INSTALLATION
CONTINUED
Methods For Attaching Mounting
Bracket To Wall
Only use last hole on each end
of mounting bracket to attach
bracket to wall. These two holes
are 16 inches apart from their
centers. Attach mounting
to wall only in one of two ways:
1. Attaching to wall stud
2. Attaching to wall anchor
Note: W all anchors,
screws, and spacers
hardware package. The
package is provided
Attaching to Wall Stud: This method
provides the strongest
mounting screws through mounting
bracket and into wall studs.
Attaching to Wall Anchor: This
m et ho d allow s you
mounting bracket to hollow walls
(wall areas between studs) or to
solid walls (concrete or masonry).
Decide which method
suits your needs. Either method
will provide a secure hold for the
mounting bracket.
Marking Screw Locations
1. Tape mounting bracket to wall
where heater will be located.
Make sure mounting bracket is
level.
WARNING:
Maintain mini-
mum clearances shown in Figure
6. If you can, provide greater clear-
ances from floor and joining wall.
2. Mark screw locations on wall.
(see Figure 6)
Note: Only mark last hole on
each end of mounting bracket.
Insert mounting screws through
these holes only.
3. Remove tape and mounting
bracket from wall.
Model MN200EPC MN200EHPC
bracket
mounting
are in
hardware
with heater.
hold. Insert
Model MN300EPC MN300EHPC
Figure 6 - Mounting Bracket
Clearances
Attaching to Wall Stud Method For
attaching mounting bracket to wall
to att ac h
studs
1. Drill holes at marked locations
using 9/64
2. Place mounting bracket onto
better
wall. Line up last hole on each
end of bracket with holes drilled
in wall.
3. Insert mounting screws through
bracket and into wall studs.
4. Tighten screws until mounting
bracket is firmly fastened to
wall studs.
Attaching to Wall Anchor Method
For attaching mounting bracket to
hollow walls (wall areas between
studs) or solid walls (concrete or
masonry)
1. Drill holes at marked locations
using 5/16
walls (concrete or masonry), drill
at least 1
2. Fold wall anchor as shown in
Figure 7 below.
Figure 7- Folding Anchor
Only Insert Mounting
Screws Through
Last Hole On Each
End
Floor
Only Insert Mounting
Screws Through
Last Hole On Each
End
Floor
"
drill bit.
"
drill bit. For solid
"
deep.
8
3. Insert wall anchor (wings
first) into hole. Tap anchor
flush to wall.
"
4. For thin walls (1/2
insert red key into wall
anchor. Push red key to
" "
pop open anchor wings
(see Figure 8).
IMPORTANT: Do not
hammer key! For thick walls
"
(over 1/2 thick) or solid walls,
do not pop open wings.
Figure 8 - Popping Open Anchor
Wing For Thin Walls
5. Place mounting bracket onto
wall. Line up last hole on
each end of bracket with wall
anchors.
6. Insert mounting screws through
bracket and into wall anchors.
7. Tighten screws until mounting
bracket is firmly fastened to wall.
Placing Heater on Mounting
Bracket
1. Locate two horizontal slots on
back panel of heater (see
Figure 9).
2. Place heater onto mounting
bracket. Slide horizontal slots
onto stand-out
mounting bracket.
Figure 9 - Mounting Heater Onto
Mounting Bracket
or less),
tabs on
