Procom ML100HBAHR Owner's Operation And Installation Manual
Blue flame vent-free propane/lp gas heater
Hide thumbs
Also See for ML100HBAHR:
- Owner's operation and installation manual (23 pages) ,
- Owner's operation and installation manual (22 pages)
Table of Contents
Advertisement
10,000 BTU/Hr
Thermostatically-Controlled Heater
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-573-0674, 7:30 am - 4:15 pm CST,
Monday through Friday or email customerservice@usaprocom.com
BLUE FLAME VENT-FREE
PROPANE/LP GAS HEATER
OWNER'S OPERATION AND
INSTALLATION MANUAL
MODELS
ML100HBAHR
ML100TBAHR
Advertisement
Table of Contents
Related Manuals for Procom ML100HBAHR
Summary of Contents for Procom ML100HBAHR
- Page 1 BLUE FLAME VENT-FREE PROPANE/LP GAS HEATER OWNER’S OPERATION AND INSTALLATION MANUAL MODELS ML100HBAHR ML100TBAHR 10,000 BTU/Hr Thermostatically-Controlled Heater WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ............3 Operation ..........16 Product Features ........5 Inspecting Heater ........19 Specifications ..........5 Care And Maintenance ......20 Qualified Installing Agency ......6 Troubleshooting ........21 Product Features ........6 Replacement Parts ........28 Local Codes.......... -
Page 3: Safety
SAFETY PROPANE/LP GAS: Propane/LP gas is IMPORTANT: Read this owner’s odorless. An odor-making agent is added manual carefully and completely to the gas. The odor helps you detect a gas before trying to assemble, op- leak. However, the odor added to the gas erate, or service this heater. - Page 4 SAFETY 1. Do not place Propane/LP supply tank(s) 10. Turn off heater and let cool before servic- inside any structure. Propane/LP supply ing. Only a qualified service person should tank(s) must be placed outdoors. service and repair heater. 2. Heaters with a maximum input over 11.
-
Page 5: Product Features
PRODUCT FEATURES Figure 1 - Vent-Free Gas Heater SPECIFICATIONS MODEL ML100HBAHR ML100TBAHR Ignition Piezo Piezo Gas Type Propane/LP Gas Propane/LP Gas BTU (available) 5,500/10,000 10,000 Pressure Regulator Setting 8" W.C. 8" W.C. Maximum 14" Maximum 14" Inlet Gas Pressure* (inches of water) Minimum 11"... -
Page 6: Qualified Installing Agency
QUALIFIED INSTALLING AGENCY Only a qualified agency should install and a) Installing, testing, or replacing gas piping replace gas piping, gas utilization equipment or accessories, and repair and equipment ser- b) Connecting, installing, testing, repairing, vicing. The term “qualified agency” means any or servicing equipment;... -
Page 7: Propane/Lp Supply
PROPANE/LP SUPPLY Propane/LP gas and propane/LP tank(s) are propane/LP tanks varies. Two factors decide to be furnished by the user. The propane/LP this amount: cylinder to be used must be constructed and 1. The amount of propane/LP gas in tank(s) marked in accordance with the specifications 2. - Page 8 AIR FOR COMBUSTION AND VENTILATION VENTILATION AIR Ventilation Air From Inside Building Ventilation Air From Outdoors This fresh air would come from an adjoining Provide extra fresh air by using ventilation unconfined space. When ventilating to an grills or ducts. You must provide two perma- adjoining unconfined space, you must provide nent openings: one within 12"...
-
Page 9: Installation
INSTALLATION NOTICE: This heater is intended CAUTION: This heater cre- for use as supplemental heat. ates warm air currents. These Use this heater along with your currents move heat to wall sur- primary heating system. Do not faces next to heater. Installing install this heater as your pri- heater next to vinyl or cloth wall mary heat source. - Page 10 INSTALLATION LOCATING HEATER Removing Front Panel of Heater 1. Remove two screws near bottom corners This heater is designed to be mounted on of lower front panel. a wall. 2. Pull bottom of lower front panel forward, For convenience and efficiency, install heater: then down (see Figure 7).
- Page 11 INSTALLATION Marking Screw Locations 1. Drill holes at marked locations using 1. Tape mounting bracket to wall where 5/16" drill bit. For solid walls (concrete or heater will be located. Make sure mount- masonry), drill at least 1" deep. ing bracket is level. 2.
- Page 12 INSTALLATION Installing Bottom Mounting Bracket 9. Tighten both screws until heater is firmly 1. Install bottom bracket to heater bottom secured to wall. Do not over tighten. with two screws. It may be more conve- Note: Do not replace front panel at this time. nient to remove heater from wall bracket Replace front panel after making gas connec- to attach.
