not implemented in the module have all bits set to ‘1’.
Page 231: Acs - Ac Switching Device Status
CAN Interface Specification (J1939-75) 10.1.1 ACS - AC SWITCHING DEVICE STATUS PGN 64913 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 250 ms Decimal Instrument Byte / Bit Scaling Offset Units 0DD9 3545 Generator Breaker Status - Byte 1 000: Open This parameter indicates...
Page 232: Gaac - Generator Average Basic Ac Quantities
CAN Interface Specification (J1939-75) 10.1.3 GAAC - GENERATOR AVERAGE BASIC AC QUANTITIES PGN 65030 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 100 ms Decimal Instrument Byte / Bit Scaling Offset Units 0988 2440 Generator Avg. L-L AC Byte 1 to 2 Voltage 098C...
Page 233: Gpaacr - Generator Phase A Ac Reactive Power
CAN Interface Specification (J1939-75) 10.1.6 GPAACR - GENERATOR PHASE A AC REACTIVE POWER PGN 65025 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 100 ms Decimal Instrument Byte / Bit Scaling Offset Units 0999 2457 Generator Phase A Reactive Byte 1 to 4 -2*10 Power...
Page 234: Gpbacr - Generator Phase B Ac Reactive Power
CAN Interface Specification (J1939-75) 10.1.9 GPBACR - GENERATOR PHASE B AC REACTIVE POWER PGN 65022 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 100 ms Decimal Instrument Byte / Bit Scaling Offset Units 099A 2458 Generator Phase B Reactive Byte 1 to 4 -2*10 Power...
Page 235: Gpcacr - Generator Phase C Ac Reactive Power
CAN Interface Specification (J1939-75) 10.1.12 GPCACR - GENERATOR PHASE C AC REACTIVE POWER PGN 65019 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 100 ms Decimal Instrument Byte / Bit Scaling Offset Units 099B 2459 Generator Phase C Reactive Byte 1 to 4 -2*10 Power...
Page 236: Gtacp - Generator Total Ac Power
CAN Interface Specification (J1939-75) 10.1.16 GTACP - GENERATOR TOTAL AC POWER PGN65029 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 100 ms Decimal Instrument Byte / Bit Scaling Offset Units 0994 2452 Generator Total Real Power Byte 1 to 4 -2*10 099C 2460...
Page 237: Ec2 - Engine Configuration 2
CAN Interface Specification (J1939-75) 10.2.2 EC2 - ENGINE CONFIGURATION 2 PGN64895 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate Request Decimal Instrument Byte / Bit Scaling Offset Units 0E56 3670 Maximum Crank Attempts Byte 1 per Start Attempt 10.2.3 EEC1- ENGINE SPEED PGN61444 Ext Data...
Page 238: Eoi - Emergency Stop
CAN Interface Specification (J1939-75) 10.2.6 EOI - EMERGENCY STOP PGN64914 Ext Data Size Priority Page Data Page Format Specific (Bytes) Rate 250 ms Decimal Instrument Byte / Bit Scaling Offset Units 0E17 3607 Emergency Stop Byte 6 00: Off (No Shutdown Bit 6 to 8 Requested) 01: On (Shutdown...
Page 239: Dm01 - Conditions Active Diagnostic Trouble Codes
CAN Interface Specification (J1939-75) 10.2.10 DM01 - CONDITIONS ACTIVE DIAGNOSTIC TROUBLE CODES NOTE: The availability of the Engine Alarm SPN and FMI is dependent upon the engine file selected within the DSE module’s configuration. Contact DSE technical support: support@deepseaelectronics.com for more information. NOTE: If only one DM1 alarm is active the DM1 priority will remain as six.
Page 240 CAN Interface Specification (J1939-75) Engine Alarm Condition Warning FMI Shutdown FMI Fuel Level Low Oil Pressure Low (Analogue Sensor) Oil Pressure Low (Digital Input) Oil Pressure Sensor Fault Coolant Temperature High (Analogue Sensor) Coolant Temperature High (Digital Input) Coolant Temperature Sensor Fault Charge Alternator Failed Plant Battery Voltage High Plant Battery Voltage Low...
Page 241: Maintenance, Spares, Repair And Servicing
11.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE If additional plugs are required, contact our Sales department using the part numbers below. 11.1.1 PACK OF PLUGS Module Type Plug Pack Part Number DSE8610 MKII 007-891 11.1.2 INDIVIDUAL PLUGS Module Terminal Designation Plug Description Part No.
Page 242: Purchasing Additional Fixing Clips From Dse
Maintenance, Spares, Repair & Servicing 11.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE Item Description Part No. Module Fixing Clips (Packet of 4) 020-294 11.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE Item Description Part No. Module Silicon Sealing Gasket 020-564 11.4 PURCHASING REAR MOUNT PANEL BRACKET FROM DSE Item Description Part No.
Page 243: Dsenet Expansion Modules
Maintenance, Spares, Repair & Servicing 11.5 DSENET EXPANSION MODULES ® NOTE: A maximum of twenty (20) expansion modules can be connected to the DSE8610 ® MKII DSENet Port ® NOTE: DSENet utilises an RS485 connection. Using Belden 9841 (or equivalent) cable allows for the expansion cable to be extended to a maximum of 1.2 km.
Page 244: Warranty
Maintenance, Spares, Repair & Servicing 12 WARRANTY DSE Provides limited warranty to the equipment purchaser at the point of sale. For full details of any applicable warranty, refer to the original equipment supplier (OEM) 13 DISPOSAL 13.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT) If you use electrical and electronic equipment you must store, collect, treat, recycle and dispose of WEEE separately from your other waste 057-254 ISSUE: 10...
Page 245 This Page is Intentionally Blank...
Page 246 This Page is Intentionally Blank...

DEEP SEA ELECTRONICS DSE8610 MKII Operator's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for DEEP SEA ELECTRONICS DSE8610 MKII

Summary of Contents for DEEP SEA ELECTRONICS DSE8610 MKII
