- Page 1 CHARGER ABC SCHUTZKLASSE II USER MANUAL VERSION 6 01/09/2022 www.leab.eu LEAB Automotive GmbH Thorshammer 6 24866 Busdorf...
-
Page 2: Table Of Contents
Table of contents LEAB Automotive GmbH Table of contents 1 About this Manual ................2 Safety ....................2.1 Intended use..................2.2 Foreseeable misuse ................3 About this product ................4 Package contents .................. 5 Technical specifications................. 6 Charging characteristics ................ 11 7 Setting charging characteristics ............. -
Page 3: About This Manual
Skilled workers in the field of automotive electrics. Any modifications to the product or its components are prohibited and do not conform to its intended use. Only use original LEAB or LEAB-approved ac- cessories. Throughout the manual, you will be alerted to warnings and safety notices about potential hazards associated with handling the device. -
Page 4: Safety
2 Safety LEAB Automotive GmbH DANGER Danger that will lead to severe injury or death Safety instructions with the signal word Danger indicate a hazard which, if not avoided, will result in death or severe injury. Read the safety instructions carefully and follow them to avoid the hazard. - Page 5 LEAB Automotive GmbH 2 Safety WARNING Risk of fire from overheated battery Flammable gases can escape if the battery overheats. 1. Always charge batteries in well-ventilated rooms and away from ignition sources. WARNING Burns from escaping acid Acid can leak out when handling batteries.
-
Page 6: Foreseeable Misuse
2 Safety LEAB Automotive GmbH 2.2 Foreseeable misuse The charger is designed for permanent installation in vehicles; never install the charger outside the vehicle. Do not expose the unit to strong sunlight for a long period of time. Only charge Lead-acid batteries (wet, gel, AGM) with this charger. -
Page 7: About This Product
This guarantees optimum and gentle charging. Thanks to their compact design, high performance and excellent radio interference suppres- sion, LEAB chargers have been used for many years wherever optimum bat- tery charging is required. Fig. 1: ABC charger front view... -
Page 8: Package Contents
4 Package contents LEAB Automotive GmbH Fig. 2: ABC charger connection side 1 AC wire 2 On/off switch 3 DC wire 4 Sensor cable connection (CTS/ 5 Remote display connection 4 Package contents Package contents Battery charger Mounting clamp User manual... -
Page 9: Technical Specifications
LEAB Automotive GmbH 5 Technical specifications 5 Technical specifications Part no. 0101236020 Part no. 0101236030 Model ABC 2420 ABC 2430 Battery type Lead acid (wet, gel/AGM) Lead acid (wet, gel/AGM) Battery capacity 60 Ah ... 200 Ah 90 Ah ... 300 Ah... - Page 10 5 Technical specifications LEAB Automotive GmbH Part no. 0101236020 Part no. 0101236030 CTS/TS connection Remote display connec- tion On/off switch Part no. 0101236120 Part no. 0101236130 Model ABC 1220 ABC 1230 Battery type Lead acid (wet, gel/AGM) Lead acid (wet, gel/AGM) Battery capacity 60 Ah ...
-
Page 11: Charging Characteristics
LEAB Automotive GmbH 6 Charging characteristics Part no. 0101236120 Part no. 0101236130 Weight 2.0 kg 2.0 kg AC wire 2 m, 1 mm² 1.5 m, 1 mm² DC wire 2 x 2 m, 6 mm² 2 x 2 m, 6 mm² CBL connection CTS/TS connection Remote display connec- tion On/off switch 6 Charging characteristics The ABC charger contains 15 different charging characteristics which you can select before connecting to the battery. -
Page 12: Setting Charging Characteristics
7 Setting charging characteristics LEAB Automotive GmbH 7 Setting charging characteristics Notice Battery defect due to incorrect charging To protect the battery from damage due to incorrect charging, set a suitable charging characteristic before installation. Follow the battery manufacturer's instructions. -
Page 13: Assembly
LEAB Automotive GmbH 9 Installation 8 Assembly To assemble the unit, proceed as follows: ü Choose a cool, dry and well-ventilated assembly site. ü Do not mount the unit directly next to or above batteries. ü Guarantee adequate cooling for an unimpeded supply of cooling air. -
Page 14: Connecting The Sensor Cable
9 Installation LEAB Automotive GmbH 9.3 Connecting the sensor cable The TS sensor cable measures the ambient temperature to optimally charge the battery. The CTS sensor cable measures the battery temperature and voltage to optimally charge the battery. NOTE! When connecting, pay attention to the instructions and notes in the sensor cable installation instructions. -
Page 15: Connecting The Remote Display
LEAB Automotive GmbH 10 Operation 9.5 Connecting the remote display The remote display shows the charge status of the battery via an LED. To connect the remote display, proceed as follows: 1. Plug the connecting cable for the remote display into the connector for the remote display of the charger. -
Page 16: Led Status Display On The Charger
11 Maintenance LEAB Automotive GmbH 10.3 LED status display on the charger Status Description Action Steady light, or- Battery is charging. ange The charger is in the main char- ging phase. Steady light, Battery is fully charged, charger Charger can be switched off green is in trickle charge phase. -
Page 17: Disposal
LEAB Automotive GmbH 13 EU Declaration of Conformity 12 Disposal Dispose of the device in accordance with the Waste Elec- trical and Electronic Equipment Regulations (WEEE). The system must not be disposed of with household waste. Take it to a recycling point or return it to your point of sale. - Page 18 13 EU Declaration of Conformity LEAB Automotive GmbH LEAB Automotive GmbH Thorshammer 6 24866 Busdorf...
- Page 19 LEAB Automotive GmbH 13 EU Declaration of Conformity LEAB Automotive GmbH Thorshammer 6 24866 Busdorf...
- Page 20 We make energy mobile. LEAB Automotive GmbH Thorshammer 6 24866 Busdorf Tel: +49(0) 4621 9 78 60-0 Fax: +49 (0) 4621 9 78 60-260 info@leab.eu It is prohibited to copy, duplicate, translate or otherwise pass on the content of this document to third parties without the express written...