- Page 13 INSTALLATION 1. Remove gas fitting from hardware bag. 8. Check all connections for leaks. Apply a noncorrosive leak detection fluid to gas 2. Apply pipe joint sealant lightly to male joints. Bubbles forming show a leak that NPT threads (see Figure 13). This will must be corrected.
- Page 14 INSTALLATION • sealant (resistant to natural gas and pro- CAUTION: Never connect pane/LP gas) heater directly to the gas supply. • equipment shutoff valve* This heater requires an external • test gauge connection* • sediment trap regulator (not supplied). Install •...
- Page 15 INSTALLATION Install sediment trap in supply line as shown in A sediment trap traps moisture and contami- Figure 15, page 14. Place sediment trap where nants. This keeps them from going into heater it is within reach for cleaning. Place sediment controls.
-
Page 16: Operation
• Do not try to light any appliance. the control system and any gas control • Do not touch any electric switch; do which has been under water. MANUAL CONTROL MODEL ML100HBAHR LIGHTING INSTRUCTIONS 1. STOP! Read the safety information above. contact a qualified service technician or gas supplier for repairs. - Page 17 OPERATION Ignitor Electrode Thermocouple CAUTION: Do not try to ad- just heating levels by using the Pilot Burner equipment shutoff valve. Figure 20 - Pilot THERMOSTAT MODEL ML100TBAHR LIGHTING INSTRUCTIONS 1. STOP! Read the safety information on Also contact a qualified service technician page 16.
- Page 18 OPERATION THERMOSTAT CONTROL OPERATION The thermostatic control used on these mod- Note: The thermostat sensing bulb measures els differ from standard thermostats. Standard the temperature of air near the heater cabinet. thermostats simply turn the burner on and off. This may not always agree with room tem- The thermostat used on this heater senses perature (depending on housing construction, the room temperature.
-
Page 19: Inspecting Heater
INSPECTING HEATER IMPORTANT: Owner’s should check pilot flame pattern and burner flame pattern often. Incorrect flame patterns indicate the need for cleaning (see Care and Maintenance, page 20) or service. WARNING: Only a qualified service person should service and repair heater. This includes maintenance requiring replacement or alteration of components. -
Page 20: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before servicing. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service techni- cian. -
Page 21: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. - Page 22 TROUBLESHOOTING Problem Possible Cause Corrective Action ODS/pilot lights but flame 1. Control knob is not fully 1. Press in control knob fully. goes out when control pressed in. knob is released. 2. Control knob is not pressed 2. After ODS/pilot lights, keep in long enough.
- Page 23 TROUBLESHOOTING Problem Possible Cause Corrective Action Slight smoke or odor 1. Residues from manufactur- 1. Problem will stop after a few during initial operation. ing process. hours of operation. Heater produces a click- 1. Metal is expanding while 1. This is common with most ing/ticking noise just after heating or contracting while heaters.
- Page 24 PARTS MODEL ML100HBAHR 18 16 22-1 22-2 ODS Pilot Assembly www.usaprocom.com 200052-01B...
- Page 25 PARTS MODEL ML100HBAHR This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 28 of this manual. ITEM PART # DESCRIPTION **MB10008 Cabinet Assembly MB09003 Lower Front Panel Assembly...
- Page 26 PARTS MODEL ML100TBAHR 26-1 26-2 ODS Pilot Assembly www.usaprocom.com 200052-01B...
- Page 27 PARTS MODEL ML100TBAHR This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 28 of this manual. ITEM PART # DESCRIPTION **MB10007 Cabinet Assembly MB09003 Lower Front Panel Assembly **MB11005 Reflector Unit ML086-03...
-
Page 28: Replacement Parts
• Purchase date ACCESSORIES Purchase these heater accessories from your local dealer. If they can not supply these acces- sories, contact ProCom Heating, Inc. at 1-866-573-0674 for information. EQUIPMENT SHUTOFF VALVE For all models. Equipment shutoff valve with 1/8" NPT tap. -
Page 29: Service Hints
TECHNICAL SERVICE You may have further questions about installation, operation, or troubleshooting. If so, contact ProCom Heating, Inc. at 1-866-573-0674. When calling, please have your model and serial numbers of your heater ready. www.usaprocom.com... - Page 30 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ www.usaprocom.com 200052-01B...
- Page 31 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ www.usaprocom.com 200052-01B...
-
Page 32: Warranty
We make no other warranty, expressed or implied. LIMITED WARRANTY ProCom Heating, Inc. warrants this product to be free from defects in materials and components for ONE (1) year from the date of first purchase, provided that the product has been properly installed by a qualified installer in accordance with all local codes and instructions furnished with the unit, operated and main- tained in accordance with all applicable instructions.
