20. Final assembly of the duct covers (canopy):
21. Fit control ball with its molex plug on its housing
Lower section of the duct cover serves to hang the
and twist in place.
decorative panel.
Use pins (2 upper + fixing screws and 1 at the
bottom) to fix the decorative panel.
Check that panel is firmly fixed on its position.
a
Rear View
b
°
˜ 15
c
OK!
Bottom pin
Decorative panel
