DEEP SEA ELECTRONICS DSE860 Installation Instructions

Setting up the DSE860 / DSE865

DSE860 – For connection to DSE RS232 enabled controllers.
DSE865 – For connection to DSE RS485 enabled controllers.
'Plug and Play' setup
The DSE860/5 must be setup before it will communicate correctly on your network.
Full setup instructions are contained within the operator manual 057-099 DSE860/DSE865 operating
instructions available from
Visit www.deepseaplc.com

SPECIFICATION

DC SUPPLY

Nominal voltage
Protection against surges to
Power consumption

ENVIRONMENTAL SPECIFICATIONS

Operating Temperature
Storage Temperature
Vibration
Mechanical Shock
Humidity

DIMENSIONS

Overall size
Mounting type

APPLICABLE CODES AND STANDARDS

DSE860/5 meets or exceeds the following standards
EMC (Emissions and Immunity):
Usage within USA and Canada
D E E P S E A E L E C T R O N I C S
I N S T A L L A T I O N I N S T R U C T I O N S
www.deepseaplc.com
and select DSE DOWNLOADS.
8V to 35V continuous DC
60V DC
@ 12V DC - 110mA +/- 5%, app. (in 100BaseT mode)
-30° C to +70° C
-40° C to +85° C
2g, 10-500Hz, amplitude 0.15mm, 6g desirable
N/A
85%, relative, non-condensing, up to 85° C
86mm x 35mm x 57mm (case rear to case front)
(3.4" x 1.4" x 2.3")
M36 DIN-rail
EN61000-6-2 Generic Immunity
EN61000-6-3 Generic Emissions
UL 508, CSA 22.2, NFPA 70 / 110
D S E 8 6 0 / D S E 8 6 5
:
053-062 ISSUE 1
